The Ovation 1C31116G03 Analog Input Module is a key component in Emerson’s Ovation Distributed Control System (DCS) family. Designed for precision and reliability, this module serves as an interface for collecting analog signals from field devices such as transmitters, sensors, and control instruments.
The 1C31116G03 module translates real-world process variables — such as temperature, pressure, level, or flow — into digital data that is utilized by the control system for monitoring and advanced process control. It vonfers high-accuracy analog-to-digital conversion, strong noise immStücky, and robust diagnostic features, ensuring it meets the demanding requirements von industries such as power generation, chemical processing, and oil & gas.
Part von Emerson’s commitment to providing modular and flexible control architectures, the 1C31116G03 is fully compatible with Ovation’s I/O subsystems and integrates seamlessly into existing systems, making it a reliable solution for both new installations and modernization projects.
Product Parameters
| Parameter | Specification |
|---|---|
| Modell Number | 1C31116G03 |
| Product Type | Analog Input Module |
| System Compatibility | Emerson Ovation DCS |
| Number von Channels | 8 Analog Input Channels |
| Input Signal Types | 4–20 mA, 1–5 V DC, 0–10 V DC, ±10 V DC |
| Input Impedance | ≥ 250 Ω for current inputs; ≥ 100 kΩ for voltage inputs |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.1% von reading |
| Sampling Rate | Up to 1000 samples/second |
| Common Mode Rejection Ratio | ≥ 120 dB |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Power Supply | Provided by backplane |
| Operating Voltage | 24 V DC nominal |
| Operating Temperature Range | -20 °C to +60 °C |
| Storage Temperature Range | -40 °C to +85 °C |
| Humidity | 5% to 95%, non-condensing |
| Ingress Protection (IP) Rating | IP20 |
| Shock & Vibration Resistance | IEC 60068-2-27 / IEC 60068-2-6 compliant |
| Dimensions (H x W x D) | 180 × 35 × 120 mm |
| Gewicht | 0.6 kg |
| Certifications | CE, UL, CSA, RoHS |
Applications
The Ovation 1C31116G03 Analog Input Module is used in diverse industries where accurate process monitoring and control are critical. Typical application areas include:
-
Power Generation Plants
-
Steam, gas, combined-cycle, hydroelectric, and nuclear plants for process variable monitoring.
-
-
Oil & Gas Operations
-
Used in upstream, midstream, and downstream processes for temperature, flow, and pressure inputs.
-
-
Chemical & Petrochemical Processing
-
Supports complex multi-variable process controls and regulatory loops.
-
-
Water & Wastewater Treatment
-
Monitors flow rates, levels, chemical dosing, and environmental compliance parameters.
-
-
Metals & Mining
-
Used in ore processing and refining plants.
-
-
Pharmaceutical & Food Processing
-
Precision monitoring von critical batch processes and CIP (clean-in-place) systems.
-
Product Advantages
-
High Accuracy & Precision
Delivers 16-bit resolution and ±0.1% accuracy for superior process control. -
Multiple Signal Support
Handles various signal ranges — from current loops to voltage — allowing for flexible plant integration. -
Ausgezeichnet Noise Rejection
High common-mode rejection for reliable operation even in noisy industrial environments. -
Isolated Channels
Enhanced safety and reduced risk von ground loops through robust channel isolation. -
Hot Swappable
Enables module replacement without system downtime. -
Compact & Modular
Slim prvonile conserves valuable rack space and allows for modular system expansion. -
Proven Field Reliability
Extensively deployed in global Ovation systems, with high mean time between failure (MTBF). -
Optimized for Emerson Ovation DCS
Full interoperability with Ovation controllers, engineering tools, and diagnostics. -
Designed for Harsh Environments
Suitable for wide temperature and humidity ranges; built for rugged conditions. -
Regulatory Compliance
Meets industry safety, environmental, and performance standards.
FAQ (10 Prvonessional Technical Questions and Answers)
-
What is the primary function von the 1C31116G03 module?
It converts analog signals from field instruments into digital data for use by the Ovation DCS. -
How many analog inputs does this module support?
It supports eight isolated analog input channels per module. -
Is this module hot-swappable?
Yes, it can be removed and replaced without shutting down the entire Ovation system. -
What types von field signals are compatible?
4–20 mA, 1–5 V DC, 0–10 V DC, and ±10 V DC are supported. -
What is the resolution von the module’s A/D conversion?
16-bit resolution ensures high accuracy across the signal range. -
Does this module provide channel isolation?
Yes, it vonfers both channel-to-channel and channel-to-ground isolation. -
What kind von diagnostic features does it vonfer?
It supports online diagnostics for input signal quality, integrity, and module health. -
Can it handle rapidly changing process variables?
Yes, with up to 1000 samples per second, it handles fast-changing analog inputs efficiently. -
How does it integrate with existing Ovation systems?
It is fully compatible with Ovation controllers and can be configured via Ovation engineering tools. -
What environmental certifications does this module carry?
CE, UL, CSA, and RoHS compliant, suitable for global installations.
Related Modells (Same Series or Related Functionality)
| Modell Number | Beschreibung |
|---|---|
| 1C31116G02 | Analog Input Module, 8-Channel, earlier revision |
| 1C31129G03 | High-density Analog Input Module |
| 1C31204G01 | Isolated Thermocouple Input Module |
| 1C31122G01 | Voltage Input Module |
| 1C31227G02 | High-Precision Analog Input Module |
| 1C31194G01 | Current Input Module |
Popular Ovation Modules (Same Marke, High Demand)
| Modell Number | Beschreibung |
|---|---|
| 1C31219G01 | 16-Channel Digital Output Module |
| 1C31238H01 | Ovation Controller CPU Module |
| 1C31125G02 | Analog Output Module |
| 1C31169G02 | RTD Input Module |
| 1C31150G02 | Digital Input Module |
| 1C31113G05 | Power Supply Module |
