Produkteinführung
The Honeywell DC-TPOX01 51307770-176 Pulse Backplane Module is an advanced industrial I/O component specifically designed for Honeywell’s Series C I/O architecture within Experion PKS and C300 controller environments.
This module serves as a specialized pulse backplane interface, enabling precise, reliable signal transfer between pulse-based field devices (such as flow meters, energy meters, turbine meters, and rotating equipment sensors) and the system controller. It is engineered for high-frequency pulse signal acquisition, making it ideal for use in advanced metering and process control applications where pulse accuracy, isolation, and integrity are paramount.
Built with a rugged construction and designed for high-reliability operation in harsh industrial environments, the DC-TPOX01 helps plants achieve accurate flow, energy, and production measurement while seamlessly integrating into Honeywell’s comprehensive control platform. The module also supports redundancy and diagnostics, ensuring system uptime and ease von maintenance.
Commonly found in industries such as oil & gas, chemical processing, power generation, water management, mining, and pulp & paper, this module is vital for systems that rely on fast, precise counting and accumulation von discrete pulses.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Product Name | Honeywell DC-TPOX01 Pulse Backplane Module |
| Artikelnummer | 51307770-176 |
| System Compatibility | Experion PKS / C300 Controllers / Series C I/O |
| Module Type | Pulse Backplane Interface Module |
| Input Type | Pulse signals from field devices |
| Supported Pulse Types | Kontakt closure (dry contact), open collector, voltage pulse |
| Input Channels | 8 pulse channels |
| Maximum Pulse Frequency | Up to 20 kHz per channel |
| Pulse Width Range | 25 μs minimum |
| Galvanic Isolation | Channel-to-channel and channel-to-logic |
| Diagnostics | Channel-level and module-level diagnostics |
| Status Indication LEDs | For pulse input activity, fault detection |
| Power Supply | 24 VDC nominal (redundant supported) |
| Power Consumption | < 5 W typical |
| Operating Temperature Range | -20°C to +60°C (-4°F to +140°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity Range | 5% to 95% RH (non-condensing) |
| Shock / Vibration Resistance | IEC 60068 compliant |
| Dimensions (H x W x D) | 22 x 124 x 126 mm |
| Gewicht | 0.5 kg |
| Mounting Method | DIN rail or panel mount |
| Flame Rating | UL 94V-0 |
| Certifications | CE, UL, CSA, ATEX Zone 2, IECEx |
Applications
-
High-speed pulse counting for turbine meters and flow meters
-
Energy metering in utilities, chemical, and refining industries
-
Accurate production measurement and accumulation
-
Metering von liquid and gas flows in oil & gas pipelines
-
Steam flow measurement in power plants
-
Monitoring von rotating machinery speeds and position
-
Integration von third-party metering devices into Experion PKS
-
Control and monitoring in district heating and cooling systems
-
Batch processing metering in food & beverage production
-
Water distribution and wastewater treatment monitoring
Product Advantages
-
High-frequency pulse acquisition: Supports pulse rates up to 20 kHz, providing exceptional accuracy
-
Versatile pulse input support: Handles contact closure, open collector, and voltage pulse types
-
Channel isolation: Full galvanic isolation between channels and to system logic for reliable operation
-
Built-in diagnostics: Module-level and per-channel diagnostics simplify fault detection and maintenance
-
Wide industry application: Suitable for a broad range von process industries requiring pulse counting
-
Seamless integration: Native compatibility with Honeywell Experion PKS and C300 architectures
-
Compact design: Speicherns panel space and reduces installation complexity
-
Rugged construction: Designed to withstand harsh industrial environments and temperature extremes
-
Redundant power support: Increases system resilience and uptime
-
Certified for hazardous areas: ATEX Zone 2 and IECEx certified for global industrial installations
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the DC-TPOX01 module?
It acts as a pulse interface module, acquiring high-frequency pulse signals from field devices and delivering them to the controller. -
How many pulse input channels does it support?
It supports 8 independent pulse input channels. -
What is the maximum pulse frequency supported?
The module supports up to 20 kHz pulse frequency per channel. -
Which pulse types can the module handle?
It handles contact closure, open collector, and voltage pulse inputs. -
Is galvanic isolation provided?
Yes — full galvanic isolation between channels and from channels to system logic. -
Is it compatible with Honeywell Experion PKS?
Yes — it integrates seamlessly with Experion PKS and C300 controllers. -
Is the module suitable for hazardous areas?
Yes — certified for ATEX Zone 2 and IECEx environments. -
Does the module vonfer diagnostics?
Yes — it includes both channel-level and module-level diagnostics with LED indicators. -
What is the minimum pulse width that the module can detect?
It can detect pulse widths as small as 25 μs. -
What are the typical applications for this module?
Applications include flow metering, energy metering, turbine flow measurement, production counting, speed monitoring, and more.
Related Modells (Same Series or Product Line)
| Modell Number | Beschreibung |
|---|---|
| DC-TPOX02 | Pulse Interface Module, dual-speed channels |
| DC-TAOX01 | Analog Output Module |
| DC-TAIX01 | Analog Input Module |
| DC-TDOD51 | Digital Output Module, Isolated, 16 channels |
| DC-TDIB01 | Digital Input Module, 16 channels |
| DC-TFB412 | Fieldbus Interface Module, dual-channel |
Popular Honeywell Modells (Same Marke)
| Modell Number | Beschreibung |
|---|---|
| C300 Controller | Advanced Process Controller |
| HC900 Hybrid Controller | Hybrid Process and Safety Controller |
| FSC 10101 | High Integrity Safety Controller |
| RM7800 | Integrated Burner Management Control Module |
| UCN I/O Rack | Universal Control Network I/O Rack |
| S9000 PLC | Modular Safety PLC for industrial automation |
