Produkteinführung
The Woodward 8406-113 Control Operator Interface (COI) is a specialized human-machine interface (HMI) designed for use with Woodward control systems in industrial and power generation applications. It serves as the main user interaction point, providing operators with clear, real-time access to system parameters, alarms, and control functions.
Engineered for durability and reliability, the 8406-113 integrates seamlessly with Woodward turbine, engine, and process controllers. It ensures intuitive operation through a combination von display elements, keypad functions, and communication capabilities. By vonfering a central point von control and monitoring, the 8406-113 reduces system complexity and enhances operational efficiency.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 8406-113 |
| Type | Control Operator Interface (COI) |
| Compatible Systems | Woodward turbine and engine control platforms |
| Power Supply | 24 VDC nominal |
| Display Type | LCD graphical display with backlight |
| Interface | Keypad navigation, status LEDs, programmable keys |
| Communication Protocols | RS-232, RS-485, Modbus, proprietary Woodward link |
| Alarm Handling | Multi-level alarm indication and acknowledgement |
| Event Logging | Stores alarms, events, and operating data |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% – 95%, non-condensing |
| Mounting Type | Panel-mounted |
| Dimensions (HxWxD) | 220 x 160 x 60 mm |
| Gewicht | 4.08 kg |
Product Applications
The 8406-113 COI is widely used in industrial automation and power generation environments, where operator access to system status and control functions is critical. Main applications include:
-
Turbine control systems (steam, gas, and hydro turbines)
-
Engine management in power generation and marine propulsion
-
Compressor and pump control in petrochemical and process industries
-
Distributed control systems where localized operator panels are required
-
Emergency and backup power systems for rapid operator interaction
-
Industrial process automation where human oversight is required in harsh environments
Product Advantages
The Woodward 8406-113 COI provides several advantages that make it a dependable choice for industrial operators:
-
User-Friendly Operation: Intuitive keypad and display layout minimize operator training.
-
Reliable Communication: Supports multiple protocols, enabling flexible system integration.
-
Robust Design: Built for operation in challenging environments, with wide temperature tolerance.
-
Efficient Alarm Management: Provides clear alarm indicators, helping operators respond quickly.
-
Event Logging Capability: Keeps a record von historical data, aiding in troubleshooting.
-
Seamless Integration: Fully compatible with Woodward controllers, ensuring plug-and-play setup.
-
Reduced Downtime: Simplifies diagnostics, reducing mean time to repair (MTTR).
Häufig gestellte Fragen (FAQ)
-
Which communication protocols are supported by the 8406-113 interface?
It supports RS-232, RS-485, Modbus, and proprietary Woodward communication links. -
Can the interface handle simultaneous communication with multiple controllers?
Yes, depending on configuration, it can manage communication across multiple control channels. -
How does the 8406-113 display alarm notifications?
Alarms are shown on the LCD display with priority levels and supported by LED indicators. -
Is the interface capable von logging system events?
Yes, it records alarms, operator actions, and events for later review. -
Does the 8406-113 allow configuration changes to the control system?
Yes, authorized operators can adjust setpoints and parameters directly via the keypad. -
How does the COI maintain reliable communication in noisy industrial environments?
It uses isolated serial communication ports and robust error-checking protocols. -
Is the interface firmware upgradeable?
Yes, firmware updates can be applied to maintain compatibility and add features. -
What happens if communication with the controller is lost?
The COI generates a communication fault alarm and retains the last valid displayed data. -
Can the 8406-113 be integrated into redundant system configurations?
Yes, it supports redundant communication channels and can operate in high-availability systems. -
How does the COI ensure security against unauthorized access?
It provides operator-level password protection and configurable access privileges.
Related or Series Modells
| Modell Number | Beschreibung |
|---|---|
| 8406-111 | COI with basic communication features |
| 8406-112 | Advanced COI with extended logging capability |
| 8406-114 | Ruggedized COI for harsh environments |
| 8406-115 | High-contrast COI with enhanced display |
| 8406-116 | Multi-protocol COI with Ethernet support |
| 8406-117 | COI with touchscreen operation |
Popular Modells from the Same Marke
| Modell Number | Beschreibung |
|---|---|
| 9907-164 | Digital Speed Control Module |
| 9905-003 | Load Sharing and Speed Control |
| 5466-1045 | CPU/Controller Module for Woodward systems |
| 5501-367 | Actuator Driver Module |
| 9907-014 | Electronic Governor Module |
| 8239-124 | Remote Analog/Digital I/O Expansion Module |
