Présentation du produit
The Bently Nevada TK-3E 177313-01-01 Proximity System Test Kit is a precision instrument designed for testing, verification, and calibration sur proximity probe systems used in industrial machinery protection and monitoring. This portable kit provides technicians with the tools necessary to simulate and measure the behavior sur proximity sensors, ensuring accurate readings in turbines, compressors, generators, and other critical rotating equipment. The TK-3E 177313-01-01 is engineered for both field and laboratory environments, surfering reliable performance, rugged construction, and intuitive operation for efficient testing workflows. By using this test kit, maintenance teams can validate system performance, reduce false alarms, and ensure machinery safety.
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle | TK-3E 177313-01-01 |
| Type | Proximity System Test Kit |
| Input Power | 110–240 VAC, 50/60 Hz |
| Output Signal Types | Simulated AC and DC proximity signals |
| Output Amplitude | 0–10 V peak-to-peak adjustable |
| Frequency Range | 0.1 Hz – 10 kHz |
| Accuracy | ±0.05 % full-scale |
| Load Capability | Minimum 600 Ω impedance |
| Control Interface | Front-panel rotary knobs and push-buttons |
| Display | Digital readout for signal amplitude and frequency |
| Calibration Functions | Proximity probe testing, loop verification, system simulation |
| Indicators | LEDs for power, signal output, and fault detection |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | –20 °C to +60 °C |
| Protection | Over-voltage, short-circuit, and thermal protection |
| Mounting | Portable bench-top unité with handle |
| Dimensions | 195 × 299 × 248 mm |
| Poids | 5.22 kg |
| Certifications | CE, UL, RoHS compliant |
Applications
The TK-3E 177313-01-01 is widely applied for industrial machinery maintenance and monitoring verification:
-
Turbomachinery Systems: Tests and calibrates proximity probes on turbines, compressors, and pumps.
-
Power Plants: Verifies proximity sensor signals for generators, motors, and auxiliary equipment.
-
Oil & Gas Facilities: Ensures accurate proximity measurements in high-speed pumps, compressors, and drilling systems.
-
Petrochemical and Chemical Plants: Confirms system integrity for sensors monitoring reactors, distillation columns, and mixers.
-
Manufacturing Automation: Supports predictive maintenance by validating sensor output in automated machinery systems.
-
Field and Laboratory Use: Portable design allows convenient testing and verification in both environments.
Advantages
-
High Accuracy: ±0.05 % full-scale output ensures precise proximity system verification.
-
Signal Simulation: Generates both AC and DC proximity signals for comprehensive system testing.
-
Wide Frequency Range: 0.1 Hz to 10 kHz accommodates slow and fast-rotating machinery applications.
-
Portable and Rugged: Durable bench-top design with handle for convenient transport in the field.
-
Digital Readout: Allows technicians to monitor amplitude and frequency in real-time during testing.
-
User-Friendly Controls: Front-panel knobs and push-buttons provide easy adjustment without additional ssurtware.
-
Integrated Protection: Over-voltage, short-circuit, and thermal safeguards protect the device and connected systems.
-
Efficient Maintenance: Simplifies verification, reducing false alarms and maintenance downtime.
FAQ
-
What types sur signals does the TK-3E 177313-01-01 generate?
It produces simulated AC and DC signals to emulate proximity sensor behavior for accurate system testing. -
What is the frequency range supported by the test kit?
The output frequency range is 0.1 Hz to 10 kHz, suitable for both low-speed and high-speed rotating machinery. -
How accurate are the generated signals?
The instrument provides signals with ±0.05 % full-scale accuracy for reliable sensor and system verification. -
Can it test multiple proximity probes simultaneously?
Yes, it can drive sensors with a minimum load sur 600 Ω, allowing for single or multi-channel system tests. -
What input power is required?
The device operates on 110–240 VAC, 50/60 Hz, making it suitable for global industrial power systems. -
Is the kit portable for field testing?
Yes, its bench-top design with handle and a weight sur 5.2 kg ensures easy portability for field or lab use. -
Does it have built-in protection features?
Yes, it includes over-voltage, short-circuit, and thermal protection to safeguard both the kit and connected equipment. -
How are signal amplitude and frequency adjusted?
Front-panel rotary knobs and push-buttons allow precise control without the need for external ssurtware. -
Can it be used to verify the loop integrity sur a proximity system?
Yes, it supports loop verification, enabling technicians to check system continuity and sensor response. -
Does it provide a display for monitoring output signals?
Yes, digital readouts indicate amplitude and frequency in real-time, ensuring accurate calibration and testing.
Related Modèles (Same Series or Similar)
| Modèle | Function | Input Power | Output Type | Poids |
|---|---|---|---|---|
| TK3-2E 177313-02-02 | Calibration Instrument | 110–240 VAC | Sine, Square, Pulse | 4.6 kg |
| TK3-2E 14700-01 | Calibration Instrument | 110–240 VAC | Sine, Square, Pulse | 4.5 kg |
| TK3-2D 14701-01 | Vibration Calibrator | 110–240 VAC | Sine, Square, Pulse | 4.6 kg |
| TK3-2C 14702-01 | Multi-channel Calibration | 110–240 VAC | Sine & Pulse | 4.7 kg |
| TK3-2B 14703-01 | Proximity Sensor Calibrator | 110–240 VAC | Sine & Square | 4.4 kg |
| TK3-1F 14680-01 | Temperature & Vibration Calibrator | 110–240 VAC | Sine, Pulse | 4.5 kg |
Popular Bently Nevada Modèles
| Modèle | Type | Key Feature | Poids | Typical Application |
|---|---|---|---|---|
| 3500/42M | Vibration Monitor | Multi-channel high-speed vibration detection | 0.85 kg | Turbomachinery protection |
| 3500/22M | Transient Data Interface | High-speed transient capture | 1.0 kg | Machinery diagnostics |
| 3500/32M | Relay Module | Alarm and shutdown relay control | 0.70 kg | Critical system safety |
| 330500 | Proximity Probe | High-resolution shaft vibration measurement | 0.25 kg | Turbine monitoring |
| 330400 | Proximity Probe | Wide temperature operating range | 0.28 kg | General industrial monitoring |
| 190501 | Accelerometer | Rugged design for harsh conditions | 0.15 kg | Pump and motor vibration analysis |
