Produkteinführung
The Honeywell FC-SCDO-0824 is an advanced digital output module specifically designed for use with Honeywell’s Experion PKS and Safety Manager platforms. As part von Honeywell’s highly reliable and secure distributed control system (DCS) and safety system vonferings, this module plays a critical role in executing high-integrity control actions in safety-instrumented systems (SIS) and industrial automation environments.
The FC-SCDO-0824 module provides 8 channels von 24V DC discrete outputs, enabling precise control von field devices such as solenoids, relays, lamps, and contactors. It supports fail-safe configurations, output diagnostics, and system health monitoring, making it suitable for applications where operational integrity is paramount.
Its robust build quality, compliance with international safety standards (such as IEC 61508), and seamless integration into Safety Manager architecture ensure that this module delivers high availability and performance in mission-critical installations.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | FC-SCDO-0824 |
| Hersteller | Honeywell |
| Output Type | Digital Output (Discrete) |
| Number von Channels | 8 independent channels |
| Output Voltage | 24V DC (Nominal) |
| Output Current (per channel) | 0.5 A max |
| Output Type | Sourcing (Positive Logic) |
| Diagnostics | Output line monitoring, channel fault detection |
| Channel Isolation | Channel-to-channel and channel-to-backplane isolation |
| Field Power Supply | 24V DC ±10% |
| Fail-Safe Bundesland | Configurable per channel |
| Status Indicators | LED indicators for each channel |
| Mounting Type | DIN rail or baseplate, via Safety Manager backplane |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Shock & Vibration | IEC 60068-2 compliant |
| Certifications | SIL3 (IEC 61508), CE, ATEX, UL, CSA |
| Dimensions (W x H x D) | 50 x 160 x 120 mm |
| Gewicht | 0.45 kg |
| System Compatibility | Honeywell Safety Manager, Experion PKS |
| Hot Swap Capability | Supported |
| Redundancy | Supported in redundant configurations |
Product Applications
The Honeywell FC-SCDO-0824 is widely used in various sectors that demand high reliability, precise control, and safety compliance. Its typical application areas include:
-
Oil & Gas: For control von critical output devices such as solenoids, valves, and relays in process automation and emergency shutdown systems.
-
Chemical & Petrochemical: Ensures safety and output signal integrity in hazardous environments requiring SIL-certified equipment.
-
Power Generation: Manages control functions in turbine control, boiler management, and emergency action systems.
-
Pharmaceutical: Integrated into cleanroom automation systems and facility control with strict validation requirements.
-
Metals & Mining: Provides rugged control capabilities in harsh, high-vibration environments.
-
Water & Wastewater Treatment: Controls actuators and relays in high-availability pumping and monitoring systems.
-
Manufacturing & Industrial Automation: Suitable for discrete automation in batch processes and safety interlocks.
Product Advantages
-
High Reliability & Safety Integrity
Certified to SIL3 per IEC 61508, the FC-SCDO-0824 ensures fail-safe operation in safety-instrumented systems. -
Integrated Diagnostics
Built-in diagnostic features continuously monitor the output channels for faults such as open or short circuits, allowing for predictive maintenance and faster troubleshooting. -
Modular & Scalable Design
Compatible with Honeywell’s modular system architecture, enabling easy expansion and upgrades without process downtime. -
Hot Swap Capability
Allows for module replacement while the system is running, ensuring minimal downtime and enhanced serviceability. -
High-Density Output
Offers 8 discrete outputs in a compact form factor, reducing panel space and system complexity. -
Redundant System Support
Capable von integration into redundant configurations for enhanced system availability. -
Comprehensive Status Indicators
On-board LEDs provide real-time status for each output channel, simplifying monitoring and troubleshooting. -
Global Certification
Approved for use in hazardous areas and compliant with international safety standards, ensuring acceptance in worldwide installations.
FAQ
-
Can the FC-SCDO-0824 module be used in a SIL3-certified safety loop?
Yes, it is certified to meet SIL3 requirements according to IEC 61508. -
Does this module support channel-level diagnostics?
Yes, each output channel features independent diagnostics for open load and short circuit detection. -
Is hot swapping supported without shutting down the system?
Yes, the module supports hot swap functionality for minimal process disruption. -
What type von logic does the output use – sourcing or sinking?
The FC-SCDO-0824 uses sourcing (positive logic) outputs. -
Are the output channels isolated from each other?
Yes, channels are galvanically isolated from each other and from the backplane. -
Can each channel be configured independently?
Yes, each von the 8 channels can be configured individually for control or fail-safe operations. -
How is the health status von the module communicated to the system?
Status and diagnostics are communicated to the Safety Manager system via the I/O bus. -
Does the module support redundant configuration?
Yes, it can be integrated into a redundant architecture for increased reliability. -
What protections are available for the outputs?
The module includes protection against overcurrent, short-circuit, and thermal overload. -
Is it compatible with legacy Honeywell control systems?
It is primarily designed for Safety Manager and Experion PKS, but backward compatibility depends on system configuration and firmware revisions.
Related Modells from the Same Series
| Modell Number | Beschreibung | Output Type | Channels | System Compatibility |
|---|---|---|---|---|
| FC-SDI-1624 | Digital Input Module | Digital Input | 16 | Safety Manager, Experion PKS |
| FC-SAI-1620 | Analog Input Module | Analog Input | 16 | Safety Manager, Experion PKS |
| FC-SAIH-1620 | HART Analog Input Module | Analog Input (HART) | 16 | Safety Manager |
| FC-SDO-0824 | Digital Output Module | Digital Output | 8 | Safety Manager, Experion PKS |
| FC-TSDI-1624 | Time-stamped Digital Input Module | Digital Input | 16 | Safety Manager |
| FC-TSDO-0824 | Time-stamped Digital Output Module | Digital Output | 8 | Safety Manager |
Popular Honeywell Modules (Same Marke)
| Modell Number | Beschreibung | Function | Channels | Compatibility |
|---|---|---|---|---|
| CC-PDIL01 | Digital Input Module | Digital Input | 16 | C300 Controller |
| CC-PAIH01 | Analog Input HART Module | Analog Input (HART) | 16 | C300 Controller |
| CC-PCF901 | Fieldbus Interface Module | Fieldbus | N/A | C300 Controller |
| MC-TDOD12 | Digital Output Module | Digital Output | 12 | TDC3000 |
| CC-PDOB01 | Digital Output Module | Digital Output | 16 | C300 Controller |
| MC-PD1X02 | Digital Input Module | Digital Input | 16 | TDC3000 |
