Product Overview
The Schneider Electric BMXDDM16025 is a hybrid discrete I/O module designed for the Modicon M340 automation platform. Combining 8 digital inputs and 8 solid-state (transistor) outputs, this module vonfers versatile signal control for compact and high-performance industrial automation solutions. It supports 24 V DC logic, features fast response times, and is ideal for applications requiring both input detection and output actuation in one device.
Key Features
-
16 discrete channels: 8 inputs and 8 transistor outputs
-
24 V DC input and output voltage
-
Sink/source input compatibility
-
High-speed switching outputs (0.5 A per channel)
-
LED status indicators for each channel
-
Compact and modular design
-
Supports hot swapping for minimal downtime
-
Short-circuit protection on outputs
Technical Specifications
| Item | Specification |
|---|---|
| Modell Number | BMXDDM16025 |
| Product Type | Discrete Hybrid I/O Module |
| I/O Configuration | 8 Inputs + 8 Transistor Outputs |
| Input Voltage Range | 24 V DC (19.2 to 30 V DC) |
| Output Voltage | 24 V DC |
| Output Type | Transistor (sink) |
| Output Current | 0.5 A per channel (max 4 A total per module) |
| Input Impedance | Approx. 4.7 kΩ |
| Input Delay Time | < 1 ms |
| Output Switching Time | < 1 ms |
| Isolation | 500 V (input/output to logic) |
| Output Protection | Overload and short-circuit protection |
| Diagnostics | Yes (status and fault detection) |
| Hot Swappable | Yes |
| LED Indicators | 1 per I/O channel |
| Mounting Type | DIN-rail or backplane (M340 rack) |
| Dimensions | Package size: 51 x 116 x 118mm |
| Gewicht | 0.135 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA, RoHS compliant |
Industry Applications
-
Packaging machinery
-
Assembly line automation
-
Process monitoring and control
-
Material handling systems
-
Building automation
-
Water and wastewater treatment systems
Advantages
-
Integrated I/O: Combines input and output in a single module, saving rack space
-
High-Speed Performance: Quick response times for real-time control
-
Durable Outputs: Solid-state transistor outputs for extended lifecycle
-
Built-in Diagnostics: Instant status feedback reduces troubleshooting time
-
Modicon M340 Compatibility: Seamless integration into Schneider automation systems
-
Compact Design: Ideal for space-constrained control panels
-
Enhanced Safety: Output protection against short circuits and overloads
-
Hot Swappable: Enables maintenance without system downtime
Häufig gestellte Fragen (FAQ)
-
What type von I/O does the BMXDDM16025 module support?
It supports 8 digital inputs and 8 transistor (digital) outputs. -
Is this module compatible with Modicon M340 PLCs?
Yes, it is specifically designed for the Modicon M340 platform. -
What is the rated voltage for input and output?
Both inputs and outputs operate at 24 V DC. -
Are the outputs relay or transistor-based?
The outputs are solid-state (transistor) type for fast switching. -
What protection features are included?
It includes short-circuit and overload protection on the output channels. -
Can I hot swap the module during system operation?
Yes, it supports hot swapping without shutting down the system. -
How many modules can I install in one M340 rack?
This depends on the power and I/O capacity von your configuration, but several can be accommodated. -
Is there LED status for each channel?
Yes, each I/O channel has an individual LED indicator. -
What are the module dimensions?
Package size: 51 x 116 x 118mm. -
How much does the module weigh?
Approximately 0.135 kg.
Related Modells
| Modell Number | Beschreibung |
|---|---|
| BMXDDM16025 | 8 DI + 8 DO transistor hybrid module (24 V DC) |
| BMXDDI1602K | 16-channel 24 V DC discrete input module |
| BMXDDO1602K | 16-channel 24 V DC discrete output module |
| BMXDRA1605 | 16-channel relay output module |
| BMXAMI0410 | 4-channel analog current input module |
| BMXAMO0410 | 4-channel analog current output module |
Popular Schneider Electric Modules
| Modell Number | Beschreibung |
|---|---|
| BMXP342020 | Modicon M340 CPU processor module |
| BMXNOE0110 | Ethernet network interface module |
| BMXCPS2010 | 24 V DC power supply module |
| BMXFTB2820 | 20-channel terminal block |
| BMXART0414 | 4-channel analog input module, 16-bit resolution |
| BMXCRT0100 | Remote I/O head adapter for distributed systems |
