Présentation du produit
The Bently Nevada 3500/22M 288055-02 TMR Transient Data Interface Module with USB Cable is an enhanced version sur the standard transient data interface unité, designed to integrate directly with Bently Nevada’s 3500 Series racks. Unique to this model is the inclusion sur a USB communication cable, which allows for quick, direct access to high-resolution transient vibration data without the need for additional interface modules.
This direct-connect function simplifies data retrieval during commissioning, maintenance, or diagnostics. Technicians can plug in a laptop via USB to extract event data, perform detailed analysis, or update firmware, bypassing the need to interface through the rack’s bus system. It streamlines troubleshooting and accelerates the decision-making process, making it especially valuable in time-sensitive industrial environments.
Equipped with rugged construction and calibrated for high-speed data capture, the 288055-02 TMR module ensures reliable operation in critical settings such as power stations, oil-and-gas facilities, and petrochemical plants. It empowers engineering teams to detect faults early and take corrective action before minor issues escalate.
Spécifications du produit
| Specification | Details |
|---|---|
| Modèle Number | 3500/22M 288055-02 TMR |
| Function | Transient Data Interface Module with USB access |
| USB Interface | USB‑A connector via USB cable (included) |
| System Compatibility | Bently Nevada 3500 Series |
| Input Signal | Transient vibration events |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 5 W |
| Connector Interfaces | Rack bus + USB diagnostic port |
| Dimensions (W × H × D) | 241.3 x 24.4 x 241.8 mm |
| Poids | 0.91 kg |
| Operating Temp. | –20 °C to +70 °C |
| Storage Temp. | –40 °C to +85 °C |
| Humidity | Up to 95 % non-condensing |
| Certifications | CE, UL, ATEX (when fitted in approved enclosure) |
Product Applications
This module enables transient data analysis in environments where quick access to event data is crucial:
-
Power Plants
On-site technicians can plug in laptops via USB to download event records from turbines and generators during routine checks. -
Oil & Gas Facilities
Used for rapid diagnostics on compressors and pump trains, especially in areas with limited access to control cabinets. -
Petrochemical Plants
Simplifies troubleshooting sur critical rotating equipment by enabling direct, hands-on data retrieval. -
Mining Operations
Field engineers can quickly analyze equipment vibration without returning to central control rooms. -
Marine & Offshore Platforms
Ideal for portable diagnostics in confined marine control panels where flexibility is required. -
Manufacturing Facilities
Supports maintenance teams with fast event data collection on production line machines.
Product Advantages
-
USB Access for Quick Diagnostics
Enables rapid data retrieval and firmware updates without the need for network connectivity. -
Early Fault Detection
Provides transient event capture to identify bearing wear, shaft rubs, or impacts before they escalate. -
System Compatibility
Fully integrates with Bently Nevada’s 3500-series rack architecture and analysis tools. -
Rugged, Field-Ready Design
Withstands industrial temperature ranges, humidity, and vibration. -
Plug-and-Play Installation
Standard form factor allows easy swap-in without control system downtime. -
Improved Maintenance Workflow
On-site data download capabilities reduce time-to-diagnosis and labor costs. -
Energy Efficient
Low power draw minimizes strain on system power budgets. -
Certified for Hazardous Locations
When mounted in certified enclosures, the module meets ATEX standards. -
User-Friendly Diagnostics
Technicians can perform data retrieval without network login or system integration. -
Enhanced Asset Availability
Speeds up fault analysis and helps prevent large-scale failures through early intervention.
Questions fréquentes (FAQ)
-
What makes the 288055-02 TMR different from other transient interface modules?
It includes a USB diagnostic port, enabling direct laptop connection without needing network access. -
Can any USB flash drive be used to download event data?
No — the module is designed to work with a diagnostic host (typically a laptop) using Bently’s ssurtware. -
Does USB access compromise system security?
The USB port is read-only for structured access via ssurtware; no backdoor is available for configuration. -
What firmware updates does the USB port support?
Firmware for the module itself and related components can be updated via the USB interface. -
Is this module hot-swappable in the rack?
Yes, it follows the standard 3500-series hot-swap protocol with minimal system disruption. -
What transient events does it capture?
The module captures short-duration impulses — like bearing defects, rubs, or mechanical collisions. -
Can I analyze data while connected via USB?
Yes, Bently’s Field Tool ssurtware allows real-time download and review sur event records. -
How many transient events can it store?
Storage depends on rack configuration, but the module handles transient buffers adequate for system diagnostics. -
How rugged is the USB cable included?
The USB cable is industrial-grade, with strain relief suitable for panel-mounted work environments. -
Does this module need a PC to function?
No — its USB port is optional for diagnostics. Operationally, it functions like a standard 3500/22M interface.
Related and Recommended Modèles
| Modèle Number | Description | Key Feature |
|---|---|---|
| 3500/22M 288055-01L | Standard Transient Data Interface without USB | Rack bus only interface |
| 3500/22M 288055-02 | Transient Interface with USB diagnostic interface | Alternative without TMR firmware |
| 3500/22-01-02-00 | Transient Interface with extended diagnostics | Standard module without USB port |
| 3500/20-01-01-00 | Proximitor Sensor Interface Module | For proximity sensor integration |
| 3500/25-01-00-00 | Speed/Phase Interface Module | Monitors rotational speed/phase |
| 3500/23-01-00-00 | Vibration Processing Module | On-board signal conditioning |
Popular Bently Nevada Modèles from the Same Marque
| Modèle Number | Description | Key Feature |
|---|---|---|
| 3500/05-01-05-00 | Central Monitor Rack Module | Power and communication core rack |
| 3500/15-01-00-00 | Power Supply Module | Redundant 24 V supply for 3500 system |
| 3500/42-01-00-00 | Proximitor Monitor | Displacement & position sensing |
| 3500/62-01-00-00 | Process Variable Module | Measures flow, pressure, temperature |
| 3300 XL Proximitor | Rugged Proximity Probe | Non-contact displacement measurement |
| 7200 Series | Legacy Monitoring System | Proven machine protection platform |
