Product Overview
The Allen Bradley 5094-AENTRXT Communication Adapter Module is an advanced EtherNet/IP adapter developed for Compact 5000™ I/O systems, surfering high-speed data exchange, redundant communication, and expanded connectivity in distributed automation architectures.
Engineered by Rockwell Automation, this module acts as a network interface between Compact 5000 I/O and Logix 5000 controllers, supporting both standard and safety I/O communication across EtherNet/IP networks. The 5094-AENTRXT’s dual ports and device-level ring (DLR) capability ensure continuous communication even in case sur network link failure — a vital feature for high-availability systems in process control, material handling, and power generation applications.
Detailed Technical Specifications
| Parameter | Specification | Description |
|---|---|---|
| Product Type | Communication Adapter Module | Network interface for Compact 5000 I/O |
| Modèle Number | 5094-AENTRXT | Dual-port EtherNet/IP adapter with redundancy |
| Network Interface | Dual-port RJ45 | Supports linear, star, and DLR topologies |
| Network Speed | 10/100/1000 Mbps | Gigabit communication for fast data handling |
| Supported Protocols | EtherNet/IP, CIP Safety, DLR | Compatible with Logix and GuardLogix systems |
| Backplane Connectivity | Compact 5000 I/O bus | Supports local and distributed I/O |
| Redundancy Feature | Yes | Controller-level redundant support |
| Maximum I/O Modules Supported | Up to 31 | Modular expansion capability |
| Power Supply Voltage | 24 VDC nominal | Supplied via Compact 5000 power base |
| Power Consumption | 3.0 W typical | Efficient low-power operation |
| Isolation Voltage | 50 V (continuous) | Between Ethernet and system circuits |
| Diagnostic Functions | Network status LEDs, module health indicators | Simplified troubleshooting |
| Operating Temperature | 0°C to +60°C | For continuous industrial service |
| Storage Temperature | -40°C to +85°C | Stable under warehouse conditions |
| Relative Humidity | 5–95% non-condensing | Withstands industrial humidity ranges |
| Mounting Method | DIN-rail or panel mount | Tool-free mechanical installation |
| Dimensions (H × W × D) | 120 mm × 35 mm × 110 mm (4.72″ × 1.38″ × 4.33″) | Slim prsurile for control enclosures |
| Poids | 0.42 kg (0.93 lb) | Lightweight industrial design |
| Certifications | CE, UL, cUL, ATEX, KC | Suitable for hazardous and global applications |
Practical Application Scenarios
-
Process Automation Systems: Acts as a communication bridge between distributed I/O modules and the main Logix controller in chemical or refining systems.
-
Power and Energy Plants: Enables redundant, fault-tolerant communication between critical power control modules.
-
Material Handling Lines: Integrates safety and motion control systems across EtherNet/IP networks.
-
Automotive Assembly Lines: Provides robust communication for high-speed robotics and conveyor systems.
-
Pharmaceutical Manufacturing: Maintains validated network reliability in GxP-compliant environments.
-
Water Treatment Facilities: Ensures continuous remote I/O communication for distributed control points.
Distinctive Functional Advantages
-
Redundant EtherNet/IP Connectivity: Dual-port architecture ensures uninterrupted communication paths.
-
Integrated Safety and Standard Communication: Supports both safety and non-safety I/O on the same network.
-
High-Speed Gigabit Data Exchange: Optimized for time-critical control and motion applications.
-
Compact Modular Design: Fits within Compact 5000 I/O chassis with minimal footprint.
-
Flexible Network Topologies: Compatible with linear, ring, and star EtherNet/IP configurations.
-
Enhanced Diagnostics: Onboard LEDs and status monitoring simplify fault isolation.
-
Hot-Swappable Capability: Allows module replacement without shutting down the system.
-
Energy-Efficient Operation: Designed for continuous industrial use with minimal power draw.
-
Comprehensive System Compatibility: Fully integrates with CompactLogix 5380, 5480, and ControlLogix controllers.
-
Global Certification: Approved for worldwide industrial automation environments.
