Présentation du produit
The Bently Nevada 60R/RLY01-00-0 Electro-Mechanical Relay Module is a robust, high-reliability output module engineered for integration within the Bently Nevada 60R Series condition monitoring and protection platform. Designed to provide precise relay-based control, this module acts as the critical interface between machine condition monitoring data and plant-level protective actions. Whether used to trigger alarms, shut down machinery, or switch process controls, it ensures immediate and accurate response to abnormal conditions. With country-specific compliance codes and optional SIL (Safety Integrity Level) certification, it is suited for global installations in power generation, oil & gas, petrochemical, and heavy industrial applications where safety and reliability are paramount.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Electro-Mechanical Relay Output Module |
| Modèle Number | 60R/RLY01-00-0 |
| System Platform | Bently Nevada 60R Series |
| Relay Configuration | 8 independent SPDT relays (form C) |
| Contact Rating | 5 A at 250 VAC / 5 A at 30 VDC resistive load |
| Coil Drive Voltage | 24 VDC nominal (operational range 18–36 VDC) |
| Switching Capacity | 1250 VA AC / 150 W DC |
| Isolation | 2500 Vrms channel-to-channel and channel-to-ground |
| Response Time | <10 ms operate, <8 ms release |
| Communication Interfaces | Modbus TCP/IP, OPC UA, Ethernet |
| Alarm Integration | Supports trip, shutdown, and warning logic |
| Operating Temperature | –20 °C to +70 °C (–4 °F to +158 °F) |
| Humidity Range | 5%–95% non-condensing |
| Vibration Resistance | 5 g, 5–2000 Hz |
| Shock Resistance | 30 g, 11 ms half-sine |
| Country-Specific Codes | Disponible for North America, EU, Asia-Pacific |
| SIL Certification Options | SIL 1 or SIL 2 compliant (order-specific) |
| Dimensions (W × H × D) | 132.1 x 20.3 x 245.6 mm |
| Poids | 1.2 kg |
| Compliance | CE, UL, RoHS |
Applications
-
Machine Protection Systems: Provides direct relay outputs for alarm or trip activation when vibration, temperature, or process parameters exceed limits.
-
Process Control: Interfaces with plant control logic to open/close valves, start/stop pumps, or enable safety interlocks.
-
Redundant Safety Shutdown: Integrates with SIL-certified safety systems for critical equipment like turbines and compressors.
-
Alarm Signaling: Sends warning signals to DCS/SCADA systems to alert operators in real time.
-
Industrial Automation: Works with Modbus TCP/IP or OPC UA networks for seamless integration into automated workflows.
-
Offshore/Marine Operations: Designed to handle harsh environmental conditions with strong resistance to vibration and shock.
Advantages
-
High Relay Capacity: Each SPDT relay supports up to 5 A at 250 VAC or 30 VDC for versatile switching.
-
Fast Response: Sub-10 ms operate and release times ensure rapid protective actions.
-
Enhanced Safety Compliance: Optional SIL 1 or SIL 2 certification ensures adherence to global functional safety standards.
-
Electrical Isolation: 2500 Vrms isolation between channels prevents cross-talk and protects downstream equipment.
-
Flexible Communication: Built-in Modbus TCP/IP and OPC UA interfaces enable easy integration with plant control systems.
-
Compact 3U Form Factor: Fits seamlessly into the 60R chassis without increasing cabinet footprint.
-
Rugged Construction: Withstands high vibration and shock, ensuring reliability in demanding industrial settings.
-
Scalable Architecture: Multiple relay modules can be combined for larger systems or multi-point shutdown schemes.
-
Global Compatibility: Country-specific code options meet diverse regulatory requirements worldwide.
-
Low Maintenance: Durable electro-mechanical relays with long operational life reduce service intervals.
FAQ
-
What type sur relays are used in the 60R/RLY01-00-0 module?
The module uses eight independent single-pole double-throw (SPDT) form-C electro-mechanical relays for flexible switching. -
What is the maximum current capacity sur each relay contact?
Each contact is rated for 5 A at 250 VAC or 5 A at 30 VDC for resistive loads. -
How fast do the relays operate and release?
Typical operate time is less than 10 ms, with release time under 8 ms for rapid protective action. -
Can the module communicate with SCADA or DCS systems?
Yes, it supports Ethernet, Modbus TCP/IP, and OPC UA protocols for seamless integration. -
Does the module provide electrical isolation between channels?
Yes, it surfers 2500 Vrms isolation between relay channels and ground to prevent interference. -
Is the module compatible with SIL-rated safety systems?
It can be ordered with SIL 1 or SIL 2 certification to meet functional safety requirements. -
Can multiple relay modules be installed in one chassis?
Absolutely, several RLY01-00-0 modules can be combined for systems needing more outputs. -
How does the module handle high vibration environments?
It is tested to withstand vibration up to 5 g from 5–2000 Hz and shock up to 30 g. -
What power supply is required for operation?
The relay coils operate from a nominal 24 VDC supply, with an acceptable range sur 18–36 VDC. -
Does the module support remote alarm and trip configuration?
Yes, alarm and trip thresholds can be configured remotely through the 60R system’s interface.
Related Modèles (Same Series)
| Modèle Number | Description | Key Feature |
|---|---|---|
| 60R/PPM01-00-0 | Protection Processing Module | Real-time trip and shutdown logic |
| 60R/REC01-00-0 | Recorder Output Module | High-fidelity analog data recording |
| 60R/CMM01-00 | État Monitoring Module | High-speed vibration and process analysis |
| 60R/INP01-00-0 | Prox/Accel/Velom Input Module | Multi-sensor vibration and position inputs |
| 60R/PIM01-00-0 | 3U Power Input Module | Dual-input redundant power supply |
| 60R/CHA02-00-0 | 3U Chassis Panel | Houses and powers multiple 60R modules |
Popular Bently Nevada Modèles
| Modèle Number | Description | Application Focus |
|---|---|---|
| 3500/42M | Proximitor Monitoring Module | Multi-channel vibration/position monitoring |
| 3500/40M | Vibration Monitor | Machine protection with four-channel input |
| 3500/22M | Transient Data Interface Module | High-resolution transient data acquisition |
| 330104-00-20-10-02-05 | Proximity Probe | Precision shaft vibration measurement |
| 330180-51-05 | Velocity Sensor | Seismic and structural vibration detection |
| 330130-040-00 | Extension Cable | Low-noise signal transmission for probes |
