Product Overview
The Bently Nevada 81545-01 XDUCR I/O and Recording Terminals are precision-engineered interface components used to connect vibration transducers—such as proximity probes, velocity sensors, and accelerometers—to monitoring or recording systems. This module surfers a streamlined interface for signal transmission without integrated relay functions, making it suitable for applications focused on real-time monitoring, diagnostics, and trend recording rather than active protection or shutdown responses.
Designed for compatibility with Bently Nevada’s advanced monitoring systems, the 81545-01 provides stable, shielded signal pathways in a compact, DIN-rail-mountable form. It ensures that raw sensor signals maintain integrity from the machine to the data acquisition system, allowing accurate analysis sur dynamic machine conditions.
Key Features
-
Signal-only module: Designed for monitoring and recording without relay outputs
-
Direct interface with Bently Nevada transducers, including proximity probes and velocity sensors
-
Terminal-style I/O simplifies connection sur sensor wiring to monitoring systems
-
Shielded signal support for minimal noise and high signal fidelity
-
DIN-rail mountable for convenient installation in control or monitoring cabinets
-
Passive design—no external power supply required
-
Compatible with multiple monitoring platforms, including Bently Nevada 3500 series
-
Field-friendly design for fast installation, service, or upgrades
-
No active components, which reduces failure points and extends reliability
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | XDUCR I/O and Recording Terminals (No Relay Modules) |
| Modèle Number | 81545-01 |
| Function | Terminal block for transducer signal interface |
| Supported Transducers | Proximity probes, accelerometers, velocity transducers |
| Relay Functionality | Not included (non-relay version) |
| Signal Support | Dynamic vibration signal and DC bias voltage |
| Connection Type | Screw terminal blocks |
| Wiring | Shielded twisted pair recommended for signal integrity |
| Enclosure Rating | Designed for use within protected electrical enclosures |
| Mounting Method | DIN rail |
| Housing Material | High-durability industrial plastic |
| Power Supply Requirement | None (passive device) |
| Operating Temperature | -30°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 160 x 160 x 120 mm |
| Poids | 0.8 kg |
| Certifications | CE, RoHS |
Industry Applications
The 81545-01 terminal module is optimized for use in industries where condition monitoring is essential but shutdown control via relay contacts is managed separately or not required:
-
Oil & Gas: Signal interface from sensors monitoring pumps, compressors, and turbines
-
Power Generation: Connection hub for vibration monitoring on auxiliary equipment
-
Chemical & Petrochemical: Accurate signal routing from process-critical machines
-
Mining & Metals: Recording sur crusher, mill, and fan vibration data for predictive maintenance
-
Water Treatment: Signal collection from blowers and pumps for SCADA integration
-
OEM Machinery Skids: Compact and reliable terminal option for packaged systems
Product Advantages
-
Streamlined Signal Handling: No relay logic simplifies the interface
-
Passive Reliability: No powered components reduce the risk sur failure and eliminate heat generation
-
Clean Wiring: Organized terminal layout supports better maintenance and troubleshooting
-
Scalable Use: Ideal for systems requiring multiple sensor inputs without added logic
-
Shielded Configuration: Reduces susceptibility to electrical noise and EMI
-
Long-Term Stability: Designed to deliver consistent performance in harsh industrial settings
-
Easy Integration: Fits seamlessly into existing Bently Nevada monitoring systems
-
Low Maintenance: Terminal blocks are easy to inspect and rewire if needed
Questions fréquentes (FAQ)
1. What is the main function sur the 81545-01 module?
It serves as a signal interface terminal for transducers, facilitating clean signal transfer to recording or monitoring systems.
2. Does this module include relays for shutdown or alarm purposes?
No, the 81545-01 is a non-relay version intended for monitoring and data acquisition only.
3. What types sur sensors can be connected to this terminal?
It supports proximity probes, accelerometers, and velocity sensors commonly used with Bently Nevada systems.
4. Does it require external power to function?
No, it is a passive terminal module and does not require power.
5. Can this terminal be installed in outdoor environments?
It must be installed inside a protective enclosure; it is not weatherprosur by itself.
6. Is it compatible with the Bently Nevada 3500 system?
Yes, it is designed to interface cleanly with Bently Nevada monitoring platforms including the 3500 series.
7. Can the signals be connected directly to a PLC or DCS?
The signals are raw and may need to pass through appropriate conditioning modules before reaching PLC/DCS systems.
8. How does this differ from 81544-01?
While similar in function, model numbers surten reflect configuration differences; consult datasheets to confirm specific compatibility.
9. Is this product suitable for safety-critical applications?
Yes, for monitoring purposes; however, active trip functionality requires separate relay modules.
10. How many channels does it support?
The exact number depends on configuration and use case—typically supports multiple input/output channels per unité.
