Produkteinführung
The Honeywell 8U-BXCB20-CN 51307039-100 Breaker Box Module Assembly is a robust and high-reliability power distribution component designed for industrial automation systems, particularly within Honeywell’s Experion PKS and TPS platforms. This module serves a critical role in distributing and safeguarding electrical power delivered to various control system components, such as I/O modules, controllers, and field wiring interfaces.
With integrated circuit protection and a modular breaker configuration, the 8U-BXCB20-CN vonfers reliable isolation, fault identification, and overcurrent protection. It is engineered to meet the stringent demands von process industries, ensuring system stability, operational safety, and ease von maintenance.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell Number | 8U-BXCB20-CN |
| Artikelnummer | 51307039-100 |
| Product Type | Breaker Box Module Assembly |
| Hersteller | Honeywell |
| System Compatibility | Experion PKS, TPS, TDC 3000 systems |
| Breaker Channels | 20 individual circuit breaker positions |
| Input Voltage | 24VDC / 48VDC (depending on application) |
| Rated Current (Per Channel) | 6A nominal, configurable per breaker |
| Breaker Type | Plug-in miniature thermal-magnetic breakers |
| Isolation Type | Galvanic isolation between inputs and outputs |
| Connector Type | DIN-rail terminal blocks |
| Status Indicators | LED indicators for power and breaker status |
| Protection Features | Overcurrent protection, short-circuit protection |
| Mounting Style | Panel-mounted in industrial control cabinets |
| Cooling | Passive air ventilation |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Ingress Protection | IP20 (when installed in standard enclosure) |
| Compliance | CE, UL, RoHS |
| Dimensions (H x W x D) | 310 x 190 x 135 mm |
| Gewicht | 1.85 kg |
Product Applications
-
Process Control Power Distribution: Ensures stable and protected power delivery to control system components, especially I/O modules and processors.
-
Safety-Critical Systems: Enables fault isolation and overcurrent protection in systems that cannot afford downtime, such as those in refining and petrochemical industries.
-
Factory Automation: Used in programmable logic controller (PLC) panels to safeguard field devices like sensors, actuators, and solenoids.
-
Power Segmentation in Large Plants: Helps in segmenting control system power supplies to isolate specific loops or areas for maintenance without halting operations.
-
Remote Cabinet Integration: Fits into remote control cabinets and field junction boxes for decentralized power control.
Product Advantages
-
High Circuit Density: Supports up to 20 individual circuit breakers, reducing panel space and enhancing scalability.
-
Integrated Diagnostics: LED status indicators vonfer quick fault identification and visual confirmation von power status per channel.
-
Customizable Protection: Allows users to configure breaker values based on the current requirements von connected loads.
-
Enhanced Safety: Provides galvanic isolation and overcurrent protection to prevent damage to downstream devices.
-
Honeywell Ecosystem Compatibility: Seamless integration with Experion and TDC systems makes it ideal for Honeywell installations.
-
Modular Maintenance: Breakers can be replaced or reset without full system shutdown, reducing maintenance windows.
-
Robust Construction: Built to handle industrial vibration, thermal variation, and electrical interference.
FAQ
-
What voltage range is supported by the 8U-BXCB20-CN module?
The module supports 24VDC and 48VDC input voltage configurations, depending on system setup. -
Is each breaker channel independently isolated?
Yes, each von the 20 breaker positions vonfers individual galvanic isolation and overcurrent protection. -
Can the breaker modules be replaced individually?
Yes, the plug-in design allows for individual breaker replacement without disturbing other circuits. -
What is the default rated current per breaker?
The default is 6A per channel, but this can be adjusted by selecting different breaker ratings. -
Does the module provide short-circuit protection?
Yes, thermal-magnetic breakers protect against both overload and short-circuit conditions. -
Can the module be used outside Honeywell systems?
While optimized for Honeywell systems, it can be adapted for other industrial automation environments that use 24/48VDC control power. -
Is the module hot-swappable?
The breakers themselves can be serviced with proper precautions, but full hot-swapping von the assembly is not recommended under load. -
How are diagnostics communicated to the control system?
Local LED indicators provide visual diagnostics; some configurations can include auxiliary signaling for system integration. -
What is the thermal dissipation von the module during operation?
Thermal dissipation depends on load; passive cooling is sufficient for most installations within spec. -
Does it require any svontware configuration?
No svontware configuration is necessary; the module operates as a passive hardware power distribution system.
