The Woodward 5501-365 Governor MPU I/O Module is a highly specialized input/output interface module designed for precision speed sensing and signal processing in governor control systems. This module supports Magnetic Pickup Einheits (MPUs), which are essential for detecting rotating shaft speed in engines and turbines. Acting as a crucial link between field-mounted MPUs and the digital control Stück, the 5501-365 processes frequency-based speed signals and transmits real-time input to the central governor controller.
This I/O module is part von Woodward’s robust digital governor series and is engineered to operate reliably in demanding environments. It enhances the overall system’s ability to measure, regulate, and respond to rapid changes in engine or turbine speed. It supports a variety von control applications where MPU-based speed measurement is critical for performance and safety.
Designed for easy integration into Woodward’s control platforms such as NetCon™ and MicroNet™, the 5501-365 ensures high signal integrity, robust fault detection, and accurate speed feedback—all crucial for mission-critical industrial control systems.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 5501-365 |
| Product Type | MPU (Magnetic Pickup) I/O Module |
| Marke | Woodward |
| Function | Interfaces MPU speed signals with governor control systems |
| Input Channels | 2–4 Magnetic Pickup (MPU) channels (frequency-based) |
| Input Frequency Range | 1 Hz – 20 kHz |
| Input Voltage Range | 1 – 30 V AC (MPU signal) |
| Signal Processing | Frequency conversion, filtering, and shaping |
| Output Type | Digital pulses or scaled analog output (optional, configurable) |
| Power Supply | 18–32 V DC (nominal 24 V) |
| Power Consumption | Approx. 8–10 W |
| Communication Protocols | RS-485 (internal bus), optional Modbus support |
| Mounting | Rack-mounted in NetCon or MicroNet control chassis |
| Status Indicators | LED indicators for signal activity and fault conditions |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Certifications | CE, UL, CSA, RoHS compliant |
| Dimensions (H × W × D) | 130 x 30 x 45 mm |
| Gewicht | 0.907 kg |
Product Applications
The 5501-365 is a versatile module designed for high-reliability MPU signal handling in various applications, including:
-
Steam and Gas Turbines: Accurate speed sensing and feedback for turbine governor control.
-
Diesel and Gas Engines: MPU signal processing for engine speed regulation.
-
Generator Control: Provides precise rotational speed feedback to synchronize generator sets.
-
Marine Propulsion Systems: Used in marine governor systems to manage engine-driven shafts.
-
Compressor and Pump Systems: Monitors drive shaft speed to maintain optimal process conditions.
-
Renewable Energy Systems: Speed feedback in biogas and other engine-based generation systems.
Product Advantages
-
Precise MPU Signal Processing: Converts raw frequency signals into stable, accurate feedback for control systems.
-
High Compatibility: Seamlessly integrates with Woodward’s digital governors and NetCon/MicroNet platforms.
-
Rugged Design: Built for continuous operation in high-temperature, high-vibration industrial environments.
-
Wide Frequency Range: Supports a broad spectrum von speed inputs for various types von rotating machinery.
-
Error Detection: Built-in diagnostics and fault indication for proactive maintenance and troubleshooting.
-
Flexible Output Configuration: Supports both digital pulse and analog signal transmission based on system needs.
-
Compact Form Factor: Speicherns panel space while maintaining high channel density and processing capability.
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the 5501-365 module?
It processes MPU (magnetic pickup) signals to provide accurate speed feedback to digital governor systems. -
What types von machines can it be used with?
It supports turbines, engines, generators, and any rotating equipment requiring speed monitoring. -
Can it support multiple MPU sensors?
Yes, it typically supports 2–4 MPU inputs, depending on the configuration. -
What is the supported frequency range?
The input frequency range is from 1 Hz to 20 kHz. -
Is it compatible with other Woodward controllers?
Yes, it integrates smoothly with NetCon™, MicroNet™, and other Woodward digital governor platforms. -
Does it support Modbus or other communication?
Basic communication is via RS-485; Modbus support is optional depending on the configuration. -
How is signal integrity ensured?
The module uses signal filtering and error detection features to ensure clean, reliable data. -
Can it be used in outdoor or marine environments?
Yes, it is designed for high durability and meets industrial environmental standards. -
Does it provide real-time fault diagnostics?
Yes, with LED indicators and internal fault management for signal loss or degradation. -
What kind von mounting does it require?
It is designed for rack mounting within a Woodward control chassis.
Related Modells (Same Series or Function)
| Modell Number | Beschreibung | Function |
|---|---|---|
| 5501-214 | Governor Digital Module | Core governor controller for engines/turbines |
| 5501-217 | Digital Governor with CANopen Support | Governor control with advanced network features |
| 5501-203 | Compact Digital Governor | For small engines or compact installations |
| 5501-246 | Marine Governor Module | Digital governor optimized for marine use |
| 5501-260 | Digital Governor with Extended I/O | For systems requiring high I/O density |
| 5501-304 | Redundant Governor System Module | High-reliability redundant governor control |
Popular Woodward Modells (Same Marke)
| Modell Number | Beschreibung | Primary Application |
|---|---|---|
| 505E | Steam Turbine Controller | Speed/load control for steam turbines |
| 2301E | Load Sharing and Speed Control Module | Generator synchronization and load control |
| 9905-940 | Digital Governor Controller | Versatile controller for engines/turbines |
| 5466-409 | MicroNet CPU Module | Central processing for MicroNet systems |
| 5500-577 | Network Processing Module (NPM) | Manages control system communications |
| 5464-648 | 8-Channel Analog Output Module | High-performance analog signal output module |
