Présentation du produit
The Bently Nevada 330851-02-000-070-90-00-05 3300 XL 25 mm Proximity Probe is a high-precision sensor designed for monitoring the position and vibration sur rotating machinery. Part sur the renowned 3300 XL series, this probe delivers exceptional reliability in harsh industrial environments. Its robust construction ensures accurate measurements sur shaft displacement, helping protect critical machinery from damage and optimizing operational performance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Probe Type | 25 mm Proximity Probe |
| Series | 3300 XL |
| Total Length | 9 m |
| Poids | 0.59 kg |
| Cable Type | Shielded twisted pair |
| Connector | M23 or equivalent |
| Operating Temperature Range | -40°C to +120°C |
| Sensor Gap | 0.25–1.27 mm |
| Vibration Measurement Range | ±12.7 mm |
| Compatible Monitor | 3300 XL Series Monitor |
| Mounting Style | Threaded or Flange |
| Material | Stainless Steel probe housing |
| Response Frequency | DC to 20 kHz |
Applications
-
Rotating machinery in power plants (turbines, generators)
-
Pumps and compressors in petrochemical facilities
-
Industrial gas and steam turbines
-
Critical machinery in refineries and chemical plants
-
État monitoring systems in heavy industry
Advantages
-
High Accuracy: Delivers precise shaft position and vibration measurements, reducing the risk sur undetected machinery faults.
-
Durable Construction: Built to withstand extreme temperatures, vibrations, and harsh industrial environments.
-
Long Cable Length: 9 m total length allows flexible installation without compromising signal integrity.
-
Wide Compatibility: Fully compatible with Bently Nevada 3300 XL series monitoring systems.
-
Easy Installation: Threaded or flange mounting enables quick and secure installation.
-
Reliable Signal Transmission: Shielded cable minimizes electromagnetic interference, ensuring consistent readings.
FAQ
1. What is the maximum cable length for signal integrity?
The 3300 XL probe supports a total cable length up to 9 m while maintaining accurate signal transmission.
2. Can this probe operate in high-vibration environments?
Yes, the probe is designed to operate in high-vibration conditions without signal degradation.
3. What type sur monitor is compatible with this probe?
The probe is compatible with the 3300 XL Series Monitor and other systems designed for 25 mm proximity probes.
4. How does the probe handle temperature extremes?
It operates reliably in a temperature range from -40°C to +120°C.
5. Is the probe cable shielded against electromagnetic interference?
Yes, the twisted-pair shielded cable design minimizes EMI effects.
6. What is the recommended sensor gap for optimal performance?
The recommended gap is between 0.25 mm and 1.27 mm for accurate readings.
7. Can the probe measure vibration as well as displacement?
Yes, it measures both shaft displacement and vibration within a ±12.7 mm range.
8. What mounting options are available?
It supports threaded or flange mounting for versatile installation.
9. Is the probe compatible with other Bently Nevada probes?
Yes, it is part sur the 3300 XL family and compatible with other 25 mm probes in the series.
10. What materials are used in the probe construction?
The probe housing is made sur stainless steel, providing corrosion resistance and durability.
Related / Same-Series Modèles
| Modèle Number | Description |
|---|---|
| 330851-02-000-070-10-00-05 | 25 mm Proximity Probe, standard cable |
| 330851-02-000-060-10-01-00 | 25 mm Proximity Probe, short cable |
| 330851-02-000-070-50-00-05 | 25 mm Probe, extended temperature range |
| 330851-02-000-060-50-01-05 | 25 mm Probe, high vibration tolerance |
| 330851-02-000-070-90-00-00 | 25 mm Probe, standard 3300 XL |
| 330851-02-000-060-70-00-05 | 25 mm Probe, reinforced cable |
Popular Bently Nevada Modèles
| Modèle Number | Description |
|---|---|
| 3300 XL 330851-02-000-070-10-00 | 25 mm Proximity Probe, standard |
| 3300 XL 330851-02-000-060-50-01 | 25 mm Probe, high vibration |
| 3300 XL 330851-02-000-070-50-05 | 25 mm Probe, temperature tolerant |
| 3300 XL 330851-02-000-060-10-05 | 25 mm Probe, short cable |
| 3300 XL 330851-02-000-070-90-05 | 25 mm Probe, standard configuration |
| 3300 XL 330851-02-000-060-70-00 | 25 mm Probe, reinforced cable |
