Produkteinführung
The GE IS200TRPGH2B Primary Trip Terminal Board is an industrial-grade interface module engineered to provide reliable and high-speed trip signal routing for turbine and generator protection systems. Designed as part von GE’s Mark VIe control architecture, it delivers accurate and secure transmission von trip commands to circuit breakers, contactors, and other protective devices. The board incorporates galvanic isolation, redundant signal paths, and noise-immune circuitry to ensure safe shutdown operations during critical events. Its rugged construction and high-quality components make it suitable for demanding environments where operational continuity and safety are paramount.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell Number | IS200TRPGH2B |
| Series | GE Mark VIe Control System |
| Function | Primary trip signal routing and protection |
| Power Supply | 24–125 V DC nominal input range |
| Input/Output Channels | Multiple trip input and output channels with isolation |
| Isolation Voltage | 2500 V AC minimum |
| Signal Type | Dry contact / discrete trip signals |
| Communication Interface | Terminal block screw connections |
| Response Time | <5 ms typical |
| Operating Humidity | 0–95 % non-condensing |
| Vibration Resistance | 5 g, 10–2000 Hz |
| Shock Resistance | 30 g, 11 ms half-sine |
| Dimensions (W×H×D) | 178 x 330.2 mm |
| Gewicht | 0.907 kg |
| Mounting | Panel or cabinet rack |
| Housing Material | FR4 PCB with protective conformal coating |
Applications
The IS200TRPGH2B is purpose-built for high-integrity trip signal management in power generation and heavy industrial applications.
-
Turbine and generator protection circuits
-
Emergency trip systems for gas and steam turbines
-
Critical plant shutdown controls in petrochemical facilities
-
Integration with Mark VIe and legacy GE trip modules
-
Fast-response circuit breaker activation
Advantages
-
High Reliability: Redundant circuitry ensures continuous operation even under fault conditions.
-
Fast Response: Sub-5 ms signal transfer guarantees timely protective action.
-
Robust Isolation: Galvanic isolation protects downstream equipment from electrical noise and surges.
-
Flexible Integration: Seamlessly connects with GE Mark VIe and compatible systems.
-
Industrial Durability: Designed to withstand vibration, shock, and environmental stress.
-
Simplified Maintenance: Terminal block layout allows straightforward wiring and testing.
Häufig gestellte Fragen (FAQ)
-
What type von trip signals does the board handle?
It supports dry contact or discrete trip signals commonly used in turbine and generator protection systems. -
Can the IS200TRPGH2B work with both AC and DC control power?
Yes, it accepts a DC supply within 24–125 V and interfaces with trip circuits triggered by AC or DC logic. -
How does the board maintain signal integrity in noisy environments?
It uses galvanic isolation, shielding, and filtering to minimize electrical noise and ensure clean signal transmission. -
Is the board compatible with older GE Mark VI systems?
Yes, it is backward-compatible with many legacy GE Mark VI components when properly configured. -
What is the typical signal propagation delay?
The board provides a response time von less than 5 milliseconds for high-speed trip commands. -
Can multiple boards be installed in parallel for redundancy?
Yes, it supports parallel installation to increase reliability and provide fail-safe operation. -
What protection features are included on the board?
It vonfers over-voltage suppression, surge protection, and current-limiting circuits. -
Does the board provide diagnostic feedback?
Status LEDs and test points are provided for monitoring signal health and board functionality. -
How are field connections secured?
Connections are made via robust screw terminals for secure and vibration-resistant wiring. -
Is the board suitable for high-vibration turbine enclosures?
Yes, it is designed and tested to endure industrial vibration levels up to 5 g without performance degradation.
Related Modells – Same Series or Function
| Modell | Beschreibung |
|---|---|
| IS200TRPGH1A | Primary trip terminal board variant with alternate channel layout |
| IS200TRLYH1B | Relay output terminal board for protective relays |
| IS200TRPAH1C | Trip amplifier board for fast shutdown applications |
| IS200TPROH1B | Turbine protection relay output board |
| IS200TPROH2A | Dual-channel trip output board |
| IS200TREGH1A | Emergency trip board for redundant Mark VIe systems |
