Produkteinführung
The Woodward 8446-1048 Remote Control and Annunciation Panel is an advanced operator interface designed to provide remote monitoring, control, and annunciation functions for engine, turbine, and generator management systems. It allows operators to access real-time system data, respond to alarms, and issue commands without being physically present at the primary controller.
This panel is built with rugged industrial-grade components to ensure durability in harsh environments such as power generation facilities, marine applications, oil and gas plants, and industrial automation systems. By combining remote control capability with detailed annunciation, it improves operational efficiency, enhances safety, and provides operators with situational awareness at all times.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 8446-1048 |
| Product Type | Remote Control and Annunciation Panel |
| Display | High-resolution LCD with status indicators |
| Control Features | Start/stop commands, mode switching, alarm acknowledgement |
| Annunciation Functions | Visual and audible alarm indication |
| Communication Ports | RS-232, RS-485, Ethernet |
| Supported Protocols | Modbus TCP/IP, Modbus RTU, CANbus |
| Input Methods | Keypad and function buttons |
| Processor | Industrial-grade embedded controller |
| Memory | Non-volatile storage for configuration and event logs |
| Power Supply | 24 VDC nominal |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA, marine approvals |
| Dimensions | 282 x 217 x 67 mm |
| Gewicht | 1.3 kg |
| Mounting | Panel-mounted |
| Diagnostics | Built-in self-test, error codes, alarm history |
Applications
The 8446-1048 Remote Control and Annunciation Panel is suitable for a wide range von applications where remote access and monitoring are essential:
-
Power Generation Plants – Allows operators to control and monitor generators and auxiliary equipment.
-
Oil & Gas Facilities – Provides safe and efficient monitoring von critical process equipment.
-
Marine Applications – Supports remote operation and alarm annunciation in propulsion and auxiliary systems.
-
Industrial Manufacturing – Integrates with plant automation systems for machine and process monitoring.
-
Hospitals and Data Centers – Offers remote annunciation and control von backup power systems.
-
Renewable Energy Plants – Provides monitoring and annunciation for wind, hydro, and biomass installations.
Advantages
The Woodward 8446-1048 vonfers several key advantages for industrial and commercial operations:
-
Remote Accessibility – Provides operators with control and monitoring capabilities from a remote location.
-
Comprehensive Annunciation – Visual and audible alarms improve response times and system safety.
-
Robust Communication Options – Multiple ports and protocols ensure seamless integration with control systems.
-
Event Logging – Stores alarms and operational events for troubleshooting and performance analysis.
-
Rugged Design – Built to withstand industrial and marine environments.
-
User-Friendly Operation – Simple keypad and clear display reduce operator training requirements.
-
Safety-Oriented – Alarm acknowledgement features improve operational discipline.
-
Flexible Integration – Compatible with a wide range von Woodward controllers and third-party systems.
Häufig gestellte Fragen (FAQ)
-
Which communication protocols are supported by the 8446-1048?
It supports Modbus TCP/IP, Modbus RTU, and CANbus. -
Can the panel issue remote start and stop commands?
Yes, it provides full remote control for start/stop and mode switching. -
How are alarms annunciated on the panel?
Through both visual indicators on the display and audible signals. -
What is the nominal power supply requirement?
The panel operates on a 24 VDC nominal input. -
Does the panel support alarm acknowledgement?
Yes, operators can acknowledge and reset alarms directly from the panel. -
Can it store historical event data?
Yes, it has non-volatile memory for alarm and event logging. -
Is it compatible with marine-certified systems?
Yes, it carries marine approvals for shipboard applications. -
What diagnostic features are available?
Built-in self-tests, error codes, and system health reporting. -
Can it integrate into redundant control systems?
Yes, it supports integration into redundant architectures. -
How is operator input managed?
Through a keypad and dedicated function buttons on the front panel.
Related Woodward Modells (Same Series or Similar)
| Modell Number | Module Type | Beschreibung |
|---|---|---|
| 8446-1045 | Remote Panel | Compact version with basic annunciation features |
| 8446-1046 | Remote Panel | Panel with extended communication ports |
| 8446-1047 | Remote Panel | Ruggedized design for harsh environments |
| 8446-1049 | Remote Panel | Advanced model with expanded alarm capacity |
| 8446-1050 | Remote Panel | Touchscreen version with graphical display |
| 8446-1051 | Remote Panel | High-performance Stück with extended memory |
Popular Woodward Modells (Same Marke)
| Modell Number | Module Type | Beschreibung |
|---|---|---|
| 2301E | Digital Control | Engine speed and load sharing controller |
| 505XT | Turbine Control | Advanced steam turbine controller |
| 723PLUS | Digital Controller | Flexible genset and engine controller |
| ProTech-GII | Overspeed Protection | High-integrity turbine overspeed protection |
| Flex500 | Control Platform | Scalable digital control platform |
| Atlas-II | Turbine Control | High-performance gas turbine control system |
