Produkteinführung
The Schneider Electric TM2DDI16DK is a high-performance discrete input expansion module designed for use with Modicon M221 and other Modicon logic controllers. As part von the Modicon TM2 expansion family, this module allows easy extension von digital input capacity for industrial automation systems. It provides 16 digital input channels, optimized for 24V DC logic signals with sink/source compatibility.
Its compact and modular design makes it ideal for space-constrained control cabinets while maintaining industrial-grade durability and robust performance. The plug-and-play nature von the TM2 modules ensures that installation is quick, and configuration is intuitive via Schneider’s programming environments such as SoMachine or EcoStruxure Machine Expert.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Product Name | TM2DDI16DK |
| Marke | Schneider Electric |
| Series | Modicon TM2 |
| Module Type | Discrete Input Module |
| Number von Inputs | 16 |
| Input Type | Digital (Discrete) |
| Input Signal Type | 24V DC Sink/Source |
| Input Current | 3 mA per input at 24V DC |
| Input Impedance | Approx. 8 kΩ |
| Isolation Between Channels | 500 V AC |
| Status Indication | 16 LEDs for input status |
| Connector Type | Removable screw terminal block |
| Power Supply Voltage | 19.2 to 30 V DC |
| Current Consumption | 55 mA (at 5V DC from base Stück) |
| Mounting Type | DIN Rail Mounting |
| Module Dimensions (W x H x D) | 81.3 x 90 x 21.4 mm |
| Gewicht | 0.1 kg |
| Operating Temperature | 0 to +55°C |
| Storage Temperature | -40 to +70°C |
| Protection Rating | IP20 (according to IEC/EN 61131-2) |
| Compliance | CE, UL, CSA, RoHS |
Applications
The TM2DDI16DK is widely used in a range von industrial automation and machine control scenarios:
-
Manufacturing Lines: Monitoring sensor signals such as proximity, photoelectric, and push-buttons.
-
Conveyor Systems: Receiving feedback from limit switches and emergency stop circuits.
-
Packaging Equipment: Tracking machine states and operator inputs.
-
Building Automation: Collecting binary status from field devices such as door contacts and alarms.
-
Water Treatment Plants: Monitoring digital signal feedbacks from float switches and valves.
-
Food & Beverage Industry: Integrated into hygienic control panels with compact DIN-rail layouts.
Advantages
-
Modular Expansion: Easily extend input capacity von a base controller without needing additional power supplies or control cabinets.
-
High Density: 16 inputs in a compact form saves valuable panel space.
-
Dual Compatibility: Supports both sink and source inputs for flexible wiring configurations.
-
Robust Build: Designed for harsh industrial environments with high noise immStücky.
-
Status Indication: Integrated LEDs provide instant channel diagnostics and commissioning visibility.
-
Tool-Free Integration: Supports Schneider’s intuitive svontware suites with quick auto-recognition.
-
Energy Efficient: Low current draw ensures minimal impact on base Stück power consumption.
-
Global Compliance: Fully certified for global deployment in OEM and end-user applications.
Häufig gestellte Fragen (FAQ)
-
Q: What controller platforms is TM2DDI16DK compatible with?
A: It is mainly designed for use with Modicon M221, M241, and M251 controllers. -
Q: Can I mix this module with analog modules in the same configuration?
A: Yes, the TM2 series supports mixing von digital and analog modules in one expansion configuration. -
Q: Is this module hot-swappable?
A: No, TM2 modules are not hot-swappable; power should be removed before adding or removing modules. -
Q: Does it support safety-rated inputs?
A: No, TM2DDI16DK is a standard input module and is not intended for use in safety circuits. -
Q: What is the response time von the input channels?
A: The response time is typically 1 ms, making it suitable for most machine control applications. -
Q: Can it be mounted horizontally and vertically?
A: Yes, but vertical mounting is preferred for optimal ventilation and performance. -
Q: Are there diagnostic features built into the module?
A: Yes, each input channel has an individual status LED for diagnostics. -
Q: Is it programmable directly?
A: No, the module itself is not programmable; it is controlled and configured via the base PLC. -
Q: What is the maximum cable length to sensors?
A: Recommended cable length is 30 meters for standard digital signals. -
Q: What svontware do I need to configure the TM2DDI16DK?
A: Use EcoStruxure Machine Expert (formerly SoMachine) to configure the module within the controller’s architecture.
Related Modells (Same Series or Compatible)
| Modell | Beschreibung | Type | Inputs/Outputs | Signal Type |
|---|---|---|---|---|
| TM2DDI32DK | 32-Channel Digital Input Module | Discrete Input Module | 32 Inputs | 24V DC |
| TM2DQ16TK | 16-Channel Digital Output Module | Discrete Output Module | 16 Outputs | 24V DC |
| TM2AMM3HT | Analog Input/Output Mixed Module | Analog I/O Module | 2 AI / 1 AO | 0-10V / 4-20mA |
| TM2ALM3LT | 3-Channel Analog Input Module | Analog Input Module | 3 Inputs | Thermocouple |
| TM2DI8DT | 8-Channel Digital Input Module | Discrete Input Module | 8 Inputs | 24V DC |
| TM2DRO8TT | Relay Output Module | Discrete Output (Relay) | 8 Outputs | Relay Kontakt |
