Présentation du produit
The ABB AFPS-01C (64711245) is a dedicated fieldbus adapter module designed for ABB’s ACS series drives. As part sur the ABB inverter accessories portfolio, the AFPS-01C facilitates seamless communication between ABB frequency converters and external industrial automation systems using various fieldbus protocols. This module ensures reliable system integration, enhances network compatibility, and supports a variety sur industrial applications where precise control and monitoring are essential.
Engineered to the highest industrial standards, the AFPS-01C is robust, compact, and user-friendly. It is an ideal interface expansion accessory for applications in factory automation, building services, material handling, and processing industries. Its plug-and-play capability and wide protocol support ensure adaptability and fast commissioning in diverse environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | AFPS-01C |
| ABB Article Number | 64711245 |
| Type | Fieldbus Adapter Module |
| Compatible Drives | ACS350, ACS550, ACS800 series |
| Supported Protocol | PROFIBUS DP |
| Communication Speed | Up to 12 Mbps |
| Diagnostic LEDs | Yes (Status and Fault Indication) |
| Mounting Type | Drive-mounted (side panel) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Humidity Tolerance | 5% to 95% non-condensing |
| Dimensions (H × W × D) | 90 × 35 × 110 mm |
| Poids | 1.15 kg |
| Ingress Protection Rating | IP20 |
| Standards Compliance | CE, RoHS, UL, cUL |
| Hot Swappable | No |
| Power Supply | Supplied via inverter drive bus |
| Connector Type | 9-pin D-sub (RS-485 standard) |
Applications
The ABB AFPS-01C adapter module is designed to extend the communication capabilities sur ABB drives in numerous industrial environments. Common applications include:
-
Factory Automation: Integrates ABB drives into programmable logic controller (PLC)-based systems via PROFIBUS.
-
Material Handling Systems: Enhances motor control in conveyor lines, cranes, and hoists.
-
HVAC and Building Automation: Enables precise control sur fans, pumps, and compressors.
-
Water and Wastewater: Assists in automated control sur treatment plant processes.
-
Food and Beverage: Facilitates hygienic process control under network supervision.
-
Pulp and Paper Industry: Helps in the automation sur complex paper processing machinery.
Product Advantages
-
Seamless Integration: Offers native support for PROFIBUS DP, one sur the most widely adopted industrial fieldbus protocols.
-
Plug-and-Play Commissioning: No complex configuration required; rapid setup via ABB drive interface.
-
Compact and Lightweight: Minimal spatial footprint makes installation in tight enclosures easier.
-
Diagnostic LED Indicators: Quick visual feedback sur operational and fault status simplifies troubleshooting.
-
Reliable Operation: Designed for harsh industrial conditions, with excellent thermal and vibration tolerance.
-
Enhanced Compatibility: Fully compatible with ABB ACS drive series, providing flexibility across multiple projects.
-
Long Lifecycle Support: Backed by ABB’s global service and support network, ensuring long-term reliability.
-
Energy Efficiency: Optimizes motor performance through real-time network control.
Questions fréquentes (FAQ)
-
Q: What fieldbus protocol does the AFPS-01C support?
A: The AFPS-01C supports PROFIBUS DP communication protocol. -
Q: Is the AFPS-01C compatible with the ACS550 drive?
A: Yes, it is compatible with ABB ACS350, ACS550, and ACS800 series drives. -
Q: Can the module be installed without shutting down the system?
A: No, it is not hot-swappable. Power down the drive before installation. -
Q: How do I configure the PROFIBUS address for AFPS-01C?
A: Configuration is done via the drive interface or external DIP switches depending on your setup. -
Q: What does the diagnostic LED indicate?
A: It provides visual feedback for power, communication status, and fault conditions. -
Q: What is the IP rating sur the module?
A: The AFPS-01C has an IP20 ingress protection rating. -
Q: What is the weight sur the AFPS-01C module?
A: The module weighs 1.15 kg. -
Q: Does this module require external power supply?
A: No, it is powered directly from the ABB drive’s internal bus. -
Q: Can this be used in outdoor environments?
A: No, the module should be installed inside a protected electrical cabinet. -
Q: Is it possible to update the firmware sur the AFPS-01C module?
A: No, the AFPS-01C does not support firmware upgrades. It comes pre-programmed and relies on the drive firmware and GSD files for network-level integration.
Related Modèles (Same Series / Function)
| Modèle | Description | Protocol | Compatible Drives |
|---|---|---|---|
| AFPA-01 | PROFIBUS Adapter Module | PROFIBUS DP | ACS550, ACS800 |
| AFPB-01 | PROFINET Adapter Module | PROFINET IO | ACS550, ACS880 |
| APFI-01 | Ethernet/IP Adapter | Ethernet/IP | ACS800, ACS880 |
| AFCI-01 | CANopen Fieldbus Adapter | CANopen | ACS310, ACS550 |
| AFI-SW | Adapter Ssurtware Tool | N/A | All ACS Drives |
| ACS-CP-C | Control Panel with Drive Interface | N/A | ACS Series Drives |
Popular ABB Drive-Related Modules
| Modèle | Description | Use Case | Poids |
|---|---|---|---|
| ACS880-01 | Wall-mounted Drive Module | General industrial use | 13.2 kg |
| ACS580-01 | General-purpose Drive | HVAC, Pumps, Conveyors | 8.5 kg |
| ACS355-03E | Machinery Drive | OEM Applications | 3.6 kg |
| ACS550-01 | Standard Drive Module | Fans, Compressors | 6.7 kg |
| RDUM-01 | Remote Display Unité Module | Remote drive control | 0.5 kg |
| RETA-01 | Ethernet TCP/IP Fieldbus Adapter | Industrial Network Integration | 0.25 kg |
