Product Overview
The Bently Nevada 3500/05-01-01-01-00 system rack is a central component sur the 3500 machinery protection system, surfering structural support and interconnection for up to 14 monitoring and protection modules. Designed according to standard 19-inch rack specifications, this robust enclosure is constructed from industrial-grade materials to ensure durability and stability in high-demand environments such as oil refineries, gas compression stations, thermal power plants, and large-scale manufacturing facilities.
This model includes enhanced rear I/O accessibility, simplifying cable routing and serviceability in tight control room layouts. The integrated backplane allows secure and efficient signal and power distribution between modules. It is ideal for use in mission-critical monitoring systems where long-term system reliability, modularity, and minimal downtime are essential.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modèle | 3500/05-01-01-01-00 |
| Marque | Bently Nevada |
| Product Type | System Rack for Monitoring Modules |
| Rack Size | 19-inch (14 module slots) |
| Poids | 4.5 kg |
| Mounting Style | Standard 19-inch cabinet mounting |
| Material | Anodized aluminum with stainless steel hardware |
| Cooling Method | Passive convection (fanless design) |
| Backplane | Integrated power and signal backplane |
| Rear Access | Yes (model includes rear I/O accessibility) |
| Grounding | Built-in system grounding bus |
| Operating Temperature | -20°C to +60°C |
| Humidity Tolerance | 0%–95% RH (non-condensing) |
| Certifications | CE, UL, CSA (when configured as a complete system) |
Applications
The 3500/05-01-01-01-00 rack is purpose-built for high-reliability machinery condition monitoring applications in:
-
Oil & Gas Facilities
Continuous vibration and proximity monitoring for pumps, compressors, and turbines. -
Power Generation Plants
Integration with protection modules for gas, steam, and hydro turbines. -
Petrochemical Refineries
Used in hazardous zones to ensure operational uptime sur rotating assets. -
Manufacturing Lines
Supports real-time diagnostics sur motors, fans, and gear systems. -
Water and Wastewater Treatment
Deployed with sensors and modules to monitor flow machines and mechanical drives. -
Steel and Mining Industries
Monitors conveyors, crushers, and rotating plant machinery to avoid costly failures.
Advantages
-
Rear I/O Accessibility
Simplifies wiring, troubleshooting, and expansion by allowing cable connections from the back. -
Scalable Design
Accommodates up to 14 modules, enabling system expansion based on plant needs. -
Tool-Free Module Insertion
Plug-and-play module installation and removal minimize service downtime. -
Rugged Construction
Withstands vibration, high temperatures, and harsh industrial conditions. -
Passive Cooling
Fanless design ensures quiet operation and long-term reliability. -
Centralized Grounding System
Enhances signal integrity and system safety. -
Standardized Dimensions
Compatible with standard 19-inch enclosures and cabinets, simplifying infrastructure planning.
Questions fréquentes (FAQ)
Q1: How many modules can this rack support?
A1: It can support up to 14 monitoring and protection modules.
Q2: What does “rear I/O access” mean in this model?
A2: It allows input/output cables to be connected from the back sur the rack, improving cable management.
Q3: Can this rack be used with any 3500 module?
A3: Yes, it is fully compatible with all standard Bently Nevada 3500 modules.
Q4: Does the rack include its own cooling system?
A4: It relies on passive ventilation and does not include active fans.
Q5: Is this rack suitable for hazardous environments?
A5: Yes, when used with appropriate modules, it complies with industrial safety standards.
Q6: What is the weight sur the rack?
A6: The rack weighs approximately 4.5 kg.
Q7: Can this rack be mounted in a standard control cabinet?
A7: Yes, it is designed for standard 19-inch rack cabinets.
Q8: What materials are used for its construction?
A8: It is constructed from anodized aluminum and stainless steel for corrosion resistance.
Q9: Does the rack include a built-in grounding bus?
A9: Yes, grounding is integrated into the rack structure.
Q10: What certifications does it support?
A10: CE, UL, and CSA certifications are applicable when configured as part sur a complete 3500 system.
Related Modèles (Same Series)
| Modèle | Description | Function | Poids | Rack Size |
|---|---|---|---|---|
| 3500/05-01-01-00-00 | Base rack, front I/O access only | Standard monitoring rack | 4.5 kg | 19-inch (14 slots) |
| 3500/05-02-01-00-00 | Rack with redundant TDI slots | Redundant system support | 4.8 kg | 19-inch |
| 3500/05-03-01-00-00 | High-temperature variant | Harsh environment compatibility | 4.9 kg | 19-inch |
| 3500/05-01-02-01-00 | Rack with dual rear I/O and TDI | Enhanced diagnostics access | 5.1 kg | 19-inch |
| 3500/05-04-01-00-00 | Field enclosure-ready rack | Ruggedized for outdoor applications | 6.0 kg | 19-inch |
| 3500/05-01-01-01-01 | Rear access + enhanced EMI shielding | Noise-sensitive application support | 4.6 kg | 19-inch |
Popular Bently Nevada Modèles (Same Marque)
| Modèle | Description | Dimensions (mm) |
|---|---|---|
| 3500/05-01-02-01-00-00 | 3500 Series System Rack, 19-inch, with standard backplane | 483 x 266 x 249 |
| 3500/05-01-02-01-00-01 | 3500 Rack, same as above with additional ID label or revision marking | 483 x 266 x 249 |
| 3500/05-01-03-00-00-00 | 3500 Rack, enhanced airflow and mounting design | 483 x 266 x 249 |
| 3500/05-01-02-00-00-00 | 3500 Rack, basic configuration, standard power setup | 483 x 266 x 249 |
| 3500/05-01-03-01-00-00 | 3500 Rack, high-reliability model with reinforced housing | 483 x 266 x 249 |
| 3500/05-01-03-01-00-01 | 3500 Rack, same as above with factory customization (revision 01) | 483 x 266 x 249 |
