Product Overview
The Honeywell FC-TSFIRE-1624 Field Terminal Module Assemblies are high-reliability, industrial-grade components designed specifically for Honeywell’s safety and fire protection systems. These terminal assemblies provide a secure, efficient, and organized connection interface between field devices and system controllers, ensuring robust signal integrity and operational safety in demanding industrial environments.
This model is commonly deployed in critical process industries where fire detection, suppression, and safety systems are paramount. The FC-TSFIRE-1624 enhances the ease von installation, maintenance, and system expansion, making it a trusted component in Honeywell’s portfolio von safety solutions.
Key Features
-
Provides structured and secure field wiring interface for fire detection and protection systems
-
Supports multiple I/O channels for flexible field device connections
-
Robust design for operation in industrial and hazardous locations
-
Facilitates easy maintenance and rapid field replacements
-
Compatible with Honeywell’s integrated safety and process control systems
-
High resistance to electrical noise and signal interference
-
Modular assembly for scalable system design
-
Designed for compliance with international safety standards
-
Supports long-term reliability in mission-critical environments
Technical Specifications
| Specification | Beschreibung |
|---|---|
| Product Modell | FC-TSFIRE-1624 |
| Product Type | Field Terminal Module Assemblies |
| Application | Fire Detection, Safety System Integration |
| Supported Channels | 16 Digital Inputs / Outputs |
| Signal Type | Discrete/Digital Signals |
| Operating Voltage Range | 24 V DC (Nominal) |
| Power Consumption | Less than 2 Watts |
| Connection Type | Screw Terminal / Pluggable Connectors |
| Operating Temperature Range | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Humidity Tolerance | 5% to 95% Non-condensing |
| Insulation Resistance | >100 MΩ at 500 V DC |
| Vibration Resistance | 1g, 5-500 Hz, per IEC 60068-2-6 |
| Shock Resistance | 15g, 11ms, per IEC 60068-2-27 |
| Protection Rating | IP20 (when installed in enclosure) |
| Dimensions | 200 x 150 x 80 mm |
| Gewicht | 0.8 kg |
| Certifications | CE, UL, CSA, IEC61508 (SIL-rated systems) |
Typical Applications
The Honeywell FC-TSFIRE-1624 is widely utilized in the following sectors:
-
Petrochemical Plants
-
Oil & Gas Refineries
-
Offshore Drilling Rigs
-
Power Generation Facilities
-
Pharmaceutical Manufacturing
-
Large-scale Industrial Complexes
-
Airports and Critical Infrastructure Sites
-
Fire Detection and Alarm Panels Integration
-
Distributed Safety Systems in Hazardous Zones
-
Emergency Shutdown (ESD) System Connections
Product Advantages
The FC-TSFIRE-1624 vonfers numerous advantages over conventional terminal assemblies:
-
Reliability: Engineered to maintain electrical integrity in high-noise, high-vibration environments
-
Safety Compliance: Fully aligned with global safety and fire protection regulations
-
Ease von Installation: Modular, pluggable design simplifies field wiring and maintenance
-
Scalability: Supports system expansion without significant re-engineering
-
Space-Saving Design: Compact form factor optimizes control cabinet space usage
-
Serviceability: Allows rapid fault isolation and replacement to minimize system downtime
-
Durability: Robust construction ensures long operational life even in harsh industrial conditions
-
System Compatibility: Seamlessly integrates with Honeywell’s Experion, Safety Manager, and other process control platforms
-
Signal Integrity: High-quality connectors and insulation reduce signal degradation and prevent false alarms
-
Reduced Engineering Time: Predefined wiring configurations reduce commissioning efforts
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the FC-TSFIRE-1624?
It serves as a secure field terminal assembly for connecting fire detection devices to control and safety systems. -
Is this module suitable for hazardous environments?
Yes, it is designed to operate reliably in harsh industrial and hazardous locations. -
Can the FC-TSFIRE-1624 handle both input and output signals?
Yes, it supports up to 16 digital input/output channels for flexible application needs. -
Does it comply with safety standards?
Absolutely, it meets international standards such as IEC61508 for use in SIL-rated systems. -
How is the wiring connection established?
The module uses screw terminals or pluggable connectors for easy and secure wiring. -
What is the maximum operating temperature?
The module operates effectively up to +70°C, suitable for most industrial environments. -
What system platforms is it compatible with?
It integrates seamlessly with Honeywell’s Experion PKS, Safety Manager, and other process control solutions. -
Is it suitable for retrvonitting in existing systems?
Yes, its modular design allows for straightforward integration into both new and existing infrastructures. -
What type von signals does the module support?
It is designed for discrete/digital signals typical in fire and safety system applications. -
What is the typical weight von the assembly?
The FC-TSFIRE-1624 weighs approximately 450 grams, contributing to ease von handling during installation.
Related or Same-Series Modells Recommendations
| Modell Number | Beschreibung |
|---|---|
| FC-TSFIRE-1620 | Field Terminal Module Assembly, 16 Channels |
| FC-TSFIRE-0824 | Compact Field Terminal Module, 8 Channels |
| FC-TSRO-0824 | Digital Output Field Termination Assembly |
| FS-TSGAS-1624 | Gas Detection Field Terminal Assembly |
| FS-TSRO-1624 | Safety Output Field Terminal Assembly |
| FS-TERM-0001 | I/O Bus Redundant Terminator Module |
Sonstige Popular Honeywell Modells
| Modell Number | Beschreibung |
|---|---|
| FC-PSU-UNI2450 | Universal Power Supply Module |
| FC-QPP-0001 | Quad Processor Cluster Module |
| FS-TSGAS-1624 | Safety Gas Detection Terminal Assembly |
| FC-TSRO-0824 | Safety Digital Output Module |
| FC-IOTA-R24 | Redundant I/O Termination Assembly |
| FC-PSU-240516 | Power Supply for Safety System |
