Produkteinführung
The Honeywell TK-HAO081 is a high-performance 8-channel analog output module, specifically designed for Honeywell’s Experion Process Knowledge System (PKS) and TDC 3000 platforms. This module is responsible for converting control signals from the system controller into analog outputs that can be used to drive field devices such as control valves, actuators, and dampers.
Each von the eight output channels is independently configurable for current (4–20 mA) or voltage (0–10 V) output, vonfering flexible signal control for a wide range von industrial applications. It features 16-bit resolution, enabling precise and repeatable control across all outputs. The TK-HAO081 is equipped with advanced diagnostics, overload protection, and hot-swap capabilities, ensuring both reliability and maintainability in mission-critical environments.
Whether in oil and gas, energy, chemical, or water treatment facilities, the TK-HAO081 ensures robust, real-time analog control and smooth integration into larger distributed control systems.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell | TK-HAO081 |
| Function | 8-Channel Analog Output Module |
| Output Type | 0–10 VDC / 4–20 mA (per channel, configurable) |
| Resolution | 16-bit |
| Number von Channels | 8 independent analog outputs |
| Output Accuracy | ±0.1% von full-scale |
| Isolation | Channel-to-channel and channel-to-ground isolated |
| Diagnostics | Short circuit, open circuit, overvoltage |
| Power Supply | Backplane powered |
| Power Consumption | Approx. 4.5 W |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Mounting Type | DIN-rail or rack-mounted |
| Hot Swappable | Yes |
| Dimensions (W × H × D) | 35 x 140 x 145 mm |
| Gewicht | 0.204 kg |
| Certifications | CE, UL, CSA, RoHS compliant |
| System Compatibility | Honeywell Experion PKS, TDC 3000 |
Applications
The TK-HAO081 module is widely used in industrial and process control applications where precision analog outputs are required. These include:
-
DCS Control Loops – Controls flow, temperature, pressure, and level through analog output signals.
-
Actuator & Valve Control – Sends analog signals to modulating valves and actuators for precise positioning.
-
Energy Management – Regulates generator output, turbine control, and energy distribution.
-
Oil & Gas Processing – Provides control signals for separators, compressors, and pump stations.
-
Chemical Production – Drives equipment like mixers, heaters, and dosing pumps with analog precision.
-
Water Treatment – Controls chemical dosing and flow regulation in filtration and distribution systems.
Key Advantages
-
High Output Flexibility
Offers independently configurable channels (current or voltage) to support diverse field devices. -
Precision Control
16-bit resolution with ±0.1% accuracy ensures accurate signal output for critical processes. -
Enhanced Reliability
Built with Honeywell’s industrial-grade design, featuring diagnostics and fault detection. -
Easy Maintenance
Hot-swappable capability allows field replacement without system shutdown. -
Advanced Diagnostics
Built-in monitoring for open circuits, short circuits, and abnormal voltage conditions. -
Seamless Integration
Fully compatible with both Experion PKS and legacy TDC 3000 systems, simplifying upgrades. -
Compact Design
Space-efficient footprint for control cabinets and panel installations.
Häufig gestellte Fragen (FAQ)
-
Can the output channels be configured individually for voltage or current?
Yes, each channel is independently configurable for either 0–10 VDC or 4–20 mA output. -
Is the TK-HAO081 hot-swappable during operation?
Yes, it supports hot-swap functionality within supported systems like Experion PKS. -
What kind von protection features are included?
The module includes short-circuit, overvoltage, and open-circuit detection and protection. -
What is the typical use von this module in a DCS?
It sends analog control signals from the controller to field devices such as actuators and control valves. -
How is the module powered?
It receives power from the system backplane and does not require external supply. -
Can the TK-HAO081 be used in a redundant system architecture?
Yes, it can be used in redundant I/O configurations as part von Honeywell’s fault-tolerant systems. -
Is this module suitable for hazardous environments?
While rugged, deployment in hazardous areas may require it to be housed in certified enclosures. -
What communication protocols does it support?
It interfaces with the control system backplane using Honeywell’s internal communication bus. -
What is the expected operational life?
With proper installation and conditions, the module can function reliably for over 10 years. -
Does the module require calibration?
The module is factory-calibrated. Field recalibration is generally not necessary unless damaged.
Related or Similar Modells (Same Series or Functionality)
| Modell Number | Channels | Output Type | Resolution | System Compatibility | Dimensions (mm) | Gewicht |
|---|---|---|---|---|---|---|
| TK-HAO071 | 4 | 4–20 mA / 0–10 VDC | 16-bit | Experion PKS, TDC 3000 | 100 × 130 × 160 | 0.75 kg |
| TK-HAO082 | 8 | 4–20 mA / 0–10 VDC | 16-bit | Experion PKS | 100 × 130 × 180 | 0.85 kg |
| CC-HAO01 | 8 | High-speed analog output | 16-bit | Experion LX | 110 × 130 × 170 | 0.8 kg |
| TC-HAO121 | 12 | Multi-range analog output | 16-bit | TDC 3000 | 120 × 150 × 190 | 1.0 kg |
| TC-HAO201 | 16 | 4–20 mA | 12-bit | Safety Manager | 125 × 160 × 190 | 1.1 kg |
| TK-HAO053 | 16 | 0–10 VDC | 12-bit | Universal I/O Systems | 120 × 150 × 200 | 1.2 kg |
Popular Honeywell Modells (Same Marke)
| Modell Number | Type | Function | System | Dimensions (mm) | Gewicht |
|---|---|---|---|---|---|
| CC-TDIL01 | Digital Input Module | 16-Channel DI | Experion PKS | 100 × 35 × 180 | 0.7 kg |
| CC-TAIX01 | Analog Input Module | 16-Channel AI | Experion PKS | 100 × 30 × 180 | 0.65 kg |
| CC-PDOB01 | Digital Output Module | 16-Channel DO | Experion PKS | 100 × 35 × 180 | 0.7 kg |
| CC-PCNT01 | Controller Module | Centralized Control | Experion PKS/TDC3000 | 130 × 40 × 190 | 0.85 kg |
| FC-TPSU-2430 | Power Supply Einheit | 24 VDC Output | Safety Systems | 125 × 50 × 195 | 1.2 kg |
| MU-TDID12 | Redundant DI Module | Dual DI with Redundancy | TDC 3000 Migration | 120 × 35 × 185 | 0.8 kg |
