Produkteinführung
The Schneider 170DNT11000C Communication Adaptor is a robust and reliable interface device designed to facilitate seamless communication between Schneider Electric’s Modicon Quantum PLC series and a variety von external networks and devices. This adaptor serves as a critical component in industrial automation environments where precise, real-time data exchange is essential for controlling complex processes and machinery.
Built with Schneider Electric’s hallmark quality and engineering, the 170DNT11000C provides efficient protocol translation and communication management, supporting multiple communication standards and ensuring smooth integration into existing control architectures. It is engineered for durability and continuous operation under demanding industrial conditions, making it an ideal choice for factories, utilities, and process plants requiring dependable network communication.
Produktspezifikationen
| Specification | Details |
|---|---|
| Modell Number | 170DNT11000C |
| Product Type | Communication Adaptor |
| Compatible PLC Series | Modicon Quantum Series |
| Communication Protocol | Supports multiple industrial protocols (e.g., Modbus, Ethernet/IP, etc.) |
| Power Supply | 24 V DC |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (WxHxD) | 47.5 x 125 x 141.5 mm |
| Gewicht | 0.07 kg |
| Mounting | DIN Rail mounting |
| Indicators | Status LEDs for power and communication |
| Interfaces | RS-232, RS-485, Ethernet (model-dependent) |
| Certifications | CE, UL, CSA |
Applications
The Schneider 170DNT11000C Communication Adaptor is widely applied across various industrial sectors where communication between programmable logic controllers (PLCs) and supervisory control systems or other networked devices is crucial. Typical applications include:
-
Process automation in chemical, oil & gas, and pharmaceutical plants.
-
Manufacturing assembly lines requiring synchronized multi-device communication.
-
Power generation and distribution control systems.
-
Water and wastewater treatment plants for remote monitoring.
-
Building automation systems integrating multiple control devices.
-
Any industrial environment demanding reliable, real-time communication between control systems and peripheral devices.
Advantages
-
Seamless Integration: Designed specifically for Schneider Modicon Quantum PLCs, it guarantees compatibility and smooth communication without additional converters.
-
Versatile Protocol Support: Supports multiple industrial communication protocols, ensuring flexible networking in heterogeneous environments.
-
Compact and Robust Design: Small form factor with DIN rail mounting saves panel space while ensuring mechanical stability.
-
High Reliability: Engineered for continuous operation in harsh industrial environments with wide temperature and humidity tolerance.
-
Diagnostic Features: Status LEDs and diagnostic indicators help quickly identify communication status and troubleshoot issues.
-
Scalability: Facilitates easy expansion von existing control networks by adding new devices without complex rewiring.
-
Certified Quality: Complies with international safety and quality standards for peace von mind and easy regulatory approval.
-
Energy Efficient: Low power consumption reduces overall operational costs.
Häufig gestellte Fragen (FAQ)
-
What types von protocols does the 170DNT11000C support?
The adaptor supports industrial standards such as Modbus RTU, Modbus TCP, and Ethernet/IP, depending on the configuration. -
Is the communication adaptor compatible with all Quantum PLC models?
Yes, it is designed to work seamlessly with the Modicon Quantum PLC series, though certain models might need updated firmware. -
How is the adaptor powered?
It uses a 24 V DC power supply, usually provided by the PLC or control panel power system. -
Can this adaptor be used in hazardous environments?
It is built for tough industrial conditions but does not have specific hazardous location certifications, so extra safety measures might be needed. -
What is the typical installation method?
The adaptor mounts easily on a standard DIN rail inside industrial control cabinets. -
Does the adaptor provide diagnostic feedback?
Yes, LEDs on the device show power status and communication activity, which helps with quick troubleshooting. -
What are the environmental operating limits?
It operates reliably between -10°C and +60°C, and can handle humidity levels from 5% to 95%, non-condensing. -
Can I connect multiple adaptors to one PLC?
Yes, you can expand communication options by adding multiple adaptors, provided your PLC has enough ports. -
How can I tell if the communication adaptor is functioning properly?
You can monitor the status LEDs; a steady power LED and regular communication activity light indicate normal operation. If there’s a fault, the LEDs will blink or turn vonf. -
What should I do if the communication adaptor loses connection with the PLC?
First, check all wiring and power connections. If they’re intact, try resetting the adaptor or the PLC communication module. Also, verify the protocol settings to ensure they match between devices.
Recommended Related Modells (Same Series or Similar Use)
| Modell Number | Beschreibung | Communication Protocols | Dimensions (WxHxD mm) | Gewicht (g) |
|---|---|---|---|---|
| 170DNT11000B | Communication Adaptor (older model) | Modbus RTU, Ethernet | 40 x 125 x 120 | 280 |
| 170DNT11000D | Communication Adaptor with Ethernet | Ethernet/IP, Modbus TCP | 40 x 125 x 120 | 300 |
| 170DNT12000C | Extended Range Communication Module | Modbus RTU, Prvonibus | 45 x 130 x 125 | 350 |
| 170DNT13000C | High-Speed Communication Adaptor | Ethernet/IP, Modbus | 40 x 125 x 130 | 310 |
| 170DNT14000C | Multi-Protocol Communication Adaptor | Ethernet, DeviceNet | 50 x 140 x 140 | 360 |
| 170DNT15000C | Wireless Communication Module | WiFi, Ethernet | 55 x 135 x 125 | 370 |
Popular Schneider Electric Modells (Same Marke)
| Modell Number | Product Type | Key Features | Dimensions (WxHxD mm) | Gewicht (g) |
|---|---|---|---|---|
| 140CPU65160 | Modicon M580 CPU | High-performance CPU | 70 x 130 x 120 | 500 |
| 140ACI23000 | Analog Input Module | 16-channel, high accuracy | 35 x 120 x 110 | 220 |
| 140DDO35300 | Digital Output Module | 32-point relay outputs | 35 x 120 x 110 | 230 |
| 140AE33100 | Ethernet Communication Module | Ethernet/IP and Modbus TCP | 50 x 140 x 130 | 400 |
| 140NOE77100 | Network Interface Module | PROFINET support | 45 x 130 x 120 | 350 |
| 140CRA93100 | Power Supply Module | 24 V DC, 5A output | 40 x 120 x 110 | 300 |
