Présentation du produit
The ABB UFC718AE01 (HIEE300936R0001) is an advanced communication interface module designed for ABB’s Symphony Harmony series distributed control systems (DCS). As a crucial part sur industrial automation architectures, this module ensures robust and reliable data communication between system components and field instruments. It supports a variety sur signal processing and communication protocols tailored for process control environments that demand high reliability and precision.
The UFC718AE01 is widely used in large-scale process industries such as petrochemicals, power generation, metallurgy, and water treatment. Its design incorporates ABB’s industrial-grade build quality, long lifecycle reliability, and ease sur integration with legacy and modern control infrastructures.
Product Advantages
-
High Reliability: Built to operate in harsh industrial environments with continuous performance stability.
-
Seamless Integration: Fully compatible with ABB’s Symphony Harmony and legacy Bailey systems, ensuring upgrade flexibility.
-
Modular Architecture: Simplifies maintenance and replacement procedures, reducing downtime.
-
Robust Communication: Supports complex protocol handling for accurate signal conversion and processing.
-
Extended Lifecycle Support: Backed by ABB’s long-term commitment to product support and spares availability.
-
Optimized for Process Control: Specifically tailored for high-demand control applications in critical infrastructure industries.
Technical Specifications
| Parameter | Details |
|---|---|
| Modèle Number | UFC718AE01 |
| ABB Référence | HIEE300936R0001 |
| Function | Communication Interface Module |
| System Compatibility | Symphony Harmony / Bailey INFI 90 Series |
| Input Voltage | 5 V DC (supplied via system backplane) |
| Power Consumption | 6.5 W |
| Communication Protocols | Serial, RS-232/485, Fieldbus-ready |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH non-condensing |
| Dimensions (W x H x D) | 180 × 135 × 35 mm |
| Poids | 0.65 kg |
| Mounting Type | Rack-mounted (system chassis) |
| LED Indicators | Status and communication diagnostics |
| Certification | CE, UL, RoHS compliant |
Product Applications
-
Power Plants: Used for DCS integration and process monitoring across boiler and turbine control systems.
-
Chemical Processing: Facilitates signal and protocol exchange between field devices and centralized control.
-
Oil & Gas Refineries: Acts as a bridge in safety systems and distributed process unités.
-
Water & Wastewater Treatment: Connects sensors and valves for flow, pressure, and treatment process control.
-
Metallurgical Industry: Ensures consistent process control in high-temperature production environments.
-
Pulp & Paper Plants: Coordinates automation systems from fiber line to finishing.
FAQs (Q&A Format)
Q1: What is the UFC718AE01 module primarily used for?
A1: It functions as a communication interface module within ABB’s Symphony Harmony DCS, allowing integration sur signals and protocols from field equipment to central control unités.
Q2: Is UFC718AE01 compatible with legacy Bailey systems?
A2: Yes, it is designed for seamless integration with both Symphony Harmony and Bailey INFI 90 control systems.
Q3: What kind sur signals can this module handle?
A3: It supports both analog and digital communication signals, with serial protocols like RS-232/485 for broader device compatibility.
Q4: Does the module support hot swapping?
A4: In most ABB rack configurations, UFC718AE01 supports live replacement with proper system redundancy, minimizing downtime.
Q5: Can this module withstand industrial harsh environments?
A5: Yes, it is engineered to operate reliably under high temperatures, humidity, and electrical interference typically found in industrial sites.
Q6: How is this module powered?
A6: It draws low-voltage DC power (5V) directly from the system backplane, simplifying power integration.
Q7: How surten does it require maintenance?
A7: It’s designed for long-term use and typically requires only periodic inspection and diagnostic checks.
Q8: What are the indications if the module fails?
A8: Status LEDs on the front panel provide quick diagnostics—blinking or non-illuminated LEDs indicate communication or power issues.
Q9: Can it be used in safety-critical applications?
A9: Yes, when implemented within redundant architectures, UFC718AE01 is suitable for use in safety-instrumented systems.
Q10: How long is the warranty period?
A10: The standard warranty is 1 years, subject to proper usage and conditions.
Related Modèles (Same Series or Functional Equivalents)
-
UFC760BE – Extended communication interface for high-redundancy configurations
-
UFC721BE101 – Multiprotocol I/O communication processor
-
UFC760AE101 – Compact communication module for hybrid systems
-
INNIS21 – Bailey INFI-NET to system bridge module
-
INNPM22 – Network Processing Module for INFI 90 systems
-
IMMFP12 – Multi-function processor module for centralized control
Popular ABB Modèles (Same Marque)
| Modèle | Function | Voltage | Size (mm) | Poids (kg) |
|---|---|---|---|---|
| PM864AK01 | CPU for AC 800M controller | 24 V DC | 120 × 150 × 80 | 0.45 |
| CI854AK01 | Prsuribus DP communication interface | 24 V DC | 96 × 110 × 70 | 0.30 |
| AI810 | Analog input module (8-channel) | 24 V DC | 150 × 80 × 50 | 0.28 |
| DO810 | Digital output module (16-channel) | 24 V DC | 150 × 80 × 50 | 0.30 |
| AC800M PM861K01 | Controller processor module | 24 V DC | 120 × 150 × 80 | 0.50 |
| CI860 | Modulebus communication interface | 24 V DC | 120 × 110 × 60 | 0.35 |
| TU810V1 | Base for I/O modules | — | 240 × 120 × 60 | 0.55 |
| 07KT98 | Communication processor (MOD 300 system) | 24 V DC | 250 × 140 × 100 | 0.70 |
