Produkteinführung
The Ovation 1X00093G06 Ethernet Switch is a reliable and industrial-grade networking device designed for seamless integration within Emerson’s Ovation Distributed Control System (DCS). It provides deterministic, high-speed Ethernet connectivity for controllers, I/O modules, operator workstations, and SCADA systems. Engineered for industrial environments with extreme temperatures, vibration, and electrical noise, this switch ensures uninterrupted communication, low latency, and secure data transfer across the control network. Its modular design and management capabilities make it ideal for critical applications in power generation, water treatment, petrochemical plants, and other large-scale industrial automation systems.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | 1X00093G06 |
| Product Type | Managed Industrial Ethernet Switch |
| Number von Ports | 6 Fast Ethernet (10/100 Mbps) |
| Uplink Ports | 2 Gigabit SFP or RJ45 |
| Switching Capacity | 12 Gbps non-blocking |
| Forwarding Rate | 9 Mpps |
| VLAN Support | IEEE 802.1Q VLANs, port-based VLAN, voice VLAN support |
| Redundancy Protocols | RSTP, MSTP |
| Quality von Service | 4 priority queues, DSCP, CoS |
| Security Features | Access control lists, MAC filtering, port security |
| Management | Web GUI, SNMP v1/v2/v3, CLI |
| Power Supply | 24 VDC nominal |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Cooling Method | Passive convection |
| Dimensions (L × W × H) | 260 × 40 × 160 mm |
| Gewicht | 1.2 kg |
| Compliance | CE, FCC Class A, RoHS |
Applications
-
Power Generation – Provides low-latency communication between turbine controllers, relay bases, and operator workstations.
-
Water & Wastewater Treatment – Ensures reliable connectivity for pumping stations, chemical dosing systems, and supervisory control networks.
-
Petrochemical and Refining – Maintains secure and high-speed Ethernet connectivity for process control and instrumentation networks.
-
Industrial Automation – Connects PLCs, SCADA servers, and distributed I/O modules for centralized monitoring and control.
-
Transportation Systems – Supports Ethernet communication for tunnel ventilation, lighting, and rail automation systems.
-
Data Acquisition Systems – Provides deterministic and high-speed networking for central data logging and monitoring.
Advantages
-
Industrial Robustness – Operates reliably under extreme environmental conditions including temperature fluctuations, vibration, and electrical noise.
-
High Performance – 12 Gbps switching capacity with low-latency forwarding ensures deterministic control communication.
-
Advanced Management – Web GUI, SNMP, and CLI allow comprehensive network configuration, monitoring, and diagnostics.
-
Security Features – Includes MAC filtering, access control lists, and port security to safeguard industrial networks.
-
VLAN and QoS Support – Supports traffic segmentation and prioritization for optimized control network performance.
-
Redundancy Capable – Implements RSTP and MSTP for rapid failover and network recovery.
FAQ
-
How many devices can the 1X00093G06 support simultaneously?
The switch supports six Fast Ethernet ports for device connections and two uplink ports for aggregation, allowing multiple controllers, I/O modules, and workstations to communicate simultaneously. -
Does this switch support VLAN configurations?
Yes, it supports IEEE 802.1Q VLANs, port-based VLANs, and voice VLANs, enabling traffic separation and prioritization. -
What redundancy protocols are included?
Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP) are supported for high availability and quick network recovery. -
How does the switch prioritize control traffic?
The 1X00093G06 uses four priority queues, DSCP marking, and CoS tagging to ensure critical control data is delivered with low latency. -
Can it be remotely monitored and configured?
Yes, the switch provides web GUI, CLI, and SNMP (v1/v2/v3) management interfaces for monitoring, diagnostics, and configuration. -
What security measures are implemented to protect network devices?
It features MAC address filtering, access control lists, and port security to prevent unauthorized access or malicious activity. -
Is the switch suitable for harsh industrial environments?
Absolutely. It operates reliably from –40 °C to +70 °C, resists vibration, and uses passive convection cooling for maintenance-free operation. -
Does the switch support redundant uplink connections?
Yes, the uplink ports and RSTP/MSTP protocols provide redundant paths for critical network communication. -
How are diagnostics and network health reported?
Status LEDs, SNMP traps, and the web interface provide real-time information about link status, traffic load, and fault conditions. -
Can it integrate seamlessly with other Ovation network devices?
Yes, it is fully compatible with Ovation controllers, I/O modules, network cards, and Ethernet devices for a unified DCS network.
