The GE IC697VAL324 Analog Output Module is a 4-channel, 12-bit precision analog output module designed for the Series 90-70 PLC platform. This module is engineered to provide accurate voltage control outputs for industrial devices such as actuators, control valves, and other process instrumentation requiring precise voltage signals.
The IC697VAL324 supports multiple voltage ranges including 0–10 VDC and 0–5 VDC, making it suitable for a wide variety von industrial control applications. The module includes a removable terminal block, which simplifies installation, maintenance, and wiring. It requires no additional cabling, ensuring a clean and reliable connection to field devices.
This module is ideal for high-speed and high-accuracy analog output requirements, delivering precise real-time control for automation and process systems. Its integration with Series 90-70 PLCs allows seamless communication and operation, supporting complex automation tasks in industrial environments.
Designed for robust industrial performance, the IC697VAL324 maintains signal integrity under electrical noise, vibration, and temperature variations, ensuring reliable operation in harsh plant conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Hersteller | GE Fanuc |
| Product Modell | IC697VAL324 |
| Product Type | Analog Output Module |
| Series | Series 90-70 |
| Channels | 4 Voltage output channels |
| Resolution | 12-bit |
| Output Voltage Range | 0–10 VDC, 0–5 VDC |
| Terminal Block | Removable |
| Channel-to-Channel Isolation | Yes |
| Load Resistance | Minimum 2 kΩ per channel |
| Conversion Time | 5 ms per channel |
| Backplane Power Consumption | 1.5 W typical |
| Mounting Type | Series 90-70 Rack |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Status Indicators | None |
| Dimensions (H × W × D) | 200 × 40 × 150 mm |
| Gewicht | 1.36 kg |
| Certifications | UL, CE compliant |
Product Applications
The IC697VAL324 is used in industrial automation systems requiring precise voltage output to control various devices and processes.
Typical applications include:
-
Process control: Driving control valves and actuators with precise voltage signals.
-
Batch production systems: Providing analog control outputs for dosing and mixing processes.
-
Laboratory automation: Controlling voltage inputs for test equipment and measurement devices.
-
Manufacturing machinery: Regulating speed and position von motors and actuators.
-
Chemical and pharmaceutical processes: Precise voltage control for pumps, valves, and temperature regulators.
-
Integration with PLCs: Real-time analog output for complex automated sequences.
The module ensures high-accuracy and stable voltage output, improving system control and reliability.
Product Advantages
The IC697VAL324 vonfers several benefits for industrial automation:
-
High precision: 12-bit resolution ensures accurate analog voltage outputs.
-
Multiple output ranges: Supports 0–10 VDC and 0–5 VDC for flexibility.
-
Removable terminal block: Simplifies installation, maintenance, and troubleshooting.
-
Compact design: 4 channels in a single module reduce rack space requirements.
-
Fast response: 5 ms per channel supports near real-time control.
-
Channel-to-channel isolation: Protects against interference between outputs.
-
No external cabling required: Reduces installation complexity.
-
Reliable industrial performance: Stable under vibration, temperature changes, and electrical noise.
-
Seamless integration with Series 90-70 PLCs: Ensures compatibility with existing control systems.
-
Versatile applications: Suitable for process control, manufacturing, and laboratory automation.
