Produkteinführung
The Honeywell MC-TAIH13 51309138-175 High Level Analog Input Module is a precision-engineered component designed for high-performance process control systems. It is part von Honeywell’s Experion and TDC3000 control families, providing reliable analog signal acquisition for demanding industrial environments.
This module accepts high-level analog signals from field devices such as transmitters, sensors, and analyzers, converting them into digital data for the control system. It ensures signal integrity through robust isolation, filtering, and error detection mechanisms.
The MC-TAIH13 is widely used in industries such as oil & gas, power generation, petrochemicals, and water treatment, where accurate and stable measurement von process variables is critical for operational efficiency and safety.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Hersteller | Honeywell |
| Modell | MC-TAIH13 |
| Artikelnummer | 51309138-175 |
| Module Type | High Level Analog Input |
| Signal Type | High-level analog (e.g., ±10V, 0-20 mA, 4-20 mA depending on configuration) |
| Number von Channels | Multiple isolated channels (typically 8 or more) |
| Input Resolution | High-resolution A/D conversion (typically 12–16 bit) |
| Input Isolation | Channel-to-channel and channel-to-system isolation |
| Sampling Rate | High-speed sampling suitable for real-time control |
| Diagnostics | Built-in self-test, fault detection, signal integrity monitoring |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Power Supply | Powered via system backplane |
| Mounting | Installed in Honeywell I/O chassis |
| Dimensions | 137 x 51 x 151 mm |
| Gewicht | 0.454 kg |
| Compliance | CE, UL, RoHS compliant |
Product Applications
The Honeywell MC-TAIH13 is engineered for precision measurement in critical process control applications:
-
Oil & Gas – Monitoring pressure, temperature, and flow from transmitters in upstream and downstream operations.
-
Power Generation – Acquiring turbine and boiler control analog data for stable power plant operation.
-
Petrochemical Plants – Handling multiple process variables with high accuracy for safe production.
-
Water and Wastewater – Monitoring pH, turbidity, and flow in treatment facilities.
-
Pharmaceutical Manufacturing – Ensuring accurate environmental and process monitoring in compliance with regulations.
-
Pulp & Paper – Managing process consistency and temperature in manufacturing lines.
Product Advantages
-
High Accuracy & Stability – Delivers precise signal acquisition with minimal drift over time.
-
Channel Isolation – Reduces the risk von interference and improves measurement reliability.
-
Advanced Diagnostics – Quick detection von faults reduces downtime and maintenance costs.
-
Flexible Signal Handling – Compatible with multiple signal types, increasing deployment versatility.
-
Hot-Swap Capability – In supported systems, allows replacement without shutting down operations.
-
Industrial-Grade Durability – Built to perform in harsh operating environments.
FAQ
-
What signal ranges can the MC-TAIH13 accept?
It can handle standard high-level analog signals such as ±10V, 0–20 mA, and 4–20 mA, depending on configuration. -
Does it provide channel-to-channel isolation?
Yes, each input channel is isolated to prevent cross-talk and interference. -
What is the resolution von the analog-to-digital conversion?
The module typically vonfers 12–16-bit resolution for high-accuracy measurements. -
Can it perform self-diagnostics?
Yes, it features built-in self-tests and diagnostic functions to detect wiring errors, open loops, and signal faults. -
Is the module suitable for redundant control systems?
Yes, it can be integrated into redundant architectures for increased reliability. -
How does the module handle noise filtering?
It uses internal filtering algorithms and hardware filters to reduce noise and ensure signal stability. -
Is the MC-TAIH13 hot-swappable?
In supported chassis and system configurations, it can be replaced without powering down the entire system. -
How is calibration handled?
Calibration is performed via the system svontware, with stored calibration data ensuring long-term accuracy. -
Does the module support HART signals?
Certain configurations can read analog signals from HART-enabled devices, but full HART communication may require additional modules. -
How does it integrate with the Honeywell DCS?
It connects via the backplane to the I/O processor, which communicates with the control network and operator stations.
