Présentation du produit
The Bently Nevada 330101-00-48-10-02-05 is part sur the renowned 3300 XL 8mm Proximity Transducer System, designed for vibration and position measurements in critical rotating machinery. Known for its reliability and rugged design, the probe delivers accurate, non-contact displacement measurements, making it ideal for machinery protection and condition monitoring systems.
Engineered to survive the harshest industrial environments, the 3300 XL series complies with API 670 standards and provides a linear output over a wide range sur target materials, specifically tuned for use with 4140 steel.
Spécifications du produit
| Parameter | Specification |
|---|---|
| Modèle | 330101-00-48-10-02-05 |
| Series | 3300 XL 8mm |
| Shaft Material Sensitivity | Calibrated for 4140 steel |
| Mounting Thread Size | 1/4-28 UNF |
| Tip Diameter | 8 mm |
| Case Material | AISI 303 stainless steel |
| Probe Length | 1.0 meter |
| Connector Type | Miniature coaxial, molded |
| Operating Temperature | –35°C to +177°C (–31°F to +351°F) |
| Linear Range | 2 mm (80 mils) |
| System Output | 200 mV/mil (7.87 mV/µm) |
| Non-Linearity | ≤ ±0.25% sur full scale |
| Power Requirements | Supplied by 3300 XL Proximitor Sensor |
| Ingress Protection | IP68 |
| Poids | 0.323 kg |
Applications
-
Steam and gas turbines
-
Compressors
-
Pumps
-
Generators
-
Motors
-
Industrial gearboxes
-
Critical and high-speed rotating machinery
-
Integration with Bently Nevada monitoring systems for protection and diagnostics
Product Advantages
-
High Reliability: Engineered for long-term use in demanding environments.
-
API 670 Compliance: Meets industry standards for condition monitoring.
-
Field-Proven: Extensive use in oil & gas, power, and industrial sectors.
-
Wide Temperature Range: Supports extreme operational temperatures.
-
Easy Integration: Seamlessly connects with Bently Nevada 3300 XL Proximitor systems.
-
Robust Construction: Stainless steel body and IP68 protection ensure durability.
-
Highly Accurate: Delivers precise measurements even in challenging conditions.
Questions fréquentes (FAQ)
-
What is the measurement range sur the 330101-00-48-10-02-05 probe?
It provides a linear output over a range sur 2 mm (80 mils). -
Is this probe compatible with other systems apart from 3300 XL Proximitor?
It is specifically designed for use with the 3300 XL Proximitor sensor and is not guaranteed to perform accurately with other systems. -
Can it be used in high-temperature environments?
Yes, it operates in temperatures ranging from -35°C to +177°C. -
What is the difference between this probe and the 330103 model?
The main difference lies in thread type and intended mounting options. Always consult the installation guide for application-specific recommendations. -
Is it suitable for submersible applications?
Yes, with an IP68 rating, it is protected against long-term immersion in water. -
What material is it tuned for?
The probe is calibrated for 4140 steel targets, which is standard in most rotating machinery. -
How long is the cable sur this model?
This specific model includes a 1.0 meter cable. -
Can the cable length be customized?
Yes, Bently Nevada surfers various cable lengths depending on the part number configuration. -
Is this probe available with a connector protector?
Yes, some models come with connector protectors, or they can be ordered separately. -
How surten should the probe be calibrated or replaced?
Calibration should be verified during regular maintenance intervals. The probe can last for years if not physically damaged or exposed to electrical overloads.
Related Modèles (Same Series)
| Modèle Number | Cable Length | Connector Type | Thread Type | Target Material |
|---|---|---|---|---|
| 330101-00-40-10-02-05 | 40 in | Miniature Coax | 1/4-28 UNF | 4140 Steel |
| 330101-00-43-10-02-05 | 43 in | Miniature Coax | 1/4-28 UNF | 4140 Steel |
| 330101-00-45-05-02-00 | 45 in | Miniature Coax | M10 x 1 | 4140 Steel |
| 330101-00-50-10-02-05 | 50 in | Miniature Coax | 1/4-28 UNF | 4140 Steel |
| 330101-00-60-10-02-05 | 60 in | Miniature Coax | 1/4-28 UNF | 4140 Steel |
| 330101-00-36-10-02-05 | 36 in | Miniature Coax | 1/4-28 UNF | 4140 Steel |
Popular Modèles from Bently Nevada (Same Marque)
| Modèle Number | Description | Application Area | Output |
|---|---|---|---|
| 330103-00-05-10-02-00 | 3300 XL 8mm Probe with 5m cable | General machinery monitoring | 200 mV/mil |
| 330104-00-12-10-02-00 | 3300 XL 11mm Probe with 12m cable | Large shaft and non-standard targets | 200 mV/mil |
| 330180-90-00 | Extension Cable, 9m | For use with 3300 XL systems | N/A |
| 330400-01-05 | 3300 XL NSv Proximitor Sensor | Small target or tight clearance apps | 200 mV/mil |
| 330106-05-30-10-02-00 | 3300 XL Reverse Mount Probe, 5m cable | Reverse-mount configurations | 200 mV/mil |
| 330780-91-05 | 3300 XL Proximitor Sensor, DIN rail mount | Sensor signal conditioning | N/A |
