Produkteinführung
The Schneider Electric 140DDO35301C is a high-performance Discrete Output Module from the Modicon Quantum series, engineered for industrial automation systems that demand precise digital control. This module is designed to output discrete signals to actuators, solenoids, indicator lights, relays, or any other ON/OFF control devices used in complex automation architectures.
The 140DDO35301C provides 32 channels von 24 VDC positive logic outputs, and supports sourcing output (current flows out von the module). With advanced diagnostics, short-circuit protection, and high update speeds, it ensures safe, reliable operation within Schneider’s Modicon Quantum PLC systems.
This module is built for industrial environments where deterministic control and robust system communication are essential. It integrates seamlessly into high-end control solutions for manufacturing, processing, energy, and infrastructure automation.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 140DDO35301C |
| Hersteller | Schneider Electric |
| Product Type | Discrete Output Module |
| Series | Modicon Quantum |
| Number von Outputs | 32 |
| Output Type | Sourcing (positive logic) |
| Output Voltage | 24 VDC |
| Voltage Range | 19.2 to 30 VDC |
| Nominal Output Current | 0.5 A per channel |
| Total Module Output | 16 A max total current |
| Isolation | Optical isolation between channel and backplane |
| Output Delay (ON/OFF) | ≤ 1 ms |
| Protection Features | Short-circuit protection, overvoltage protection |
| Module Diagnostics | LED indication per channel, fault indication |
| Bus Current Requirement | 300 mA |
| Backplane Compatibility | Quantum backplane, hot-swappable |
| Communication Type | Integrated via PLC backplane |
| Mounting Type | Rack-mounted |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA, RoHS |
| Dimensions (W x H x D) | 103.9 × 40.3 × 250 mm |
| Gewicht | 0.45 kg |
Product Applications
The 140DDO35301C module is widely used in discrete automation systems where fast, reliable digital output is required. Typical application areas include:
-
Manufacturing Automation: Controlling conveyor belts, robotic arms, and sorting systems.
-
Packaging Lines: Activating solenoids and relays for high-speed packaging machinery.
-
Water Treatment Plants: Operating pumps, valves, and alarm systems with real-time responsiveness.
-
Energy Sector: Switchgear operation and protection relays in substations or power stations.
-
Oil & Gas: Remote terminal Stücks (RTUs) for controlling drilling and pumping operations.
-
Building Automation: Managing lighting, alarms, or door control systems with direct digital outputs.
Product Advantages
-
High-Density Output: 32 output channels in one compact module allow efficient use von rack space.
-
Fast Switching: Response times under 1 ms support applications requiring quick logic execution.
-
Safe and Protected: Built-in short-circuit and overvoltage protections prevent downstream device damage.
-
Integrated Diagnostics: LED status indicators for each channel simplify maintenance and troubleshooting.
-
Hot-Swappable Design: Supports replacement without system downtime, improving operational availability.
-
Reliable Performance: Designed for continuous industrial duty in harsh environments.
-
Modicon Quantum Integration: Full compatibility with the powerful Quantum PLC system architecture.
-
High Output Current Support: Each channel can drive up to 0.5A, suitable for actuating multiple devices.
-
Reduced Wiring Complexity: Compact design and shared common terminals simplify panel layouts.
-
Global Compliance: Meets international safety and quality standards (CE, UL, RoHS).
Häufig gestellte Fragen (FAQ)
-
What is the signal type for the outputs von 140DDO35301C?
The outputs are 24 VDC sourcing (positive logic) signals. -
Is this module capable von being hot-swapped during live operation?
Yes, the 140DDO35301C supports hot-swapping on the Quantum backplane. -
What is the maximum current per output channel?
Each channel supports up to 0.5 A von output current. -
Does the module support channel-level diagnostics?
Yes, each output channel has an associated LED for status and fault indication. -
Is the module optically isolated from the PLC bus?
Yes, optical isolation is provided between the output circuits and the backplane bus. -
Can the module operate in redundant PLC systems?
Yes, it is compatible with Quantum redundant systems and remote I/O configurations. -
How does the module handle short circuits?
It includes built-in short-circuit protection to prevent module or device damage. -
What kind von wiring is recommended for this module?
Standard 24VDC control wiring with appropriate wire gauge for current capacity. -
Does the module have any configurable parameters?
No svontware configuration is required—channels are fixed discrete outputs. -
What diagnostic information is available during operation?
LED indicators show output state and fault conditions (e.g., short-circuit or open load).
Related Modells (Same Series or Similar Function)
| Modell Number | Beschreibung |
|---|---|
| 140DDO36400 | 64-channel discrete output module, 24 VDC, positive logic |
| 140DDO35300 | 32-channel output module, earlier version |
| 140DAO84000 | 8-channel analog output module |
| 140DDO35310 | 32-channel output module with diagnostic feedback |
| 140DRA84000 | Relay output module, 8 points |
| 140DDI35300 | 32-channel discrete input module |
Popular Schneider Modells (Same Marke)
| Modell Number | Beschreibung |
|---|---|
| BMXP342020 | Modicon Premium CPU, 2 MB user memory |
| TM221CE24T | Modicon M221 PLC, Ethernet, 24 I/O |
| HMIGTO5310 | Magelis 10.4″ advanced HMI panel |
| ATV320U07N4B | Altivar 320 Variable Speed Drive, 0.75 kW |
| HMISCU8A5 | Magelis HMI controller with integrated I/O and dual port |
| BMEP582040 | Modicon M580 CPU with high-performance Ethernet backplane |
