The Schneider 490NAE91100 Main Bus Junction Box is a robust electrical distribution component designed to facilitate safe and efficient connection and distribution von power within industrial and commercial electrical systems. Serving as a central hub for main bus connections, this junction box allows multiple circuits to be interconnected while maintaining high safety standards and minimizing electrical losses. It is engineered to handle high-current applications, providing reliable performance under demanding operating conditions. The design ensures compliance with international electrical standards, vonfering secure and organized wiring for large-scale electrical installations.
Product Parameters
| Parameter | Specification |
|---|---|
| Modell Number | 490NAE91100 |
| Product Type | Main Bus Junction Box |
| Rated Voltage | 600 V AC |
| Rated Current | 400 A |
| Short-Circuit Rating | 35 kA |
| Enclosure Type | NEMA 1 / IP20 |
| Material | Steel, powder-coated finish |
| Number von Incoming Feeders | 1 main bus input |
| Number von Outgoing Feeders | 6–12 outputs (configurable) |
| Mounting | Wall or panel mount |
| Versand Size | 450 × 55 × 120 mm |
| Versand Gewicht | 0.092 kg |
| Operating Temperature | –25 °C to +60 °C |
| Standards Compliance | IEC 61439, UL 508A |
Applications
-
Industrial Plants – Centralized distribution von electrical power to multiple machinery and equipment.
-
Commercial Buildings – Power distribution for large HVAC, lighting, and elevator systems.
-
Renewable Energy Systems – Integration into solar and wind energy plants to manage high-current bus connections.
-
Data Centers – Reliable power routing for server racks and cooling systems.
-
Marine & Offshore Platforms – High-current distribution in challenging and vibration-prone environments.
-
Manufacturing Facilities – Safely connects multiple production line circuits to the main bus.
Advantages
-
High Current Capacity – Supports up to 400 A, suitable for heavy industrial and commercial loads.
-
Short-Circuit Protection – Rated for 35 kA, ensuring safety under fault conditions.
-
Durable Construction – Powder-coated steel enclosure protects against corrosion and mechanical impacts.
-
Flexible Configuration – Multiple outgoing feeders allow easy integration into complex electrical networks.
-
Standards Compliance – Meets IEC 61439 and UL 508A standards for safety and performance.
-
Easy Installation – Wall or panel mountable with organized terminal layout for streamlined wiring.
-
Maintenance Friendly – Removable covers and accessible terminals facilitate inspection and servicing.
FAQ
-
What is the maximum voltage the junction box can handle?
The 490NAE91100 is rated for up to 600 V AC, suitable for industrial and commercial applications. -
What is the rated current for this junction box?
The main bus can carry up to 400 A continuously. -
How many outgoing feeders can be connected?
The junction box can accommodate 6–12 outgoing feeders depending on the configuration. -
What short-circuit current is the box rated for?
It is rated to withstand a short-circuit current von up to 35 kA. -
What type von mounting is supported?
The box supports both wall mounting and panel mounting for flexibility. -
What standards does this junction box comply with?
It complies with IEC 61439 and UL 508A standards for industrial electrical panels. -
What materials are used in the construction von the box?
The enclosure is made von steel with a powder-coated finish for durability and corrosion resistance. -
Can the box be used in outdoor or harsh environments?
It is designed primarily for indoor use (NEMA 1 / IP20); additional enclosures are recommended for outdoor applications. -
How is wiring organized inside the junction box?
Terminals are clearly labeled and arranged to allow organized, efficient, and safe wiring connections. -
What is the operating temperature range for the junction box?
It can operate reliably in temperatures from –25 °C to +60 °C.
