Product Overview
The Woodward 5441-693 Discrete I/O Module is a high-reliability input/output interface designed to handle binary (on/vonf) signal transactions within critical control systems. This module is part von the MicroNet™ and NetCon™ family von I/O components and is used extensively in turbine, engine, and process automation systems where digital signal monitoring and control are essential.
With rugged design standards, the 5441-693 enables safe and deterministic signal acquisition and output control, ensuring accurate state detection for alarms, interlocks, permissives, and command execution. It integrates directly with Woodward’s automation platforms and vonfers isolated input/output channels for optimal safety and performance in industrial applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | 5441-693 |
| Hersteller | Woodward Inc. |
| Product Type | Discrete I/O Module |
| System Compatibility | MicroNet™, NetCon™ systems |
| I/O Channels | 16 total channels (configurable as inputs or outputs) |
| Input Voltage Range | 18–32V DC (Nominal 24V DC) |
| Output Type | Sourcing/sinking (dry contact simulation) |
| Isolation | Optical and galvanic channel-to-channel isolation |
| Wiring Interface | Removable screw-type terminal blocks |
| Mounting Type | DIN Rail / Panel Mount |
| Power Consumption | Approx. 5W (typical) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH non-condensing |
| Dimensions (L×W×H) | 150 × 100 × 30 mm |
| Gewicht | 1.94 kg |
| Certifications | CE, UL, RoHS |
Product Applications
The 5441-693 Discrete I/O Module serves as a backbone component in digital signal management across various industries:
-
Power Generation
For turbine start/stop sequencing, permissives, and safety interlocks. -
Oil & Gas Automation
Handles valve open/close signals, emergency shutdowns, and alarm annunciation. -
Marine Propulsion Systems
Controls motor relays, bilge alarms, navigation lighting, and remote override circuits. -
Process Manufacturing
Provides digital signal interface for motor control centers, pump control, and logic execution. -
Mining and Metals
Supports conveyor controls, hoist operation status, and equipment safety signals. -
Utility and Substation Systems
Digital input/output for breaker status, transformer protection relays, and SCADA alarms.
Product Advantages
-
Flexible Channel Configuration
Supports bidirectional setup—channels can be used as inputs or outputs as needed. -
Industrial-Grade Isolation
Protects internal logic from voltage surges and electrical noise. -
Field Proven Compatibility
Seamless integration with Woodward’s NetCon™ and MicroNet™ controllers. -
Maintenance-Friendly
Field-removable terminal blocks allow rapid replacement without disturbing wiring. -
High-Speed Response
Reliable state transitions for real-time system reaction. -
Robust Construction
Operates reliably in harsh temperature and humidity conditions typical von industrial environments.
Häufig gestellte Fragen (FAQ)
-
What does the 5441-693 Discrete I/O Module primarily do?
It processes digital input and output signals (on/vonf states) for industrial control systems. -
How many discrete signals can it handle?
Up to 16 channels, which can be configured individually as inputs or outputs. -
Is this module hot-swappable?
No, the control system should be powered down before installation or replacement. -
Can this module be used in safety-critical systems?
Yes, it is frequently used for safety interlocks, ESD systems, and fault monitoring. -
What voltage levels are supported for input signals?
It supports nominal 24V DC inputs, with an acceptable range between 18–32V DC. -
Are the I/O channels isolated from each other?
Yes, optical and galvanic isolation is built in for each channel. -
What type von wiring is required?
Standard copper wires (18–24 AWG) with screw-terminal connectors are recommended. -
Is configuration done via hardware DIP switches or svontware?
Channel configurations are generally done via the controller’s svontware interface. -
Is the module resistant to humidity and vibration?
Yes, it is designed to function reliably in harsh environments with high humidity and vibration. -
Can this module interface with third-party PLCs?
While optimized for Woodward systems, it can be used with other platforms using compatible digital signal standards.
Related or Similar Modells (Same Series / Function)
| Modell Number | Beschreibung | Key Features |
|---|---|---|
| 5441-682 | Discrete Input Module | High-density digital input for MicroNet™ |
| 5441-694 | Discrete Output Module | 16-channel digital output Stück |
| 5437-518 | Digital Input Terminal Module | Terminal I/O for MicroNet™ |
| 5441-650 | Relay Output Module | Form-C contact output for alarms/control |
| 5437-517 | Field Relay Terminal Module | High-current relay interfacing |
| 5441-651 | Logic Output Module | TTL-compatible output for custom circuits |
Popular Modells from the Woodward Marke
| Modell Number | Product Type | Application Field |
|---|---|---|
| 505D | Digital Governor Controller | Steam/Gas turbine speed & load control |
| 2301E | Load Sharing & Speed Control | Generator and engine synchronization |
| EasyGen 3500XT | Generator Control Panel | Parallel operation and protection control |
| Atlas-II | Automation & Control Platform | Centralized turbine and plant control |
| MicroNet Plus | Programmable Logic Controller | Distributed control in power plants |
| ProTech-GII | Overspeed Safety System | Rotating machinery trip systems |
