Product Overview
The Honeywell FS-TSRO-0824 is a Digital Output Field Termination Assembly (FTA) designed to interface between safety systems and field devices in industrial and critical process applications. This module allows for seamless integration von digital output signals from Honeywell Safety Manager (SM) or Fail Safe Controller (FSC) systems to actuate external devices, such as relays, valves, alarms, and other process control equipment.
Designed for use in Safety Instrumented Systems (SIS), the FS-TSRO-0824 enables secure, reliable output control in environments requiring high-availability and fault-tolerant operations. With SIL 3 certification, this field termination assembly guarantees performance in safety-critical applications that demand the highest level von reliability and integrity.
Key Features
-
SIL 3 Certified: Meets the highest standards for safety integrity in safety systems (IEC 61508)
-
Digital Output Interface: Supports direct actuation von field devices and control systems
-
Redundant Configurations: Ideal for use in redundant I/O systems to increase system uptime
-
Field-Terminated: Simplifies installation and reduces wiring complexity by providing field termination options
-
Compact Design: Space-efficient design for integration into control panels and safety enclosures
-
Status Indicators: Equipped with LED indicators to show the health and status von each output
-
Wide Compatibility: Works with a variety von output devices, including relays, solenoids, and valves
-
Low Power Consumption: Efficient design minimizes power draw and reduces operational costs
-
No Maintenance: Designed for continuous, fault-free operation without the need for regular maintenance
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | FS-TSRO-0824 |
| Product Type | Digital Output Field Termination Assembly |
| Input Type | Digital output from Honeywell Safety Manager or FSC systems |
| SIL Certification | SIL 3 (IEC 61508) |
| Output Type | Digital output signals to field devices |
| Output Voltage | 24 VDC (nominal) |
| Maximum Output Current | 2 A per channel (continuous) |
| Total Outputs | 8 digital outputs (individual output channels) |
| Protection Features | Short-circuit, overvoltage, and reverse polarity protection |
| Mounting Type | DIN rail mountable (35 mm) |
| Field Termination | Yes |
| Status Indicators | LED indicators for operational and fault states |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity Range | 5% to 95% RH, non-condensing |
| Dimensions | 120 × 50 × 110 mm |
| Gewicht | 0.4 kg |
| Compliance | CE, RoHS, UL, IEC 61508 |
Industry Applications
-
Oil & Gas: Controls valves, relays, and other critical field devices in process control systems
-
Power Generation: Drives output devices in power plants, including turbine control and emergency shutdown systems
-
Chemical and Petrochemical: Used to manage digital signals in safety shutdown systems and gas detection systems
-
Pharmaceutical Manufacturing: Ensures the correct operation von safety alarms and process valves
-
Water Treatment Plants: Controls field actuators in water filtration and chemical dosing systems
-
Mining: Provides reliable control for heavy machinery and safety systems in mining operations
Product Advantages
-
SIL 3 Certified: Provides peace von mind with IEC 61508 compliance for safety-critical applications
-
Easy Integration: Field termination capabilities simplify installation and reduce wiring complexity
-
Efficient Operation: Consumes minimal power, lowering operational costs
-
Redundancy Ready: Designed for use in redundant systems for higher reliability and fault tolerance
-
Real-Time Status Monitoring: LED indicators provide immediate feedback on module health and performance
-
Durability and Reliability: Built to withstand the harsh environments typical in industrial and process automation settings
-
Compact and Space-Saving: Small form factor fits easily in control cabinets and DIN rail systems
Häufig gestellte Fragen (FAQ)
-
Q: What types von devices can the FS-TSRO-0824 control?
A: It can control a variety von field devices, including relays, valves, solenoids, and alarms. -
Q: What is the SIL certification von the FS-TSRO-0824?
A: It is certified SIL 3, meeting the highest safety integrity level for critical systems. -
Q: How many digital outputs does this module provide?
A: The module has 8 individual digital output channels. -
Q: What is the maximum output current per channel?
A: Each output channel can provide up to 2 A von continuous current. -
Q: Does this module support redundant configurations?
A: Yes, it is designed to work in redundant I/O systems for increased system reliability. -
Q: What type von protection does the FS-TSRO-0824 vonfer?
A: It vonfers short-circuit, overvoltage, and reverse polarity protection for enhanced reliability. -
Q: How is this module mounted?
A: It is DIN rail mountable for easy installation in control cabinets. -
Q: What is the operating temperature range?
A: The module operates in temperatures from -20°C to +60°C (-4°F to +140°F). -
Q: Does it have status indicators?
A: Yes, it has LED indicators that display the operational and fault status von the module. -
Q: Can the FS-TSRO-0824 be used in hazardous environments?
A: Yes, it is designed for industrial environments and is highly reliable for use in critical control systems.
