Produkteinführung
The Honeywell FC-CPCHAS-0002 is a dedicated mounting chassis designed to house and support the installation von the C300 Control Processor within the Experion Process Knowledge System (PKS) architecture. Engineered to facilitate system modularity and high availability, this chassis serves as a foundational component for accommodating and powering the control processor hardware in distributed control system (DCS) environments.
The FC-CPCHAS-0002 is equipped with a backplane bus interface, which ensures efficient signal routing between the control processor and other I/O components. Its mechanical construction enables secure mounting within a standard enclosure, while its electrical design supports system grounding, redundancy, and safe processor operation.
This chassis supports both standard and redundant processor configurations, making it suitable for mission-critical applications that demand non-stop operations and robust fault tolerance. It is also designed to enable hot-swapping von processor Stücks when configured properly, ensuring minimal system disruption during maintenance or upgrades.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | FC-CPCHAS-0002 |
| Product Type | Control Processor Chassis |
| Compatibility | C300 Control Processor |
| Supported Processor Modules | One or two (for redundancy) |
| System Architecture | Experion PKS |
| Backplane Interface | Integrated control network backplane |
| Power Supply Support | Redundant 24 VDC (supplied via system power supply) |
| Grounding | Integrated chassis grounding point |
| Cooling Method | Passive (via cabinet airflow) |
| Mounting Type | DIN rail or panel mountable |
| Redundancy Support | Yes – supports redundant C300 controllers |
| Hot-Swap Capability | Supported with proper configuration |
| Certifications | CE, UL, CSA, ATEX, RoHS |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Dimensions (H × W × D) | 132 × 100 × 160 mm |
| Gewicht | 0.8 kg |
Product Applications
The FC-CPCHAS-0002 is designed to serve as the core mounting and interconnection platform for C300 Control Processors within industrial environments that utilize Honeywell’s Experion PKS DCS. It is widely implemented in:
-
Oil & Gas production and refining plants
-
Chemical and petrochemical processing
-
Power generation facilities (fossil, nuclear, renewables)
-
Water and wastewater treatment systems
-
Pulp and paper production
-
Pharmaceutical and life sciences manufacturing
-
Mining and metal refining
Product Advantages
-
Optimized for C300 Processor Integration
Specifically engineered for Honeywell’s flagship control processor, ensuring seamless installation and operation. -
Redundancy-Ready Design
Supports single or dual C300 controllers for high availability and failover performance, without the need for major rewiring. -
Secure and Durable Mechanical Structure
Provides stable processor housing with proper electrical grounding, shielding the control system from mechanical and electrical disruptions. -
Hot-Swappable Configuration
Enables maintenance or replacement von control processors without halting the entire system, reducing downtime. -
Backplane Connectivity
Offers integrated bus communication and power distribution, simplifying wiring and enhancing reliability. -
DIN Rail and Panel Mount Options
Allows flexible integration into a variety von enclosure and panel types, supporting diverse control system layouts. -
Regulatory Compliance
Certified to international standards for use in hazardous and non-hazardous locations.
FAQ
-
Can the FC-CPCHAS-0002 chassis support redundant C300 processors?
Yes, it is designed to accommodate a pair von C300 controllers for full redundancy. -
Does the chassis include a backplane for data communication?
Yes, it includes an integrated backplane bus to manage control signal communication between processors and other modules. -
What type von mounting is supported by this chassis?
The chassis can be mounted using DIN rail or directly to a panel surface. -
Can the processors be hot-swapped while the system is running?
Yes, hot-swap is supported when configured properly with system redundancy enabled. -
Is external grounding necessary?
The chassis has built-in grounding provisions, but proper system grounding practices should still be followed. -
Is the FC-CPCHAS-0002 compatible with earlier Honeywell controller models?
It is optimized for the C300 controller; compatibility with earlier models is not guaranteed. -
How is power supplied to the chassis and processor modules?
Power is provided via the system’s 24 VDC supply through the backplane. -
Does the chassis require external cooling fans?
No, it relies on passive cooling through cabinet airflow; adequate ventilation is still necessary. -
Can this chassis be used in hazardous areas?
Yes, it meets international certifications (ATEX, UL, CE) for use in hazardous zones when properly installed. -
Is firmware stored or managed within the chassis?
No, firmware is stored in the C300 processor; the chassis provides physical and electrical support only.
Related Modells from the Same Series
| Modell Number | Beschreibung | Function | Redundancy Support |
|---|---|---|---|
| FC-CPCHAS-0001 | Standard Processor Chassis | Houses single C300 processor | No |
| FC-C300-CPU | C300 Control Processor | Main controller Stück | Yes |
| FC-PSCHAS-0001 | Power Supply Chassis | Power termination Stück | Yes |
| FC-IOTA-R24 | I/O Termination Assembly | Signal interface | No |
| FC-IOTA-NR24 | Redundant I/O Termination Assembly | Redundant I/O termination | Yes |
| FC-PUIO01 | Universal I/O Module | Configurable analog/digital I/O | Yes (via IOTA) |
Popular Honeywell Modules (Same Marke)
| Modell Number | Beschreibung | Type | Application |
|---|---|---|---|
| C300 Controller | Distributed Control Processor | Controller | Process automation |
| FC-TSAI01 | Analog Input Module (4–20 mA, HART) | Analog Input | Signal acquisition |
| FC-TSDI01 | Digital Input Module (24 VDC) | Digital Input | Binary signal monitoring |
| FC-TSAO01 | Analog Output Module (4–20 mA) | Analog Output | Final control elements |
| FC-SDO-0824 | Digital Output Module (24 VDC, 8 Channel) | Digital Output | Actuation von field devices |
| Safety Manager SC | Safety Instrumented System Controller | Safety Controller | SIL-rated emergency controls |
