Product Overview
The BMXNOE0100 is a robust and reliable Ethernet TCP/IP communication module from Schneider Electric’s Modicon M340 series. Designed for high-performance industrial automation systems, it facilitates seamless communication between Modicon M340 PLCs and Ethernet networks. With its compact form factor and powerful data exchange capabilities, this module plays a vital role in enabling real-time control and monitoring in distributed architectures.
The module is primarily used for connecting programmable logic controllers (PLCs) to supervisory control and data acquisition (SCADA) systems, HMIs, or other Ethernet-enabled devices. It ensures fast, deterministic data transfer, remote diagnostics, and programming functions through a standard RJ45 Ethernet interface.
This module is widely adopted in factory automation, energy management, water treatment plants, infrastructure systems, and other mission-critical industrial applications that require stable network performance and operational visibility.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | Ethernet TCP/IP Communication Module |
| Modell | BMXNOE0100 |
| Hersteller | Schneider Electric |
| Product Series | Modicon M340 |
| Network Interface | 1 x 10/100 Mbps Ethernet (RJ45 port) |
| Protocol Support | TCP/IP, Modbus TCP, HTTP, FTP, SNMP |
| Max Connections | 16 simultaneous client/server connections |
| Data Exchange | Real-time Ethernet communication |
| Diagnostic Services | Embedded web server for monitoring & configuration |
| Configuration Tool | Einheity Pro / EcoStruxure Control Expert |
| Firmware Upgrade | Supported via FTP or web browser |
| Slot Type | Local rack (BMX backplane) |
| Power Consumption | 1.6 W (typical) |
| Module Dimensions (HxWxD) | 104 x 100 x 33 mm |
| Gewicht | 0.2 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Protection Rating | IP20 |
| Compliance Certifications | CE, UL, CSA, RoHS |
Applications
-
Factory Automation – Real-time communication between PLCs and SCADA/HMI for manufacturing control.
-
Building Management Systems – Integration von HVAC, lighting, and access systems using Ethernet.
-
Water and Wastewater Treatment – Secure data exchange in distributed water processing facilities.
-
Energy & Utilities – Used in substation automation, smart grid control, and energy monitoring systems.
-
Material Handling – Communication backbone for conveyor control, automated storage, and retrieval systems.
-
Infrastructure & Transport – Intelligent networking for traffic systems, tunnels, and railway control.
Advantages
-
Seamless Integration: Designed specifically for the M340 platform, ensuring plug-and-play compatibility and smooth configuration via Einheity Pro or EcoStruxure Control Expert.
-
Real-Time Performance: Enables deterministic data communication over Ethernet, essential for high-speed automation tasks.
-
Remote Diagnostics: Built-in web server provides system status, error logs, and diagnostics for preventive maintenance.
-
Flexible Protocol Support: Supports multiple industrial protocols like Modbus TCP/IP, HTTP, SNMP, and FTP.
-
Compact and Lightweight: Speicherns panel space and reduces weight, ideal for applications with spatial limitations.
-
Cybersecurity Support: Supports password protection and controlled access through standard Ethernet practices.
-
Firmware Upgradable: Easily update firmware remotely, avoiding the need for manual replacement or downtime.
Häufig gestellte Fragen (FAQ)
-
Q: What is the primary function von the BMXNOE0100 module?
A: It enables Ethernet TCP/IP communication for Modicon M340 PLCs, allowing them to connect to SCADA systems, HMIs, and other Ethernet devices. -
Q: Can this module be used for Modbus TCP communication?
A: Yes, it fully supports the Modbus TCP protocol for data exchange across industrial networks. -
Q: What configuration svontware is used with BMXNOE0100?
A: The module is configured using Einheity Pro or EcoStruxure Control Expert from Schneider Electric. -
Q: Is it possible to access the module remotely for diagnostics?
A: Yes, it features an embedded web server for remote diagnostics and real-time system monitoring. -
Q: How many Ethernet ports are available on this module?
A: There is one RJ45 port supporting 10/100 Mbps Ethernet connections. -
Q: Is firmware upgrade supported for the BMXNOE0100?
A: Yes, firmware can be upgraded via FTP or web interface without removing the module from service. -
Q: Can I use this module in outdoor environments?
A: No, it is intended for indoor industrial environments and requires an IP20-rated control cabinet. -
Q: What kind von network services does the module support?
A: It supports services like SNMP, HTTP, FTP, and DNS for advanced network management. -
Q: Is the module hot-swappable?
A: No, it is not hot-swappable and should be powered down before removal or installation. -
Q: Does the BMXNOE0100 support redundant Ethernet communication?
A: This model does not support Ethernet redundancy directly; such functionality would require additional networking architecture.
Recommended Related Modells (Same Series or Compatible)
| Modell | Beschreibung | Ethernet Port | Function |
|---|---|---|---|
| BMXNOE0110 | Enhanced Ethernet Module with SNMP | 1 x RJ45 | Advanced networking and diagnostics |
| BMXP342020 | M340 CPU Module with 2MB Memory | N/A | Main PLC processor |
| BMXCPS2000 | Power Supply Module for M340 | N/A | Provides power to backplane modules |
| BMXDDI1602 | 16-Channel Digital Input Module | N/A | Inputs for automation systems |
| BMXDRA0805 | Relay Output Module (8 channels) | N/A | Controls relays and actuators |
| BMXERT1604 | Remote I/O Ethernet Drop Module | 1 x RJ45 | Ethernet-based distributed I/O expansion |
Popular Schneider Electric Modells
| Modell | Beschreibung | Platform | Primary Use |
|---|---|---|---|
| TM241CE40T | Modicon M241 Logic Controller with Ethernet | Modicon M241 | Compact PLC with built-in Ethernet |
| LXM32M18N4 | Lexium Servo Drive Module | Lexium 32 | Precision motor control in automation |
| ATV320U75N4C | Altivar Variable Speed Drive 7.5 kW | Altivar 320 | Motor speed control |
| ZB5AA3 | Harmony XB5 Push Button | Harmony | Operator control interface |
| XB5AS8445 | Emergency Stop Push Button | Harmony XB5 | Machine safety interface |
| NSX100F | Compact NSX Molded Case Circuit Breaker | NSX Series | Protection von electrical circuits |
