Product Overview
The GE Fanuc IC660EBD100 is a discrete input/output Electronics Assembly designed to operate as part sur the Genius I/O Block family within distributed industrial control systems. This module serves as the intelligent electronics portion sur a modular I/O block and is engineered to support discrete input operations when paired with a compatible terminal base unité.
The IC660EBD100 enables high-speed, real-time communication over the Genius bus and provides enhanced diagnostics and configuration capabilities. It is designed to work in harsh industrial environments where reliability, noise immunitéy, and modularity are critical.
Key Features
-
Designed for use with discrete I/O terminal bases
-
Compatible with Genius I/O networks for fast and reliable data communication
-
Provides 16 discrete inputs with configurable logic
-
Optical isolation between field and logic circuits
-
Built-in diagnostic and status indicators for simplified maintenance
-
Retains user configuration with non-volatile memory
-
Hot-swap capable electronics without disturbing wiring
-
Supports various industrial voltage levels and input types
-
Fully compatible with legacy GE Fanuc Genius systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Modèle Number | IC660EBD100 |
| Type | Discrete Input I/O Electronics Assembly |
| Supported I/O | 16 discrete inputs |
| Input Voltage Range | 10–30 VDC |
| Input Type | Sourcing or sinking (depends on base) |
| Input Current | Typically 6.5 mA at 24 VDC |
| Communication Interface | Genius Bus Network |
| Status Indicators | LEDs for power, network, and input status |
| Diagnostics | Input short circuit, open load, over-voltage detection |
| Configuration Method | Handheld Monitor or configuration ssurtware |
| Memory Type | Non-volatile configuration memory |
| Hot Swap Support | Yes (electronics module only) |
| Isolation | Optical between field and logic circuits |
| Power Supply | Supplied from terminal base |
| Dimensions | 224.4 x 88.9 x 100 mm |
| Poids | 1.8 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting | Plug-in to terminal base unité |
| Certifications | UL, CSA, CE compliant, Class I Div 2 compliant |
Industry Applications
-
Factory Automation: For managing sensors and switches in automated lines
-
Packaging Systems: Monitors limit switches, photoeyes, and control buttons
-
Power Generation: For system protection, monitoring, and feedback systems
-
Oil & Gas Facilities: Used for critical process monitoring and feedback control
-
Water Treatment Plants: Supports input from pumps, valves, and safety sensors
-
Industrial Machinery OEMs: Embedded within custom control solutions
Product Advantages
-
Dedicated Discrete Input Design: Simplifies control logic and wiring
-
Network-Enabled: Integrates with Genius bus for decentralized control
-
Flexible Configuration: Input logic configurable for varied application needs
-
Rugged Performance: Built for long-term industrial use with high durability
-
Reduced Downtime: Onboard diagnostics help prevent and identify issues quickly
-
Modular Assembly: Electronics can be replaced without touching field wiring
-
Legacy Compatibility: Suitable for upgrades and expansions sur existing GE Genius installations
-
Ease sur Maintenance: LED indicators and handheld monitor interface speed up diagnostics
Questions fréquentes (FAQ)
-
What kind sur inputs does the IC660EBD100 support?
It supports 16 discrete digital inputs, either sourcing or sinking based on the terminal base used. -
Does it provide input isolation?
Yes, optical isolation is provided between logic and field-side circuits. -
How is configuration stored in this module?
It uses non-volatile memory to retain configuration through power cycles. -
Can I replace the electronics unité without disconnecting field wiring?
Yes, the modular design allows hot-swapping sur the electronics unité independently. -
Is this product compatible with legacy Genius I/O systems?
Yes, it is fully compatible with GE Fanuc Genius legacy systems. -
How do I configure the IC660EBD100?
You can use a GE Handheld Monitor or compatible ssurtware tools. -
Does this module provide input diagnostics?
Yes, it provides LED diagnostics for input status and faults. -
Can it be used in hazardous locations?
Yes, when installed in accordance with specifications, it meets Class I Div 2 compliance. -
What voltage is required for input detection?
It supports 10–30 VDC inputs, typically 24 VDC. -
What terminal base does this module require?
It must be installed into a compatible Genius discrete input terminal base unité.
Related Modèles in the Same Series
| Modèle Number | Description |
|---|---|
| IC660EBD020 | Discrete I/O Electronics (16 Inputs / 16 Outputs) |
| IC660EBD101 | 16-Point Output Block Electronics |
| IC660TBD100 | Terminal Base for 16-Point Discrete Input |
| IC660BBD120 | 32-Point Discrete Sink I/O Block |
| IC660BBA103 | Thermocouple Input Block |
| IC660EBA105 | Analog/Digital I/O Block Electronics |
Popular GE Fanuc Modules
| Modèle Number | Description |
|---|---|
| IC693CPU372 | High-performance CPU with Ethernet Interface |
| IC695PSD140 | RX3i Redundant Power Supply Module |
| IC693MDL654 | 32-Point DC Input Module |
| IC695CHS012 | RX3i Series 12-Slot Rack |
| IC693ALG391 | 2-Channel Analog Output Module |
| IC660BPM100 | Genius Handheld Monitor |
