Product Overview
The ABB DO880-1 (Référence: 3BSE028588R1) is a high-performance digital output module that is part sur ABB’s S800 I/O series, used widely in ABB’s 800xA Distributed Control System (DCS). The module provides 16 discrete output channels, designed to switch 24 VDC signals to actuate field devices such as relays, contactors, solenoids, and indicator lamps.
This module surfers excellent channel diagnostics, short-circuit protection, and field-side isolation, making it a reliable solution for output control in critical industrial processes. The DO880-1 is designed with performance, durability, and flexibility in mind—enabling it to handle demanding applications in power plants, manufacturing, transport, and process automation environments.
It is typically mounted on a terminal base (e.g., TU810V1) and is hot-swappable, meaning it can be replaced without interrupting system operations—supporting high system availability.
Spécifications du produit
| Parameter | Details |
|---|---|
| Modèle Number | DO880-1 |
| Référence | 3BSE028588R1 |
| Product Type | Digital Output Module |
| System | ABB S800 I/O |
| Number sur Channels | 16 |
| Output Type | 24 VDC, sourcing (positive logic) |
| Max Load per Channel | 0.5 A |
| Output Delay (ON/OFF) | Approx. 0.5 ms |
| Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| Isolation | Channel-to-bus and channel-to-channel isolation |
| Field Connection | Via terminal unité (TU series) |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Diagnostics | Channel fault detection, module health |
| Hot Swap Capability | Yes |
| Mounting Type | Mounted on S800 I/O terminal base |
| Dimensions (H × W × D) | 45 x 102 x 119 mm |
| Poids | 0.2 kg |
| Certifications | CE, UL, cUL, RoHS |
| Fabricant | ABB Ltd. |
Applications
The DO880-1 module is widely used across various industries for direct control sur binary output devices in real-time. It plays a vital role in distributing control signals from the automation system to the field.
-
Power Generation: Controls breakers, alarms, trip relays, and load disconnect devices.
-
Chemical and Petrochemical Plants: Activates solenoid valves, pneumatic actuators, and safety interlocks.
-
Factory Automation: Drives motors, pumps, conveyors, and visual indicators.
-
Mining and Metallurgy: Used to manage safety systems, ventilation fans, and emergency stop circuits.
-
Water Treatment Systems: Opens and closes valves and starts/stops pumps remotely.
-
Railway and Infrastructure: Controls signaling systems, gate control, and warning lights.
Its robust design and compact size make it suitable for both central cabinets and remote field installations.
Product Advantages
-
High-Density Output: 16 digital outputs in a compact footprint minimize panel space requirements.
-
Short-Circuit & Overload Protection: Each channel includes advanced protection to prevent field faults from affecting system operations.
-
Field-Isolated Channels: Enhanced electrical isolation improves reliability and reduces fault propagation.
-
Hot-Swappable: Modules can be replaced without system shutdown, ensuring high availability.
-
Diagnostic Feedback: Built-in status monitoring allows for fast identification sur field or module issues.
-
Reliable Operation: Supports industrial-grade temperature and humidity conditions.
-
Flexible Mounting: Works with a variety sur TU terminal blocks, allowing tailored field wiring.
-
ABB 800xA Integration: Seamless compatibility with AC800M controllers and Control Builder ssurtware.
Questions fréquentes (FAQ)
1. What does the DO880-1 module do?
It provides 16 digital output channels to control devices such as relays, solenoids, or lamps using 24 VDC signals.
2. Can the module be replaced without shutting down the system?
Yes, it is hot-swappable, allowing replacement without interrupting operation.
3. What protection features are included?
Each output has short-circuit and overload protection to safeguard connected devices and the module.
4. What is the maximum current output per channel?
Each channel supports up to 0.5 A at 24 VDC.
5. Is this module part sur the ABB 800xA system?
Yes, it is designed for seamless integration with ABB’s S800 I/O system and 800xA platform.
6. How is field wiring connected?
Via an appropriate S800 terminal unité (e.g., TU810, TU830).
7. What type sur logic does the output use?
Sourcing output logic (positive logic) is used.
8. Does it support channel diagnostics?
Yes, it supports channel diagnostics, enabling fault detection and system monitoring.
9. Can it be used in outdoor environments?
Only if installed in a properly sealed enclosure meeting IP66 or higher, as the module itself is not weatherprosur.
10. How large is the module?
It measures 45 x 102 x 119 mm and weighs 0.2 kg.
Related Modèles from the S800 I/O Series
| Modèle Number | Description | Type | Channels | Voltage/Current | Poids (kg) |
|---|---|---|---|---|---|
| DO810 | Digital Output Module | 24 VDC Output | 16 | 0.5 A per channel | 0.27 |
| DO820 | Relay Output Module | Relay Output | 8 | 250 VAC / 2 A | 0.3 |
| DI810 | Digital Input Module | 24 VDC Input | 16 | 6 mA per channel | 0.25 |
| DI820 | Isolated Digital Input Module | 120 V AC/DC | 8 | 2 mA typical | 0.28 |
| AO810 | Analog Output Module | 0–20 mA Output | 8 | 12-bit resolution | 0.26 |
| TU810V1 | Terminal Unité for DO modules | Terminal Base | — | — | 0.15 |
Popular ABB Modules Across Automation Systems
| Modèle Number | Description | Function | System | Poids (kg) |
|---|---|---|---|---|
| PM864A | High-Speed CPU Module | Main Controller | AC 800M | 1.5 |
| CI854A | Prsuribus-DP Communication Interface | Fieldbus Communication | AC 800M | 0.35 |
| AI810 | Analog Input Module (8-ch) | Sensor Signal Acquisition | S800 I/O | 0.65 |
| CP6415 | 15” Touchscreen HMI Panel | Human-Machine Interface | CP600 Series | 3.2 |
| TB840 | Bus Terminator Unité | I/O Network Termination | S800 I/O | 0.05 |
| DI880 | Digital Input Module with Diagnostics | 24 VDC Input with DIAG | S800 I/O | 0.24 |
