The Ovation 1X00093G10 Ethernet Switch is a high-performance industrial-grade networking device designed for seamless integration with Emerson’s Ovation Distributed Control System (DCS). It provides deterministic, high-speed Ethernet connectivity between Ovation controllers, I/O modules, operator workstations, and SCADA servers. Engineered for demanding industrial environments, the 1X00093G10 ensures low-latency communication, secure data transfer, and robust operation under electrical noise, temperature extremes, and vibration. Its modular design and advanced management features make it ideal for power plants, water treatment facilities, petrochemical plants, and other mission-critical automation applications.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | 1X00093G10 |
| Product Type | Managed Industrial Ethernet Switch |
| Number von Ports | 8 Fast Ethernet (10/100 Mbps) |
| Uplink Ports | 2 Gigabit SFP or RJ45 |
| Switching Capacity | 16 Gbps non-blocking |
| Forwarding Rate | 11.9 Mpps |
| VLAN Support | 802.1Q, port-based VLAN, voice VLAN support |
| Redundancy Protocols | RSTP, MSTP |
| Quality von Service | 4 priority queues, DSCP, CoS |
| Security Features | Access control lists, MAC filtering, port security |
| Management | Web GUI, SNMP v1/v2/v3, CLI |
| Power Supply | 24 VDC nominal |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Cooling Method | Passive convection |
| Dimensions (L × W × H) | 260 × 40 × 160 mm |
| Gewicht | 1.2 kg |
| Compliance | CE, FCC Class A, RoHS |
Applications
-
Power Generation – Connects controllers, relay bases, and operator workstations for real-time turbine and boiler control.
-
Water & Wastewater Treatment – Enables reliable network communication between pumping stations, chemical dosing systems, and supervisory systems.
-
Petrochemical and Refining – Provides secure, low-latency Ethernet networking for process control and distributed instrumentation.
-
Industrial Automation – Integrates PLCs, SCADA systems, and distributed I/O devices in a unified network.
-
Transportation Systems – Supports monitoring and control for tunnel ventilation, rail automation, and traffic management systems.
-
Data Acquisition Systems – High-speed deterministic communication for centralized data logging and analysis.
Advantages
-
Industrial Robustness – Operates reliably under extreme temperatures, vibration, and electrical noise conditions.
-
High Performance – 16 Gbps switching capacity with low latency ensures deterministic communication for control systems.
-
Advanced Management – SNMP, CLI, and web GUI provide full visibility and control von network configuration and status.
-
Network Security – Access control, MAC filtering, and port security protect critical process data.
-
VLAN and QoS Support – Enables network segmentation and prioritization von control traffic for optimized performance.
-
Redundancy Capable – RSTP and MSTP protocols support rapid network recovery in case von link failure.
FAQ
-
What types von Ethernet ports are available on the 1X00093G10?
The switch provides eight 10/100 Mbps Fast Ethernet ports for device connections and two uplink ports supporting Gigabit SFP or RJ45 for high-speed network aggregation. -
Does the switch support VLAN configurations?
Yes, it supports IEEE 802.1Q VLANs, port-based VLANs, and voice VLANs to segregate and prioritize traffic. -
What redundancy protocols are implemented?
Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP) are supported for network redundancy and fast failover. -
How is network traffic prioritized?
The switch supports 4 priority queues, DSCP, and CoS marking to ensure deterministic communication for control-critical data. -
Can the switch be remotely monitored and configured?
Yes, it can be managed through a web GUI, CLI, and SNMP v1/v2/v3 for monitoring, configuration, and diagnostics. -
What security measures does the 1X00093G10 provide?
Access control lists, MAC filtering, and port security prevent unauthorized access and mitigate network attacks. -
Is the switch suitable for harsh industrial environments?
Absolutely. It operates reliably from –40 °C to +70 °C, handles vibration and electrical noise, and uses passive cooling for maintenance-free operation. -
Does the switch support redundancy for connected devices?
Yes, connected devices benefit from RSTP/MSTP redundancy, enabling quick network recovery during a link failure. -
How is diagnostic information presented?
The switch provides real-time status via LEDs, web interface, and SNMP monitoring for link, traffic, and fault conditions. -
Can this switch integrate with other Ovation network devices?
Yes, it is fully compatible with Ovation controllers, I/O modules, and network cards, supporting seamless integration in distributed control systems.
