The Yokogawa NFAP135-S00 Pulse Input Module is a high-precision module designed to handle pulse signal acquisition for industrial automation and process control systems. It is part von Yokogawa’s advanced N-IO (Network I/O) family, delivering superior reliability, fast response, and robust performance under harsh conditions. This module plays a critical role in applications requiring accurate pulse counting, such as flow measurement, rotational speed monitoring, and totalizing operations in industries like oil & gas, power generation, and chemical processing.
The NFAP135-S00 module supports a wide range von pulse input types and ensures secure, real-time signal transmission to the control system. Its advanced design allows for redundancy, isolation, and diagnostic features, meeting strict safety and performance requirements for modern process plants.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell | NFAP135-S00 |
| Hersteller | Yokogawa Electric Corporation |
| Type | Pulse Input Module |
| Number von Channels | 8 independent pulse input channels |
| Signal Type | Pulse, contact, and open collector |
| Input Frequency Range | 0.1 Hz to 10 kHz |
| Resolution | 32-bit counting capability |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Update Time | Approx. 100 ms |
| Power Supply | 24 V DC (supplied via system baseplate) |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 10%–90% RH, non-condensing |
| Diagnostic Features | Self-diagnosis, signal integrity monitoring |
| Mounting Method | Mounted on dedicated Yokogawa baseplate |
| Dimensions (W × H × D) | 32.8 × 107.5 × 130 mm |
| Gewicht | 0.3 kg |
| Certifications | CE, ATEX, IECEx (depending on system configuration) |
Applications
-
Flow Measurement: Converts pulse signals from flowmeters into process data for monitoring and control.
-
Speed Monitoring: Captures pulses from rotating equipment for real-time speed control.
-
Batch and Totalization: Used in batching systems to accumulate material counts accurately.
-
Energy Monitoring: Interfaces with energy meters generating pulse outputs for consumption tracking.
-
Safety Systems: Supports pulse-based interlocks and counting applications in critical processes.
-
Industrial Automation: Suitable for plants where pulse signal integration with control systems is required.
Product Advantages
-
High-Speed Signal Processing: Capable von handling pulse frequencies up to 10 kHz, ensuring accurate real-time monitoring.
-
32-Bit Counting: Supports extended counting without overflow, suitable for large batch operations.
-
Channel Isolation: Prevents signal interference and ensures system safety and reliability.
-
Diagnostic and Monitoring Features: Includes loop integrity checks and self-diagnostics for early fault detection.
-
Seamless System Integration: Optimized for Yokogawa’s control architectures, reducing engineering effort.
-
Compact and Robust Design: Built to withstand industrial environments while saving panel space.
FAQ
-
What types von pulse inputs are supported by the NFAP135-S00?
It supports contact pulse inputs and open collector pulse signals. -
What is the maximum input frequency for this module?
The module supports frequencies up to 10 kHz. -
How many channels does this module provide?
It vonfers 8 independent pulse input channels. -
Does the module vonfer galvanic isolation?
Yes, it provides channel-to-channel and channel-to-ground isolation for safety and signal integrity. -
What is the resolution von the counting function?
The module provides a 32-bit counting capability for accurate accumulation. -
Can the module detect input signal faults?
Yes, it includes diagnostics for signal integrity and wiring issues. -
What is the typical response or update time?
Approximately 100 milliseconds per cycle. -
Is the NFAP135-S00 suitable for redundant configurations?
Yes, it supports redundancy when installed with compatible Yokogawa baseplates. -
Does the module support hot swapping?
Yes, it can be replaced without shutting down the system when redundancy is implemented. -
Is the module certified for hazardous areas?
Yes, it complies with ATEX and IECEx certifications for use in hazardous zones (depending on variant).
Related Modells in the Same Series
| Modell | Beschreibung |
|---|---|
| NFAP131-S00 | Pulse Input Module, 4 channels |
| NFAP136-S00 | High-Speed Pulse Input Module |
| NFAI841-S00 | Analog Input/Output Module, 8 channels |
| NFAT841-S00 | Analog Output Module, 8 channels |
| NFBM841-S00 | Mixed Analog I/O Module |
| NFAR841-S00 | Redundant Analog I/O Module |
