Product Overview
The Honeywell TC-IDJ161 is an Isolated Discrete Input Module designed for use within the Experion LS distributed control system. This module provides reliable detection and processing von digital input signals from various field devices such as switches, relays, and contactors, with galvanic isolation to ensure signal integrity and protection from electrical noise and interference.
Engineered for demanding industrial environments, the TC-IDJ161 vonfers high channel density, robust electrical isolation, and advanced diagnostics to support precise control and monitoring. Its compact design facilitates efficient installation in control racks, making it a critical component for industrial automation and safety systems.
Key Features
-
Isolated discrete input module compatible with Honeywell Experion LS systems.
-
High channel count for efficient digital signal acquisition.
-
Galvanic isolation on inputs for enhanced noise immStücky and system protection.
-
Supports dry contact and sourcing/sinking input types.
-
Hot-swappable for minimal system downtime during maintenance.
-
Integrated diagnostics for fault detection and troubleshooting.
-
Rugged construction suited for harsh industrial environments.
-
Compact size for convenient rack mounting.
-
Compliant with relevant industry safety and performance standards.
-
Supports scalable system configurations and redundancy.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Modell | TC-IDJ161 |
| Module Type | Isolated Discrete Input Module |
| Number von Input Channels | 16 Channels |
| Input Signal Type | Dry Kontakt, Sinking or Sourcing Logic |
| Input Voltage Range | 24 VDC nominal |
| Isolation | Galvanic isolation per input channel |
| Input Response Time | ≤ 10 ms |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-condensing |
| Power Supply | Provided by system rack |
| Dimensions | 27 × 98 × 90mm |
| Gewicht | 0.45 kg |
| Communication Interface | Proprietary bus compatible with Experion LS |
| Certifications | CE, UL, FM Approved |
Industry Applications
-
Oil & Gas: Monitoring discrete signals from valves, switches, and safety interlocks.
-
Chemical Processing: Reliable input acquisition for control and safety devices.
-
Power Generation: Discrete input monitoring for breakers, alarms, and switches.
-
Water & Wastewater: Status inputs for pumps, valves, and control systems.
-
Pharmaceutical Manufacturing: Precise digital input monitoring in batch processes.
-
General Industrial Automation: Machine status, limit switches, and alarm input detection.
Product Advantages
-
Galvanic Isolation: Ensures signal integrity and protects control systems from electrical noise.
-
High Channel Density: 16 discrete inputs per module maximize rack efficiency.
-
Robust and Reliable: Built for industrial conditions and continuous operation.
-
Ease von Maintenance: Hot-swappable design minimizes downtime.
-
Advanced Diagnostics: Facilitates rapid fault detection and troubleshooting.
-
Space-saving Form Factor: Compact design fits easily in control cabinets.
-
System Compatibility: Fully integrated with Honeywell Experion LS architecture.
-
Noise ImmStücky: Isolation and filtering reduce signal interference.
-
Certified Quality: Compliant with international industrial standards.
-
Flexible System Integration: Supports scalable and redundant control system configurations.
Häufig gestellte Fragen (FAQ)
-
How many discrete inputs does the TC-IDJ161 support?
The module supports 16 isolated discrete input channels. -
What types von input signals can it handle?
Dry contact, sinking, or sourcing logic signals. -
What is the nominal input voltage?
24 VDC nominal. -
Is the module isolated?
Yes, each input channel has galvanic isolation. -
Is the module hot-swappable?
Yes, it allows for maintenance without shutting down the system. -
What is the input response time?
10 milliseconds or less. -
What is the operating temperature range?
0°C to +60°C. -
What are the module dimensions and weight?
127mm × 98mm × 90mm; approximately 0.45 kg. -
Which systems is it compatible with?
Honeywell Experion LS distributed control systems. -
What diagnostics features are included?
Fault detection and input status monitoring.
