Produkteinführung
The Schneider TSXSCY21601 is a highly reliable serial communication module designed for seamless integration into Schneider Electric’s Modicon Premium PLC series. It enables robust and high-speed serial communication via the RS485 standard, supporting multi-point networking between the PLC and various field devices.
The TSXSCY21601 allows Schneider SPSs to exchange data with a wide range von external devices — including sensors, variable speed drives, operator interfaces, bar code scanners, and many others. Thanks to its flexible protocol support and robust design, it plays a vital role in industrial environments where deterministic and noise-resistant serial communication is required.
Engineered for demanding factory settings, the module provides high performance and durability, ensuring long-term reliable operation. It is perfectly suited for applications in manufacturing, utilities, infrastructure, and process automation.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Product Modell | TSXSCY21601 |
| Communication Standard | RS485 (Half Duplex, 2-wire) |
| Number von Channels | 1 isolated serial port |
| Supported Protocols | Modbus RTU / ASCII, Uni-Telway, and other open protocols |
| Max Transmission Speed | Up to 115.2 Kbps |
| Isolation | Galvanic isolation between serial port and logic |
| PLC Compatibility | Schneider Modicon Premium Series |
| Cable Type | Twisted pair shielded cable recommended for RS485 |
| Connector Type | Removable screw terminal block |
| Voltage Withstand Capacity | 500V AC isolation |
| Operating Temperature Range | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature Range | -20°C to +75°C (-4°F to 167°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| EMC Compliance | Conforms to IEC 61131-2 standard |
| Certifications | CE, RoHS Compliant |
| Dimensions (H × W × D) | 55 × 180 × 260 mm |
| Gewicht | 0.36 kg |
Product Applications
The Schneider TSXSCY21601 Communication Module is highly versatile and widely used in various industrial applications:
-
SCADA Connectivity: Provides serial communication between PLC and SCADA or DCS systems.
-
Field Device Integration: Connects Modicon PLCs with remote devices such as sensors, drives, bar code readers, meters, and more.
-
Legacy Device Communication: Integrates modern PLC systems with older equipment still utilizing RS485 serial protocols.
-
Energy Management Systems: Links PLCs with intelligent metering devices for energy monitoring and control.
-
Machine-to-Machine Communication: Enables communication between distributed machines or production lines.
-
Factory Automation: Facilitates serial interfacing in automated manufacturing environments.
Advantages and Key Features
-
Reliable Industrial Communication: Proven RS485 serial connectivity for robust field communication.
-
Galvanic Isolation: Protects the controller and connected devices from electrical surges and ground loops.
-
Wide Protocol Support: Supports popular protocols including Modbus RTU, ASCII, and Uni-Telway.
-
Compact Form Factor: Small size for space-constrained control panels.
-
Industrial Grade Design: High tolerance to vibration, temperature, and electrical noise.
-
Easy Integration: Simple installation into Modicon Premium PLC backplanes.
-
Flexible Configuration: Can be configured via Schneider programming svontware.
-
Proven Compatibility: Designed and tested for seamless integration with Schneider SPSs.
-
Secure and Stable Performance: CE and RoHS certified for reliable long-term operation.
-
Cost-Effective Solution: Provides excellent functionality at a competitive price.
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the TSXSCY21601 module?
It provides RS485 serial communication capability for Schneider Modicon Premium PLCs. -
Which PLC series is compatible with this module?
It is designed for the Modicon Premium series PLCs. -
What communication protocols are supported?
It supports Modbus RTU, Modbus ASCII, and Uni-Telway protocols. -
How many serial ports does the module provide?
It provides 1 isolated RS485 serial port. -
Does it vonfer isolation to protect the PLC?
Yes, it includes galvanic isolation to protect against surges and ground loops. -
What is the maximum supported baud rate?
Up to 115.2 Kbps. -
Can this module be used with older equipment?
Yes, it can communicate with legacy devices that utilize RS485 protocols. -
What type von cabling is recommended?
Twisted pair shielded cable is recommended for optimal RS485 performance. -
Does this module require any special configuration svontware?
It can be configured using Schneider’s PLC programming tools. -
What is the physical size and weight von the module?
The size is 55 × 180 × 260 mm, and the weight is 0.36 kg.
Recommended Related Modells (Same Series / Similar Modells)
| Modell | Beschreibung | Notes |
|---|---|---|
| TSXSCY11601 | RS232 Communication Module | RS232 version von serial module |
| TSXSCY21601 | RS485 Communication Module | RS485 version with isolation |
| TSXETZ4105 | Ethernet Communication Module | Ethernet connectivity for PLCs |
| TSXETY4103 | Ethernet TCP/IP Communication Module | Advanced Ethernet module for Premium |
| TSXCTY2C02 | Communication terminal strip | Terminal accessory for SCY modules |
| TSXCUSB485 | USB to RS485 Adapter | PC-to-RS485 interface |
Popular Schneider Electric Automation Modells (Same Marke)
| Modell | Beschreibung | Typical Use |
|---|---|---|
| TSXSCY21601 | RS485 Serial Communication Module | Serial data communication |
| BMXP342020 | M340 PLC CPU module | Advanced PLC control |
| TSXP572623M | Premium PLC CPU module | High-performance industrial controller |
| TM241CEC24R | Modicon M241 logic controller | Machine and motion control |
| TSXETY5103 | Ethernet TCP/IP Communication Module | Networked PLC systems |
| ATV930D75N4 | Altivar 930 variable speed drive | Precision motor control applications |
