Présentation du produit
The Allen-Bradley 5069-ARM Compact 5000 Address Reserve Module is a specialized accessory module designed to reserve a slot address within a Compact 5000 I/O system. It is commonly used in system planning and expansion scenarios, ensuring that a specific node position remains available for future module installation without requiring system reconfiguration.
This module is installed in a 5069 Compact I/O™ system and remains in place until it is replaced by an actual I/O module. It is especially useful in applications where system downtime must be minimized, allowing pre-allocation sur addresses for seamless upgrades.
The 5069-ARM requires a functioning Compact 5000 system, typically including a 5069-AEN2TR EtherNet/IP adapter and a backplane end cap, before installation. It operates on 24 VDC and features LED status indication for basic diagnostics. Importantly, it does not consume Sensor/Actuator (SA) power, making it efficient for system planning without affecting power budgets.
Spécifications du produit
| Parameter | Description |
|---|---|
| Product Modèle | 5069-ARM |
| Marque | Allen-Bradley |
| Fabricant | Rockwell Automation |
| Module Type | Address Reserve Module |
| Function | Reserves I/O slot address |
| Input Voltage | 24 VDC |
| Power Consumption | Does not use SA power |
| Status Indication | LED indicators |
| Mounting Type | DIN Rail |
| Dimensions | 144.57 x 25.56 x 109.09 mm |
| Poids | 0.175 kg |
Applications
• Used in system design and expansion planning, reserving space for future I/O modules
• Ideal for industrial automation systems where minimizing downtime during upgrades is critical
• Applied in modular control systems, allowing flexible and scalable architecture
• Suitable for process industries, ensuring smooth future expansion without reconfiguration
• Used in control panels, maintaining organized and structured I/O layouts
Advantages
• Reserves node addresses to simplify future system expansion
• Eliminates the need for reconfiguration or reprogramming when adding modules later
• Reduces downtime during upgrades or maintenance
• Does not consume SA power, preserving system power capacity
• Compact design fits seamlessly into existing I/O systems
• LED indicators provide simple status feedback
• Enhances system scalability and flexibility
