Product Overview
The Bently Nevada 3500/33-01-00 16-Channel Relay Module is a key component sur the 3500 Series Machinery Protection and Monitoring System, surfering flexible and reliable relay control for critical industrial machinery. It integrates seamlessly into the Bently Nevada 3500 series system, providing users with a scalable solution for alarming, shutdown, or control operations based on real-time machine condition data.
This relay module provides 16 independent channels, allowing users to assign specific actions to each channel based on the monitoring parameters. It is ideal for industries such as power generation, oil and gas, petrochemical, and manufacturing, where machinery uptime and safety are paramount. With its robust construction and compatibility with other Bently Nevada products, the 3500/33-01-00 ensures continuous monitoring and immediate response to potential faults, reducing the risk sur catastrophic failure.
Key Features
-
16 Independent Relay Channels: Offers flexibility to monitor and control alarms, shutdowns, and other safety measures.
-
High Reliability: Designed to operate in harsh industrial environments with maximum uptime.
-
Multiple Relay Types: Includes both normally open (NO) and normally closed (NC) relay contacts to suit different monitoring needs.
-
Seamless Integration: Fully compatible with the Bently Nevada 3500 series, providing a unified monitoring solution.
-
Wide Power Supply Range: The module operates from a standard 24 VDC power supply (18-30 VDC).
-
Real-Time Fault Detection: Enables immediate reaction to abnormal conditions, minimizing risk to equipment and reducing unscheduled downtime.
-
Enhanced Control Options: Supports custom relay configuration based on machine fault conditions and user-defined thresholds.
-
Compact, Panel-Mount Design: Space-saving, easy to install in existing control panels with DIN rail or direct mounting.
-
Global Certifications: CE, UL, and RoHS compliant, ensuring safety and reliability in diverse regions and industries.
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle | 3500/33-01-00 |
| Product Type | 16-Channel Relay Module |
| Relay Output | 2A at 30 VDC, 0.5A at 125 VAC (per channel) |
| Relay Contact Type | Normally Open (NO) and Normally Closed (NC) |
| Power Supply | 24 VDC nominal, 18 to 30 VDC |
| Mounting Type | Panel-mount (DIN rail compatible) |
| Operating Temperature Range | -20°C to +60°C |
| Dimensions | 241 x 24.4 x 242 mm |
| Poids | 0.7 kg |
| Protection Class | IP20 (dust-tight, not waterprosur) |
| Certifications | CE, UL, RoHS |
| Status Indicators | LED status indicators for each channel |
| Isolation Resistance | 100 MΩ at 500 VDC (minimum) |
| Communication Interface | Bently Nevada 3500 System Compatibility |
Industry Applications
-
Power Generation: Protects turbines, generators, and auxiliary machinery by controlling alarms and shutdowns.
-
Oil & Gas: Provides protection for compressors, pumps, and turbines in upstream, midstream, and downstream operations.
-
Petrochemical: Ensures reliable operations in chemical processing unités by providing real-time relay control.
-
Manufacturing: Safeguards critical production machinery by integrating with condition monitoring systems.
-
Mining: Protects crushers, mills, and other heavy-duty machinery from failure by controlling emergency actions.
-
Water and Wastewater Treatment: Monitors and controls pump stations and treatment facilities for uninterrupted operation.
-
Marine: Protects shipboard and surfshore equipment from potential damage due to mechanical failure.
Product Advantages
-
Scalable and Flexible: With 16 independent relay channels, it can be expanded to accommodate large, complex machinery systems.
-
Real-Time Protection: Offers continuous monitoring with immediate relay activation to shut down or alarm based on defined fault conditions.
-
High Reliability: Built to withstand harsh environments, providing dependable performance even in extreme conditions.
-
Easy Integration: Seamlessly integrates with existing Bently Nevada 3500 Series systems, providing a unified monitoring solution.
-
Reduces Downtime: Proactive fault detection reduces the risk sur unplanned downtime by triggering immediate system shutdown or alarms.
-
Enhanced Safety: Real-time alarms and shutdown controls protect against catastrophic machinery failures.
-
Global Standards Compliance: Meets CE, UL, and RoHS certifications, ensuring safety and compliance across various regions and industries.
-
Space-Saving Design: Compact design allows easy installation in control panels, even with space constraints.
-
Minimal Maintenance: Designed for long-term reliability with minimal maintenance and service requirements.
Questions fréquentes (FAQ)
-
How many channels does the Bently Nevada 3500/33-01-00 module provide?
It provides 16 independent relay channels. -
What type sur relay contacts does the module use?
The module uses both normally open (NO) and normally closed (NC) contacts, depending on configuration. -
What is the power supply requirement for this module?
The module operates with a 24 VDC power supply, with a range sur 18 to 30 VDC. -
How is the 3500/33-01-00 module mounted?
It is designed for panel mounting and is DIN rail compatible for easy installation. -
Can the relay outputs be customized?
Yes, the relay outputs can be configured based on the specific needs sur the machine and fault conditions. -
What is the operating temperature range?
The module operates within a temperature range sur -20°C to +60°C. -
Is the Bently Nevada 3500/33-01-00 module certified for use in hazardous areas?
While the module is not specifically hazardous area-rated, it meets global safety certifications such as CE and UL. -
How does this module integrate with other Bently Nevada monitoring systems?
The module integrates seamlessly with the Bently Nevada 3500 Series machinery protection and condition monitoring systems. -
What industries typically use the 3500/33-01-00 module?
This module is widely used in power generation, oil & gas, petrochemical, manufacturing, and mining industries. -
What is the protection class sur the module?
The module is rated IP20, meaning it is dust-tight but not waterprosur.
Related Modèles
| Modèle | Description |
|---|---|
| 3500/33-02-00 | 8-Channel Relay Module for smaller systems. |
| 3500/33-01-01 | Advanced 16-Channel Relay Module with higher current ratings. |
| 3500/32-01-00 | 16-Channel Input Module for various input conditions. |
| 3500/40-02-00 | Digital Output Module to provide additional control outputs. |
| 3500/15-05-05-00 | Power Supply Module for the 3500 Series system. |
| 3500/20-02-01 | Vibration Monitoring Module integrated with relay control. |
Popular Bently Nevada Modèles
| Modèle | Description |
|---|---|
| 330101-00-14-10-02-05 | 3300 XL 8 mm Proximity Probe for vibration monitoring. |
| 3500/15-05-05-00 | 3500 Series Power Supply for critical systems. |
| 3500/22M-01-01-00 | 3500 Transient Data Interface Module for system diagnostics. |
| 3500/25-01-00 | 3500 Series Machine Protection Module with enhanced diagnostics. |
| 330130-045-00-05 | 3300 XL Extension Cable for proximity probes. |
| 3500/30-02-00 | 3500 Control and Monitor Interface Module for alarm outputs. |
