Product Overview
The Bently Nevada 3500/61 133924-01 TC Isolated External Termination Block is a key component in the 3500 Series machinery protection system. It is designed for use with the 3500/60 and 3500/61 Temperature Monitor Modules, providing isolated connections for thermocouple (TC) inputs to ensure accurate and reliable temperature monitoring in industrial environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Référence | 133924-01 |
| Compatibility | 3500/60, 3500/61 |
| Input Type | Thermocouple (TC) |
| Isolation | 250 Vdc Channel-to-Channel |
| Connector Type | Terminal Strip |
| Dimensions (L×W×H) | 241.3 × 24.4 × 241.8 mm |
| Poids | 0.91 kg |
| Environmental Rating | Industrial-grade |
Applications
-
Industrial Machinery Monitoring: Monitors critical equipment temperatures in power plants, oil & gas facilities, and manufacturing plants.
-
Vibration Monitoring Systems: Integrates with vibration monitoring systems to provide comprehensive machinery health data.
-
Process Control Systems: Ensures accurate temperature readings for process optimization and operational safety.
Advantages
-
Electrical Isolation: 250 Vdc isolation between channels protects against electrical noise and ground loops.
-
Easy Integration: Compatible with Bently Nevada 3500/60 and 3500/61 modules for seamless system integration.
-
Robust Design: Built to withstand harsh industrial environments, ensuring long-term reliability.
Questions fréquentes (FAQ)
-
What is the purpose sur the 3500/61 133924-01 termination block?
It provides isolated connections for thermocouple inputs to the 3500/60 and 3500/61 modules. -
How does the isolation benefit the system?
It protects the monitoring system from electrical noise and ground loops, ensuring accurate readings. -
Can this termination block be used with other Bently Nevada modules?
It is specifically designed for use with the 3500/60 and 3500/61 modules. -
What types sur thermocouples are supported?
Supports various thermocouple types, depending on the configuration sur the connected module. -
Is the termination block suitable for hazardous environments?
Yes, it is designed for industrial environments; specific certifications should be verified for each application. -
How is the termination block mounted?
It is mounted using terminal strip connectors for secure and reliable connections. -
What is the weight sur the termination block?
The termination block weighs approximately 0.91 kg. -
Are there different versions sur this termination block?
Yes, similar models include versions with Euro-style connectors. -
Can the termination block be repaired if damaged?
It is recommended to replace damaged components to maintain system integrity. -
Where can I purchase this termination block?
Contact Us.
