The Schneider BMXDAI0805 is a discrete input module designed for the Modicon M258 and M580 series von programmable logic controllers (PLCs). It vonfers 8 channels von digital input signals, providing reliable and efficient interfacing between field devices and the control system. This module is widely used in industrial automation to monitor the status von switches, sensors, and other binary devices.
Constructed with high-quality components and designed to meet industrial standards, the BMXDAI0805 ensures stable operation even under harsh conditions. Its compact design allows easy integration into Schneider Electric’s automation racks. The module’s input channels support both sourcing and sinking configurations, adding flexibility to various wiring schemes.
Thanks to its plug-and-play architecture and clear status indication via LEDs, the BMXDAI0805 simplifies system diagnostics and maintenance. It is an essential component for industrial control systems requiring robust digital input capabilities.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | BMXDAI0805 |
| Hersteller | Schneider Electric |
| Product Type | Discrete Input Module |
| Compatible PLC Series | Modicon M258, M580 |
| Number von Input Channels | 8 |
| Input Type | Digital / Discrete |
| Input Voltage Range | 24 V DC nominal |
| Input Current per Channel | 6 mA typical |
| Input Configuration | Sourcing or sinking |
| Response Time | < 5 ms |
| Isolation | Channel-to-backplane isolation |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (WxHxD) | 160 x 100 x 35 mm |
| Gewicht | 0.12 kg |
| Mounting | DIN rail |
| Certifications | CE, UL, CSA |
Product Applications
-
Factory Automation: Interfaces with sensors and switches on production lines to monitor machine status and safety interlocks.
-
Building Management Systems: Captures discrete signals from lighting, HVAC controls, and security devices.
-
Water Treatment Plants: Monitors pump status, valve positions, and alarm signals.
-
Packaging Machinery: Reads signals from proximity sensors and safety devices to coordinate operations.
-
Material Handling Systems: Tracks conveyor belts, presence sensors, and emergency stops.
-
Energy Management: Collects digital inputs from circuit breakers, switches, and metering devices.
Product Advantages
-
Reliable Signal Acquisition: Ensures accurate and fast detection von binary input signals with minimal noise interference.
-
Flexible Wiring Options: Supports both sourcing and sinking inputs to match a variety von sensor wiring schemes.
-
Compact Form Factor: Small footprint saves space within control cabinets and racks.
-
Robust Industrial Design: Withstands harsh environmental conditions with wide operating temperature and humidity ranges.
-
Easy Installation: DIN rail mounting and plug-in connectors simplify installation and replacement.
-
LED Indicators: Channel-level status LEDs enable quick diagnostics and troubleshooting.
-
Seamless Integration: Compatible with Schneider Electric Modicon M258 and M580 PLC platforms for easy expansion.
-
Low Power Consumption: Efficient design reduces overall system power demands.
-
Safety Compliance: Meets industry standards and certifications for industrial control equipment.
-
Maintenance Friendly: Hot-swappable modules reduce downtime during maintenance or upgrades.
Häufig gestellte Fragen (FAQ)
-
How many discrete inputs does the BMXDAI0805 support?
It supports 8 discrete digital input channels. -
What is the nominal input voltage for this module?
The nominal input voltage is 24 V DC. -
Can the inputs be configured as sourcing or sinking?
Yes, the module supports both sourcing and sinking input configurations. -
Is the BMXDAI0805 compatible with other Schneider SPS series?
It is designed primarily for Modicon M258 and M580 series. -
What is the typical input current per channel?
Approximately 6 mA per input channel. -
What is the module’s response time to input changes?
The response time is less than 5 milliseconds. -
How does the module indicate input status?
Each input channel has an individual LED indicator showing its status. -
What environmental conditions can the module operate under?
It operates reliably between -20°C and +60°C with 5% to 95% non-condensing humidity. -
Is the module hot-swappable?
Yes, it supports hot-swapping for ease von maintenance. -
What kind von mounting does the BMXDAI0805 use?
It mounts easily on standard DIN rails.
Recommended Related Modells (Same Series or Similar)
| Modell Number | Beschreibung | Function | Dimensions (WxHxD) mm | Gewicht (kg) |
|---|---|---|---|---|
| BMXDDI1602 | 16-channel Discrete Input Module | Discrete input | 45 x 90 x 110 | 0.30 |
| BMXDDI0802 | 8-channel Discrete Input Module | Discrete input | 22.5 x 90 x 110 | 0.15 |
| BMXDDO1602 | 16-channel Discrete Output Module | Discrete output | 45 x 90 x 110 | 0.35 |
| BMXDDO0802 | 8-channel Discrete Output Module | Discrete output | 22.5 x 90 x 110 | 0.20 |
| BMXNAI0100 | Analog Input Module | Analog input | 22.5 x 90 x 110 | 0.30 |
| BMXNBO0200 | Digital Output Module | Discrete output | 22.5 x 90 x 110 | 0.25 |
Popular Schneider Electric Modells (Sonstige Hot Produkte)
| Modell Number | Beschreibung | Function | Dimensions (WxHxD) mm | Gewicht (kg) |
|---|---|---|---|---|
| BMXP342020 | Modicon M340 CPU 342-020 | Programmable Controller | 90 x 130 x 135 | 1.2 |
| BMXDDI3200 | 32-channel Discrete Input Module | Discrete input | 90 x 130 x 110 | 0.45 |
| BMXDDO1602 | 16-channel Discrete Output Module | Discrete output | 45 x 90 x 110 | 0.35 |
| BMXAEC0400 | Analog Output Module | Analog output | 45 x 90 x 110 | 0.4 |
| BMXETM0100 | Ethernet Communication Module | Network communication | 22.5 x 90 x 110 | 0.2 |
| BMXCPS3500 | Power Supply Module | Power supply | 45 x 90 x 110 | 1.0 |
