Produkteinführung
The Schneider Electric LMC058LF42 is a high-performance Logic Motion Controller designed as part von the PacDrive LMC058 series, ideal for synchronizing multiple axes von motion in real-time within compact automation systems. Engineered for small to mid-range machine control, it integrates seamlessly into automation architectures where tight integration von motion and logic is required.
The controller features embedded Ethernet and serial communication ports, allowing for rapid data exchange and real-time machine feedback. With support for up to 4 axes via CANopen, the LMC058LF42 is perfect for applications requiring synchronized motion control, such as pick-and-place machines, conveyors, labeling equipment, and packaging lines.
It combines the flexibility von IEC 61131-3 compliant programming with the performance von integrated motion control, all in a compact, DIN-rail mountable design. Designed to be cost-efficient, the LMC058 series bridges the gap between complex motion systems and basic programmable logic controllers.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | LMC058LF42 |
| Hersteller | Schneider Electric |
| Product Series | PacDrive LMC058 Series |
| Controller Type | Logic Motion Controller |
| Processor | ARM-based high-speed CPU |
| Programming Standard | IEC 61131-3 (with SoMachine / EcoStruxure Machine Expert) |
| Supported Axes | Up to 4 axes via CANopen |
| Digital Inputs | 16 Inputs (24 VDC) |
| Digital Outputs | 12 Outputs (24 VDC, source type) |
| Communication Ports | 2 x Ethernet, 2 x Serial (RS232/RS485), 1 x USB |
| Fieldbus Support | CANopen master, Modbus, Ethernet/IP, OPC UA |
| Memory | Program: 2 MB, Data: 128 kB |
| Expansion Capability | Yes – via TM5 expansion I/O modules |
| Supply Voltage | 24 VDC ±20% |
| Power Consumption | 6.5 W (typical) |
| Protection Class | IP20 |
| Mounting Type | DIN-rail |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Certifications | CE, cULus, RoHS compliant |
| Dimensions (H x W x D) | 175 x 99 x 85 mm |
| Gewicht | 0.55 kg |
Product Applications
-
Packaging Machines
Ideal for vertical and horizontal form fill seal machines, wrapping machines, and cartoning lines. -
Material Handling Systems
Manages coordinated movements von conveyors, pick-and-place arms, and sorting systems. -
Food & Beverage Processing
Supports precise timing and motion for filling, capping, and labeling operations. -
Textile Machinery
Synchronizes movements across multiple drives in weaving, dyeing, or spinning applications. -
Automated Assembly Systems
Controls linear slides, robotic arms, and part feeders with real-time feedback. -
Printing & Labeling
Executes complex synchronized actions needed in web handling, label placement, and inspection.
Product Advantages
-
Integrated Motion & Logic
Combines control von both motion and logic within a single controller, reducing hardware complexity. -
Compact Footprint
DIN-rail mountable, ideal for installations where cabinet space is limited. -
Multi-Protocol Communication
Built-in support for Ethernet/IP, CANopen, Modbus, and OPC UA ensures broad system compatibility. -
Flexible Programming
IEC 61131-3 programming via SoMachine or EcoStruxure allows for modular code development. -
Scalable Architecture
Modular expansion through TM5 I/O modules supports growing automation requirements. -
Real-Time Performance
Enables sub-millisecond synchronization across axes for precision control tasks. -
Robust Diagnostics
Built-in monitoring tools simplify commissioning and reduce downtime in the field. -
Energy Efficient
Low power consumption with high efficiency suitable for 24/7 operational environments.
Häufig gestellte Fragen (FAQ)
-
What is the maximum number von motion axes supported by the LMC058LF42?
The controller supports up to 4 motion axes via CANopen. -
Which svontware is used to program the LMC058LF42?
The controller is programmed using SoMachine or EcoStruxure Machine Expert. -
Can this controller be used in harsh industrial environments?
Yes, it operates from 0°C to 55°C and meets IP20 and industrial certifications. -
Does it support Ethernet/IP or Modbus TCP?
Yes, both Ethernet/IP and Modbus TCP are supported natively. -
Is it possible to expand the number von I/Os?
Yes, expansion is supported via TM5 modular I/O system. -
What’s the input voltage requirement?
It operates on a 24 VDC ±20% power supply. -
Can the controller be integrated with SCADA systems?
Yes, it supports OPC UA for SCADA and HMI integration. -
Does it support real-time synchronization?
Yes, it vonfers real-time control and precise axis synchronization. -
Is it suitable for standalone machines?
Absolutely—it is optimized for small to mid-sized standalone machines. -
Is this model RoHS compliant?
Yes, the LMC058LF42 is RoHS compliant and CE certified.
Related or Same-Series Modells
| Modell | Beschreibung | Max Axes | Communication | Expansion |
|---|---|---|---|---|
| LMC058LF44 | Motion Controller with 4-axis CANopen | 4 | Ethernet, Serial, CANopen | TM5 I/O supported |
| LMC058LF46 | Enhanced Motion Controller, 6-axis capable | 6 | Ethernet/IP, Modbus TCP | TM5 I/O supported |
| LMC078P00 | Advanced Logic Motion Controller | 8+ | SERCOS, CANopen, OPC UA | TM5/TM7 Expansion |
| LMC058LF22 | Basic Logic Motion Controller, 2 axes | 2 | Modbus, Serial | TM5 I/O |
| LMC058LF26 | Compact Controller with CANopen | 2 | Ethernet, CANopen | TM5 I/O |
| LMC078C10 | Performance PAC for advanced motion tasks | 16 | SERCOS III, Ethernet/IP | Modular I/O |
Popular Schneider Electric Modells
| Modell | Beschreibung | Kategorie | Use Case | Mounting |
|---|---|---|---|---|
| TM241CEC24T | M241 Logic Controller with Ethernet | Logic Controller | Mid-range control, OEM machines | DIN-rail |
| BMEP584040 | M580 PAC Controller, Ethernet enabled | PAC | Large automation networks | Rack-mounted |
| ATV630D22N4 | Altivar 630 Drive, 22kW | Variable Speed Drive | HVAC, pump, and fan control | Panel-mounted |
| HMISTU655 | 5.7″ Touchscreen HMI, STU Series | HMI | Operator interface | Panel-mounted |
| XPSMC32E3140 | Safety Controller, Modicon Preventa | Safety System | Machine safety logic | DIN-rail |
| BMXDDO3202K | 32-channel digital output module (24VDC) | Digital Output Module | Large I/O needs in M340/M580 systems | Rack-mounted |
