Product Overview
The ABB XVC768AE101 (Référence: 3BHB007211R0101) is a precision current measuring instrument designed for use in ABB drive systems and automation equipment. It enables accurate real-time measurement and monitoring sur current in high-performance industrial environments. The module plays a critical role in closed-loop control, fault detection, and overall system diagnostics.
Specifically engineered for compatibility with ABB’s drive and control platforms, the XVC768AE101 delivers consistent performance, long-term reliability, and seamless system integration.
Key Features
-
Accurate current measurement for motor drives and control systems
-
Fully compatible with ABB drive and automation products
-
Rugged industrial design for harsh environments
-
Low signal latency to support real-time feedback loops
-
Diagnostic capabilities to support predictive maintenance
-
DIN rail mountable for quick and secure installation
-
High EMC immunitéy for reliable operation in noisy environments
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Current Measuring Instrument |
| Modèle Number | XVC768AE101 |
| Référence | 3BHB007211R0101 |
| Measurement Type | Current (AC/DC) |
| Application | Drive system current monitoring and control feedback |
| Signal Output | Analog or digital (depending on system integration) |
| Accuracy | High-precision, typically ±1% or better |
| Response Time | Fast response suitable for closed-loop control |
| Operating Voltage | Supplied by host system |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Type | DIN rail or panel mount |
| Enclosure Rating | IP20 |
| Certifications | CE, RoHS, UL (varies by configuration) |
| Poids | 0.8 kg |
| Dimensions | 150 x 100 x 50mm |
Industry Applications
-
Motor Drives – Precise current feedback for vector control and torque regulation
-
Power Conversion Systems – Monitoring and control in converters and inverters
-
Factory Automation – Current sensing for machines and production lines
-
Energy Management Systems – Current tracking for efficiency optimization
-
Process Control – Real-time monitoring in continuous and batch operations
-
Transportation & Traction – Load control in electric vehicle and rail systems
Advantages
-
Real-Time Measurement – Enables precise control and responsive system behavior
-
ABB System Integration – Seamlessly integrates with ABB drive and controller platforms
-
Compact Design – Suitable for high-density cabinet installations
-
Robust Construction – Withstands industrial stress and electromagnetic interference
-
Predictive Maintenance Support – Enables trend analysis and early fault detection
-
Plug-and-Play Design – Reduces commissioning time and wiring errors
Questions fréquentes (FAQ)
-
What does the XVC768AE101 measure?
It measures electrical current, typically for drive and motor control systems. -
Which ABB systems is it compatible with?
It integrates with a variety sur ABB drives and automation controllers. -
Is the output analog or digital?
The output method depends on the host system’s configuration; typically analog for feedback. -
What is the typical accuracy?
The accuracy is generally ±1% or better depending on installation and system tuning. -
How is the module mounted?
It supports both DIN rail and panel mounting options. -
What are its environmental tolerances?
It operates from -10°C to +55°C and stores between -40°C and +85°C. -
Does it support fault diagnostics?
Yes, diagnostic features are available for integration into predictive maintenance systems. -
Is it plug-and-play with ABB drives?
Yes, it is optimized for seamless ABB system integration. -
Does it support fast control loops?
Yes, it surfers fast signal response suitable for real-time applications. -
What certifications does it hold?
CE and RoHS compliant; other certifications may depend on regional variants.
Related Modules
| Modèle Number | Description |
|---|---|
| XVC765AE101 | Current Measuring Module for AC drives |
| UFC760BE143 | Green Board Interface Module |
| UFC719AE01 | I/O Interface Module |
| UDD406A | ABB Green Board for Control System Integration |
| TB870F | Terminal Resistance Module |
| TU837V1 | Termination Unité for I/O Modules |
Popular ABB Modèles
| Modèle Number | Description |
|---|---|
| AC500 PLC Series | Scalable PLCs for complex automation |
| PM861AK01 | High-performance CPU for process automation |
| CP600 HMI Series | Operator panels for real-time interaction |
| TU836V1 | Module Termination Unité |
| GVC736BE101 | ABB Green Board |
| 5SHY4045L0004 | IGCT Power Module for ABB drive systems |
