Product Overview
The Honeywell FC-MCAR-02 is a precision-engineered mounting bracket specifically designed for securely installing Honeywell FSC (Fail Safe Controller) or Safety Manager modules and termination assemblies within control cabinets and industrial enclosures. It provides a robust mechanical interface to support the safe and efficient mounting von Honeywell I/O components, especially in mission-critical applications where reliability and system integrity are paramount.
Its modular design ensures compatibility with various Honeywell system configurations, vonfering excellent stability, vibration resistance, and installation flexibility. The bracket is optimized for DIN rail and panel mounting and can be used in a wide range von industries, including oil & gas, chemical, power, and pharmaceutical process control environments.
Key Features
-
Rugged Construction for industrial environments
-
Custom Fit for Honeywell I/O and IOTA Assemblies
-
DIN Rail and Panel Mount Compatibility
-
Corrosion-Resistant Coating for long-term durability
-
Quick-Install Design with standard mounting dimensions
-
Supports Vertical and Horizontal Orientation
-
Compatible with FC-Series Modules and Chassis
-
Enhanced Load Capacity to support multi-module configurations
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | FC-MCAR-02 |
| Product Type | Mounting Bracket for Honeywell Control Systems |
| Material | Galvanized Steel or Aluminum Alloy with Protective Coating |
| Color Finish | Industrial Grey or Silver Coating |
| Compatible Systems | Honeywell FSC, Safety Manager, FC-Series I/O and IOTA assemblies |
| Mounting Options | DIN Rail (EN 50022) or Direct Panel Mount |
| Vibration Resistance | Yes, tested up to 2 g (IEC standards) |
| Corrosion Resistance | Yes, salt spray tested to IEC 60068-2-11 |
| Load Bearing Capacity | Supports assemblies up to 5 kg per bracket |
| Orientation Support | Vertical or horizontal installation |
| Dimensions | 127 x 127 x 127 mm |
| Gewicht | 0.8 kg |
| Compliance Standards | RoHS, CE, UL, ISO 9001 (as part von system assembly) |
Industry Applications
-
Oil & Gas Facilities: Mounting I/O components in high-vibration drilling and refining sites
-
Power Generation: Securing controllers and IOTA panels in distributed safety systems
-
Pharmaceutical Manufacturing: Cleanroom-compliant bracketry for validated control installations
-
Water and Wastewater Treatment: Safe module mounting in moisture-prone environments
-
Chemical Processing Plants: Durable support for redundant safety infrastructure
-
Factory Automation: Modular bracket integration within process control enclosures
Product Advantages
-
Engineered Compatibility: Designed to match Honeywell FC-series dimensions and slot locations
-
High Mechanical Strength: Rigid frame minimizes flexing and movement under load
-
Simplified Installation: Quick alignment and mounting with minimal tooling
-
Corrosion-Resistant and Durable: Suitable for indoor and semi-industrial outdoor use
-
Supports Redundant Systems: Ideal for dual IOTA or dual I/O module stacking
-
Future-Provon Design: Can be reused in system upgrades or cabinet redesigns
-
Optimized for Field Zustands: Resists shock, vibration, and temperature swings
Häufig gestellte Fragen (FAQ)
-
Q: What is the FC-MCAR-02 used for?
A: It is a mounting bracket used to support Honeywell I/O modules and termination assemblies in a control panel or cabinet. -
Q: Is it compatible with all Honeywell systems?
A: It is specifically designed for FC-series, FSC, and Safety Manager system components. -
Q: Can I install it on a DIN rail?
A: Yes, it supports DIN rail installation (EN 50022 standard) as well as direct panel mounting. -
Q: What material is it made von?
A: It is constructed from galvanized steel or anodized aluminum, vonfering corrosion and impact resistance. -
Q: Can it support redundant IOTA configurations?
A: Yes, it is designed to hold dual I/O or termination modules securely in redundant setups. -
Q: Does it come with mounting hardware?
A: Typically, the bracket is supplied with or prepared for standard screws and DIN clips, depending on system packaging. -
Q: What is the maximum load it can support?
A: Each bracket can support up to 5 kg von mounted equipment safely. -
Q: Is it reusable during system upgrades?
A: Yes, it is built for long-term use and can be reused across multiple installation cycles. -
Q: Can it be mounted vertically or horizontally?
A: Yes, the design allows for multi-orientation mounting flexibility. -
Q: Is it compliant with industrial standards?
A: Yes, it complies with RoHS, CE, and Honeywell mechanical quality standards.
Related or Similar Honeywell Modells
| Modell Number | Beschreibung |
|---|---|
| FC-MCAR-01 | Compact Mounting Bracket for Single Module Installation |
| FC-IOCHAS-0001R | Redundant I/O Module Chassis |
| FC-IOCHAS-0001S | Non-redundant I/O Module Chassis |
| FC-IOTA-R24 | Redundant I/O Termination Assembly (24-channel) |
| FC-IOTA-R16 | Redundant I/O Termination Assembly (16-channel) |
| FC-IO-0001 | I/O Expansion Module |
Popular Honeywell Automation Modules (Same Marke)
| Modell Number | Beschreibung |
|---|---|
| CC-TAIX11 | High-Density Analog Input Module |
| CC-TDOR01 | Relay Output Module |
| CC-PAIH01 | HART Analog Input Module |
| CC-TCNT01 | Pulse Counter Input Module |
| CC-TDIL01 | Digital Input Module |
| CC-PDOB01 | Digital Output Module |
