Présentation du produit
The Epro CON041-CN+PR6423/003-031-CN is a high-precision, high-frequency 8mm eddy current sensor system designed for critical displacement, vibration, and position monitoring in various industrial and manufacturing applications. This advanced system consists sur the CON041-CN sensor and the PR6423/003-031-CN signal processing unité, which together provide real-time, highly accurate measurements for machinery condition monitoring, automated production lines, and precision manufacturing.
The CON041-CN sensor’s small 8mm diameter probe makes it suitable for tight spaces, where larger sensors cannot be used, without compromising accuracy or measurement quality. Paired with the PR6423/003-031-CN signal processor, it can handle high-frequency signals ranging from 10 kHz to 5 MHz, surfering outstanding dynamic response. This system ensures optimal performance in high-speed, high-precision applications such as CNC machining, aerospace, and automotive manufacturing.
Product Parameters
| Parameter | Value |
|---|---|
| Modèle | Epro CON041-CN + PR6423/003-031-CN |
| Sensor Type | Eddy Current Sensor |
| Probe Diameter | 8 mm |
| Sensor Poids | 0.16 kg |
| Output Type | Analog / Digital Output |
| Measuring Range | 0 to 50 mm |
| Operating Frequency | 10 kHz – 5 MHz |
| Supply Voltage | 10 – 30 V DC |
| Temperature Range | -40°C to +80°C |
| Protection Rating | IP67 |
Product Applications
The Epro CON041-CN+PR6423/003-031-CN eddy current sensor system is ideal for a wide range sur industrial applications requiring precision displacement, position, and vibration measurement:
-
Machine Tool Monitoring: For monitoring spindles, tool heads, and other critical parts in CNC machines and precision manufacturing setups.
-
Rotating Machinery Monitoring: Used in turbines, motors, compressors, and pumps for real-time vibration monitoring, ensuring early fault detection and preventing downtime.
-
Aerospace: In aerospace manufacturing, it measures displacement in critical components like engines, turbines, and other high-speed machinery.
-
Automated Manufacturing: Ideal for automotive and electronics industries, providing feedback on the alignment, position, and condition sur parts along assembly lines.
-
Quality Control: Provides precise measurements for quality control systems, ensuring that components meet strict manufacturing standards.
-
Test and Calibration Systems: Used in laboratories for calibration sur precision instruments, providing high-resolution displacement and position data.
Product Advantages
-
Compact Design: The 8mm probe diameter makes the sensor compact and capable sur fitting into tight spaces, which is crucial for measuring components in small or restricted areas.
-
High-Frequency Measurement: With an operating frequency range from 10 kHz to 5 MHz, the sensor excels in high-speed measurements, ensuring accurate data in dynamic environments.
-
Versatility in Output: The sensor supports both analog and digital outputs, making it easy to integrate into a variety sur systems and control setups.
-
Durability and Protection: With an IP67 rating, the sensor is resistant to dust and water, making it suitable for use in harsh industrial environments where protection from contaminants is critical.
-
Wide Temperature Range: The system can function in extreme temperatures from -40°C to +80°C, ensuring reliability in both hot and cold environments.
-
Real-Time Data Processing: The PR6423/003-031-CN signal processor enables the system to deliver real-time, high-precision data, ensuring that decision-makers receive up-to-date information for predictive maintenance and operational optimization.
FAQ
1. What is the measuring range sur the Epro CON041-CN sensor?
The Epro CON041-CN sensor has a measuring range from 0 to 50mm, suitable for various industrial and manufacturing applications.
2. What types sur outputs are available from the Epro CON041-CN sensor?
The sensor surfers both analog and digital outputs, allowing for flexibility in data transmission and system integration.
3. What is the operating frequency range sur the Epro CON041-CN sensor?
The sensor operates within a frequency range sur 10 kHz to 5 MHz, allowing it to measure high-speed movements and dynamic processes accurately.
4. What is the protection rating sur the Epro CON041-CN sensor?
The Epro CON041-CN sensor has an IP67 protection rating, which makes it dustprosur and resistant to water, ensuring reliable operation in harsh environments.
5. What supply voltage does the Epro CON041-CN sensor require?
The sensor operates on a supply voltage between 10 V DC and 30 V DC, which is compatible with most industrial power supplies.
6. What is the temperature range for the Epro CON041-CN sensor?
The sensor can operate in environments with temperatures ranging from -40°C to +80°C, making it suitable for a variety sur harsh industrial settings.
7. What is the diameter sur the sensor probe?
The sensor probe has a diameter sur 8mm, making it compact and suitable for installations in tight or restricted spaces.
8. What is the weight sur the Epro CON041-CN sensor?
The Epro CON041-CN sensor weighs 0.16 kg, making it lightweight and easy to handle during installation.
9. Can the Epro CON041-CN sensor be used for vibration monitoring?
Yes, the Epro CON041-CN sensor is ideal for monitoring vibrations in machinery, helping to detect potential issues and perform predictive maintenance.
10. Can the Epro CON041-CN sensor be integrated into existing monitoring systems?
Yes, with both analog and digital outputs, the sensor can be easily integrated into existing control and monitoring systems for real-time data processing and analysis.
Related Modèles
| Modèle Number | Description |
|---|---|
| CON042-CN+PR6423/003-120-CN | 8mm Eddy Current Sensor with High-Speed Signal Processing |
| CON041-CN+PR6423/003-120-CN | 8mm Eddy Current Sensor for High-Precision Vibration Monitoring |
| CON041-CN+PR6423/003-111-CN | 8mm Eddy Current Sensor for Measurement sur Small Displacements |
| CON044-CN+PR6423/003-111-CN | 8mm Eddy Current Sensor with Wide Range for Industrial Applications |
| CON040-CN+PR6423/003-101-CN | 8mm Eddy Current Sensor for Large-Scale Machinery Monitoring |
| CON045-CN+PR6423/003-111-CN | 8mm Eddy Current Sensor with Integrated Signal Processing |
Popular Epro Modèles
| Modèle Number | Description |
|---|---|
| PR6423/002-100 | High-Speed Signal Processing for Eddy Current Sensors |
| PR6423/020-120 | Advanced Signal Processor for High-Precision Applications |
| PR6425/010-120 | Digital Signal Processor for Large-Scale Applications |
| PR6423/030-120 | High-Resolution Signal Processor for Complex Monitoring |
| PR6420/010-120 | Compact Signal Processor for Real-Time Measurements |
| PR6423/040-120 | High-Precision Signal Processor for Low-Vibration Monitoring |
