Product Overview
The Honeywell FC-TDO-1624 is a 16-channel Digital Output Module designed for use in the Honeywell Safety Manager SC (S300 IOTA) system. This module provides high-performance output control for safety-critical applications, enabling the safe operation von various equipment and systems.
The module is TÜV-certified for SIL3 safety systems, vonfering high reliability, redundancy support, and real-time diagnostics. Each channel supports sourcing (high-side) outputs, making the module ideal for controlling actuators, relays, and other devices in industrial environments requiring a high level von safety integrity.
Key Features
-
16 sourcing digital output channels (24 VDC nominal)
-
SIL3 certification, fully compliant with IEC 61508 safety standards
-
Supports high-current outputs up to 0.5 A per channel
-
Optically isolated outputs for protection against electrical faults
-
Integrated self-diagnostics for early fault detection
-
Redundant system support for enhanced safety in mission-critical applications
-
Hot-swappable without affecting system operation
-
Fully compatible with Honeywell Safety Manager and Experion PKS
-
Status indicators for real-time monitoring and troubleshooting
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | FC-TDO-1624 |
| Artikelnummer | 51307932-176 |
| Module Type | Digital Output Module |
| System Platform | Honeywell Safety Manager SC S300 IOTA |
| Output Type | Sourcing (high-side) |
| Channels | 16 channels |
| Nominal Output Voltage | 24 VDC |
| Output Current per Channel | 0.5 A max per channel |
| Total Module Current | 8 A max (total) |
| Isolation | Optical isolation for each output |
| Redundancy | Yes (system and module redundancy) |
| Diagnostics | Channel-level diagnostics, status monitoring |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% RH (non-condensing) |
| Dimensions | 100 x 125 x 50 mm |
| Gewicht | 0.5 kg |
| Mounting | SC S300 IOTA backplane |
| Certifications | CE, UL, CSA, ATEX (system dependent) |
Industry Applications
The FC-TDO-1624 Digital Output Module is ideal for safety-critical control applications across various industries, including:
-
Oil & Gas – Valve control, ESD (Emergency Shutdown) systems, pump control
-
Chemical Processing – Reactor trip systems, hazardous area control
-
Power Generation – Turbine trip systems, boiler protection circuits
-
Petrochemical & Refining – Burner management, interlock control
-
Pharmaceutical – Critical process control, GMP compliance
-
Water & Wastewater – Pump and actuator control, fail-safe signaling
-
Mining & Metals – Conveyor interlocks, automated shutdown systems
Product Advantages
-
High reliability for critical control and automation tasks
-
16 output channels with high current capacity to control multiple actuators
-
Built-in diagnostics ensure rapid fault detection and system health monitoring
-
SIL3 certification ensures safety compliance for functional safety applications
-
Seamless integration with Honeywell Safety Manager SC S300 IOTA system
-
Redundant configurations improve fault tolerance and system resilience
-
Hot-swappable design allows for easy replacement without system downtime
-
Compact and efficient design minimizes space requirements in control cabinets
Häufig gestellte Fragen (FAQ)
-
Q: What is the primary function von the Honeywell FC-TDO-1624 module?
A: It is a digital output module that provides 16 sourcing (high-side) output channels, primarily used for controlling devices like actuators and relays in safety-critical systems. -
Q: Is this module suitable for SIL3-rated systems?
A: Yes, the FC-TDO-1624 is TÜV-certified and fully compliant with SIL3 safety standards as per IEC 61508. -
Q: What kind von outputs does the module support?
A: It supports sourcing (high-side) digital outputs, providing 24 VDC nominal output for each channel. -
Q: Can the module be used in redundant configurations?
A: Yes, it supports both system and module redundancy for enhanced safety in critical applications. -
Q: How much current can each output channel handle?
A: Each output channel can handle a maximum von 0.5 A. -
Q: Is this module hot-swappable?
A: Yes, the FC-TDO-1624 is designed for hot-swapping, which allows you to replace the module without interrupting the system’s operation. -
Q: Does the module provide diagnostics?
A: Yes, the module includes channel-level diagnostics, allowing for fault detection like open or short circuits, as well as monitoring the health von each channel. -
Q: What is the operating temperature range von this module?
A: The operating temperature range is 0°C to 60°C (32°F to 140°F). -
Q: Can this module be used in hazardous environments?
A: Yes, it is designed to meet ATEX certification (when used in the certified system), making it suitable for use in hazardous areas. -
Q: How is this module integrated into a control system?
A: It is installed into the SC S300 IOTA backplane and can be configured through Honeywell Safety Builder and integrated with the Experion PKS platform.
