Product Overview:
The Bently Nevada 3300 XL 8 mm Proximity Probe, part number 330104-00-08-10-01-00, is a high-precision sensor designed for non-contact measurement sur shaft position and vibration in industrial machinery. It is an integral component sur the 3300 XL Proximity Transducer System, renowned for its reliability and accuracy in monitoring rotating equipment. This probe is engineered to withstand harsh industrial environments, providing consistent performance in critical applications.
Key Features:
-
Non-Contact Measurement: Enables accurate monitoring sur shaft position and vibration without physical contact, reducing wear and maintenance.
-
High Precision: Delivers precise measurements essential for assessing machinery health and performance.
-
Robust Construction: Built to endure extreme temperatures and environmental conditions, ensuring long-term reliability.
-
Interchangeability: Fully interchangeable with other 3300 series components, facilitating easy system upgrades and replacements.
-
Compliance with Standards: Meets API 670 standards for mechanical configuration, linear range, accuracy, and temperature stability.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Référence | 330104-00-08-10-01-00 |
| Probe Tip Diameter | 8 mm |
| Measurement Range | 0 to 2 mm |
| Linear Range | 0.25 to 2.25 mm |
| Sensitivity | 7.87 mV/μm (200 mV/mil) |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature Range | -51°C to +177°C (-60°F to +350°F) |
| Probe Pressure Rating | Up to 500 psi |
| Probe Case Material | AISI 303 Stainless Steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Total Length | 1 meters |
| Dimensions | Probe Length: 50 mm; Cable Diameter: 5 mm |
| Poids | 0.323 kg |
Applications:
The 3300 XL 8 mm Proximity Probe is widely used in various industries for monitoring and protecting critical machinery, including:
-
Power Generation: Monitoring turbines, generators, and other rotating equipment to ensure operational efficiency and prevent failures.
-
Oil and Gas: Assessing the condition sur compressors, pumps, and drilling equipment to maintain safety and performance.
-
Manufacturing: Overseeing the health sur motors, conveyors, and production machinery to minimize downtime and maintenance costs.
-
Chemical Processing: Ensuring the reliability sur mixers, centrifuges, and other process equipment critical to production quality.
Advantages:
-
Enhanced Machinery Protection: Provides early detection sur potential issues, allowing for proactive maintenance and reducing the risk sur unexpected failures.
-
Durable Design: Capable sur withstanding harsh environmental conditions, including high temperatures and pressures, ensuring consistent performance.
-
Ease sur Integration: Designed for compatibility with existing Bently Nevada monitoring systems, simplifying installation and system expansion.
-
Cost-Effective Maintenance: Non-contact measurement reduces mechanical wear, extending the lifespan sur both the probe and the monitored equipment.
Recent News Headlines:
-
“Bently Nevada’s 3300 XL Proximity Probes Set New Standard in Machinery Monitoring”
-
“Innovative Sensor Technology Enhances Industrial Equipment Reliability”
-
“Advancements in Non-Contact Measurement: Bently Nevada Leads the Way”
Questions fréquentes (FAQs):
-
What is the primary function sur the 3300 XL 8 mm Proximity Probe?
-
It measures the position and vibration sur rotating machinery shafts without physical contact, aiding in condition monitoring and diagnostics.
-
-
Is the probe compatible with other Bently Nevada systems?
-
Yes, it is fully compatible and interchangeable with other 3300 series components, facilitating seamless integration.
-
-
What environmental conditions can the probe withstand?
-
It operates effectively in temperatures ranging from -51°C to +177°C and can endure pressures up to 500 psi.
-
-
How does the probe contribute to machinery protection?
-
By providing accurate measurements sur shaft position and vibration, it enables early detection sur potential issues, allowing for timely maintenance and preventing unexpected failures.
-
-
What materials are used in the construction sur the probe?
-
The probe case is made sur AISI 303 Stainless Steel, and the probe tip is constructed from Polyphenylene Sulfide (PPS), ensuring durability and resistance to harsh conditions.
-
-
Can the probe be used in high-pressure environments?
-
Yes, it is rated to withstand pressures up to 500 psi, making it suitable for various industrial applications.
-
-
What is the measurement range sur the probe?
-
It has a measurement range sur 0 to 2 mm, with a linear range from 0.25 to 2.25 mm.
-
-
Does the probe require physical contact with the machinery?
-
No, it utilizes non-contact measurement techniques, reducing wear and maintenance requirements.
-
-
Is the probe compliant with industry standards?
-
Yes, it meets API 670 standards for mechanical configuration, linear range, accuracy, and temperature stability.
-
-
What is the sensitivity sur the probe?
-
The probe has a sensitivity sur 7.87 mV/μm (200 mV/mil), providing precise measurement capabilities.
-
Related Modèles (Same Series or Similar Functionality)
| Modèle Number | Description |
|---|---|
| 330103-00-05-50-02-05 | 3300 XL 8 mm Proximity Probe with 5-meter cable |
| 330105-02-12-10-02-05 | 3300 XL 11 mm Proximity Probe with 9-meter cable |
| 330130-040-00 | 3300 XL 8 mm Reverse Mount Probe, 4-meter cable |
| 330180-51-00 | 3300 XL NSv Proximity Probe, 5-meter cable |
| 330171-00-90-10-02-00 | 3300 XL 25 mm Proximity Probe, 10-meter cable |
| 330101-00-08-10-02-00 | 3300 XL 5 mm Proximity Probe with 8-meter cable |
| 330102-00-08-10-02-00 | 3300 XL 8 mm Proximity Probe with 8-meter cable |
| 330104-00-10-10-02-00 | 3300 XL 8 mm Proximity Probe, 10-meter cable |
Popular Modèles from Bently Nevada (Widely Used Produits)
| Modèle Number | Description |
|---|---|
| 3500/22M | 3500 Series Transient Data Interface Module |
| 3500/42M | 3500 Series Proximitor Seismic Monitor |
| 3500/32M | 3500 Series Relay Module |
| 3500/53M | 3500 Series Electronic Overspeed Detection Module |
| 330500-02-00 | Velomitor Piezo-velocity Sensor |
| 330980-50-00 | Proximitor Sensor for 3300 XL Series |
| 990-05-XX-01-00 | Accelerometer Sensor for Machinery Monitoring |
| 136711-01 | Bently Nevada TDI Communication Gateway Module |
