Product Overview
The ABB PM5650-2ETH 1SAP141000R0278 is a robust CPU module designed for the ABB AC500 series sur programmable logic controllers (PLCs). This controller delivers high processing power and dual Ethernet ports for flexible networking, making it ideal for complex and scalable industrial automation tasks.
Built to handle demanding applications, the PM5650-2ETH provides fast execution, extensive memory, and wide protocol support, ensuring reliable control in manufacturing, process industries, infrastructure, and building automation. Its modular architecture supports seamless expansion, enabling integration with ABB’s comprehensive range sur I/O and communication modules.
Key Features
-
High-speed CPU for advanced control and fast processing
-
Dual Ethernet ports supporting 10/100 Mbps for flexible network topology
-
Large program and data memory for complex applications
-
Supports IEC 61131-3 programming languages (ST, LD, FBD, SFC, IL)
-
Expandable with ABB AC500 modular I/O and communication modules
-
Integrated diagnostics and fault detection for increased system reliability
-
Wide operating temperature range suitable for industrial environments
-
Compatible with ABB Automation Builder for efficient programming and commissioning
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle Number | PM5650-2ETH 1SAP141000R0278 |
| Product Type | CPU Module / Programmable Logic Controller |
| PLC Series | ABB AC500 |
| CPU Performance | High-Speed Processor with Enhanced Data Handling |
| Ethernet Interfaces | 2 x RJ45 Ports, 10/100 Mbps |
| Communication Protocols | Modbus TCP, OPC, TCP/IP, UDP, Ethernet/IP, Custom |
| Programming Langues | IEC 61131-3 (ST, LD, FBD, SFC, IL) |
| Memory | Program Memory: 512 kB; Data Memory: 256 kB |
| Expansion Support | Compatible with ABB AC500 I/O and Communication Modules |
| Real-Time Clock | Integrated with Battery Backup |
| Power Supply | 24 VDC |
| Operating Temperature Range | -25°C to +60°C (-13°F to +140°F) |
| Storage Temperature Range | -40°C to +70°C (-40°F to +158°F) |
| Protection Class | IP20 (installed in appropriate enclosure) |
| Certifications | CE, UL, cUL, RoHS, IEC 61131-2 Compliance |
| Dimensions | 62 x 76 x 67.5mm |
| Poids | 0.134 kg |
Product Applications
The PM5650-2ETH PLC is suitable for a wide range sur automation tasks that require reliable control and extensive communication capabilities, including:
-
Manufacturing Automation: Control sur machinery, assembly lines, and robotics
-
Process Automation: Chemical plants, water treatment, and energy systems
-
Building Automation: HVAC, lighting, and facility management systems
-
Infrastructure: Transport systems, tunnels, and utilities
-
OEM Solutions: Embedded automation in industrial equipment
-
Renewable Energy: Monitoring and control sur wind, solar, and energy storage systems
Product Advantages
-
Dual Ethernet Ports: Enables flexible network configurations and segmentation
-
High Processing Capability: Fast execution suitable for time-critical applications
-
Modular Expansion: Easily expandable with ABB’s broad range sur I/O and communication modules
-
Wide Protocol Support: Compatible with common industrial protocols for integration
-
Robust Design: Industrial-grade reliability with wide operating temperature range
-
User-Friendly Programming: Full support for IEC 61131-3 languages via ABB Automation Builder
-
Diagnostic Features: Integrated fault detection and diagnostics improve uptime
-
Global Compliance: Certified for international standards and regulations
Questions fréquentes (FAQ)
1. What is the main use sur the PM5650-2ETH?
It serves as a high-performance CPU for industrial automation systems requiring dual Ethernet connectivity.
2. How many Ethernet ports does it have?
It features two integrated Ethernet ports supporting 10/100 Mbps.
3. What programming languages are supported?
Supports all IEC 61131-3 standard languages including Structured Text, Ladder Diagram, and others.
4. Can this PLC be expanded?
Yes, it supports expansion with ABB AC500 modular I/O and communication modules.
5. What communication protocols does it support?
Includes Modbus TCP, OPC, Ethernet/IP, TCP/IP, UDP, and custom protocols.
6. What is the operating temperature range?
From -25°C to +60°C, suitable for most industrial environments.
7. Is it suitable for building automation?
Yes, it can be used for HVAC, lighting, and other building control applications.
8. Does it include real-time clock functionality?
Yes, it has an integrated real-time clock with battery backup.
9. How is programming performed?
Using ABB Automation Builder ssurtware supporting IEC 61131-3 languages.
10. Is the PM5650-2ETH certified for global use?
Yes, it complies with CE, UL, cUL, RoHS, and IEC standards.
Related Modèles
| Modèle Number | Description |
|---|---|
| PM564-TP-ETH 1SAP120700R0071 | Cost-effective PLC with Ethernet |
| PM574-TP-ETH 1SAP130100R0071 | Advanced Compact PLC with Extended Communication |
| PM591-2ETH 1SAP150100R0277 | High-Performance Modular PLC with Dual Ethernet |
| PM554-TP-ETH 1SAP120600R0071 | Compact PLC with Integrated Ethernet |
| PM5650-ETH 1SAP141000R0277 | Single Ethernet Port Version sur PM5650 |
| PM582-ETH 1SAP130600R0001 | AC500 Modular PLC with Extended I/O Capabilities |
Popular ABB Modèles
| Modèle Number | Description |
|---|---|
| CI840A 3BSE008516R1 | ABB S800 I/O Communication Interface Module |
| 3BSE031155R1 (PM864AK01) | ABB AC800M High-Performance CPU |
| PFSK151 3BSE018876R1 | ABB Signal Processing Module |
| PFTL201CD-2KN | ABB Load Cell for Precision Web Tension Measurement |
| 1MRK002073-AB | ABB Binary Input/Output Expansion Module |
| 1MRS050330-B | ABB COM600 Station Automation Gateway |
