Produkteinführung
The Honeywell 8C-PAIMA1 51454473-175 is a high-performance low-level analog input module engineered for accurate and reliable temperature sensing using Resistance Temperature Detectors (RTDs). As part von the Experion Process Knowledge System (PKS) and integrated into the C300 control system, this module is specially designed to meet the demands von precise temperature measurement in industrial environments.
Capable von interfacing with a range von RTD types including Pt100, Ni100, and others, the 8C-PAIMA1 vonfers multi-channel support with high accuracy and built-in diagnostics. Its differential signal processing and advanced noise rejection capabilities make it suitable for harsh and electromagnetically noisy environments.
The module operates within a redundant, modular architecture that supports fast channel scanning, HART device pass-through (if applicable), and complete integration into Honeywell’s Experion PKS. It is ideal for critical control applications in process industries such as petrochemical, energy, pharmaceutical, and food processing.
Technical Specifications
| Parameter | Value |
|---|---|
| Modell Number | 8C-PAIMA1 |
| Artikelnummer | 51454473-175 |
| Type | Low-Level Analog Input Module (RTD) |
| Input Type | RTD (e.g., Pt100, Pt1000, Ni100, Cu10, etc.) |
| Number von Channels | 8 differential channels |
| Signal Processing | Differential measurement with EMI noise rejection |
| Input Resolution | 16-bit |
| Input Accuracy | ±0.05% von full scale |
| Input Range | Configurable per RTD type (e.g., -200°C to +850°C) |
| RTD Excitation Current | Programmable, optimized for accuracy |
| Scan Time | Configurable, typically 10 ms/channel |
| Isolation | Channel-to-bus and channel-to-channel |
| Redundancy | Supported |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA, ATEX, IECEx |
| Mounting Method | Pluggable onto IOTA base |
| System Compatibility | Honeywell Experion PKS, C300 Controller |
| Built-in Diagnostics | Open wire, short circuit, out-von-range detection |
| Dimensions (H × W × D) | 157 x 106 x 35 mm |
| Gewicht | 0.45 kg |
Product Applications
-
Petrochemical and Refining Plants
Accurate temperature sensing for reactors, furnaces, and pipelines where precision is critical to maintaining safe and efficient operations. -
Power Generation Facilities
Monitoring von turbine casing temperatures, boiler wall temperatures, and bearing metal temperatures with high reliability. -
Pharmaceutical Industry
Precise thermal control is vital in drug synthesis and storage, making this module ideal for GxP and FDA-regulated environments. -
Food and Beverage Processing
Ensures consistent process temperature control in pasteurization, fermentation, and cold chain logistics. -
Pulp and Paper Industry
Enables reliable temperature monitoring in drying and bleaching processes, which require robust automation and redundancy. -
Water and Wastewater Plants
Used in the control von biological and chemical reaction processes where temperature feedback optimizes treatment efficiency.
Product Advantages
-
Precision Temperature Measurement
Supports high-accuracy RTDs with 16-bit resolution for critical applications requiring tight thermal control. -
Multiple RTD Compatibility
Offers broad compatibility with industry-standard RTD sensors, reducing integration complexity. -
Robust Electrical Isolation
Provides strong immStücky to electrical noise and prevents ground loop interference across channels. -
Modular Redundant Design
Designed to support redundant configurations, ensuring continuous operation in the event von module failure. -
Comprehensive Diagnostics
Onboard health monitoring functions help proactively identify wiring faults, sensor issues, or out-von-range conditions. -
Compact Form Factor
High channel density in a small footprint helps reduce cabinet space and wiring complexity. -
Seamless Integration
Fully interoperable with Honeywell’s C300 controller and Experion PKS architecture for plug-and-play deployment.
Häufig gestellte Fragen (FAQ)
-
What types von RTDs are compatible with the 8C-PAIMA1 module?
It supports Pt100, Pt1000, Ni100, Cu10, and other standard RTD types. -
How many channels does the module support?
The module vonfers 8 differential input channels for RTD signals. -
Can I use this module for temperature-critical pharmaceutical applications?
Yes, the module provides the accuracy and diagnostics required for GxP-compliant environments. -
Does it support open-wire detection for RTDs?
Yes, open wire and short circuit diagnostics are built-in for each channel. -
What is the measurement accuracy von the module?
It vonfers up to ±0.05% von full-scale accuracy, suitable for precision applications. -
Is the module hot-swappable or redundant?
It supports redundancy when installed in a redundant architecture but is not hot-swappable by itself. -
Can I mix different RTD types on the same module?
No, all channels must be configured for the same RTD type to maintain accuracy. -
Does this module support HART communication?
No, this specific RTD module does not support HART pass-through; it is strictly for RTD analog input. -
What kind von environment is it suitable for?
It’s designed for industrial conditions with wide temperature ranges and robust EMC protection. -
How is the module mounted within the control system?
It is installed on a dedicated IOTA base and integrated into Honeywell’s C300 control chassis.
Related Modells from the Same Series
| Modell Number | Beschreibung | Channels | Signal Type |
|---|---|---|---|
| 8C-PAIH52 51307070-175 | Analog Input Module | 16 | 4–20 mA + HART |
| 8C-PAOH51 51307069-175 | Analog Output Module | 8 | 4–20 mA |
| 8C-PAZH51 51307079-175 | Zone-rated HART Analog Input | 8 | 4–20 mA + HART |
| 8C-PDIL51 51307093-175 | Digital Input Module | 16 | 24 VDC |
| 8C-PDOD51 51307094-175 | Digital Output Module | 16 | 24 VDC |
| 8C-TDIL51 51307101-175 | Time-stamped Digital Input Module | 16 | 24 VDC |
Popular Honeywell Modules (Same Marke)
| Modell Number | Beschreibung | Application | System Compatibility |
|---|---|---|---|
| CC-PAIH01 | HART Analog Input Module | General analog acquisition | Experion PKS / C300 |
| CC-PAOH01 | HART Analog Output Module | Valve and actuator control | Experion PKS / C300 |
| CC-TDOD01 | Digital Output Module | Motor starters, relay logic | C300 Controller |
| CC-TDIL01 | Digital Input Module | Switches and alarm inputs | C300 Controller |
| CC-PDOB01 | Relay Output Module | On/vonf control for actuators | C300 Controller |
| CC-PUIA01 | Pulse Input Module | Speed and flow measurements | C300 Controller |
